Volume 7 : Multi-Layer Tray Feeder
INSTRUCTION MANUAL
MODULAR MOUNTER
SIGMA-G4/G5
Before using this manual, please note the following items.
1. The contents of this manual are subject to change for improvement
without prior notice. Please pay attention to the latest information such as
the CS news that will be provided or issued by our company.
2. The copyright of the instruction manual belongs to Hitachi High-Tech
Instruments Co., Ltd.
This manual shall not in any shape or form, in whole or part, be
reproduced, copied or disclosed to any third party without the written
content of the publisher.
3. Our company shall not be held to any liability for any damages suffered
or incurred by the end user, arising from any operations other than those
(including the purposes and methods) described in this instruction manual.
Be sure to handle the machine carefully.
4. This instruction manual neither guarantees any license to industrial
property rights, etc., nor grants any license of such rights.
0908-001
7OM-1603
11007-003
Before Use
We are grateful to you for purchasing our multi-layer tray feeder (GS-FP100/200) for the
Hitachi modular mounter (Chip Mounter).
This product is used to supply the tray components onto the chip mounter SIGMA-G4/
G5. (The installation of GS-FP200 (Full-size Multi-Layer Tray Feeder) onto SIGMA-G4
is not available).
This instruction manual describes the functions, handling, and operations of the multi-
layer tray feeder for those who have nished the basic training of the chip mounter.
Before operating the machine, please read this instruction manual carefully to fully
understand the instructions and precautionary measures for safety purposes.
After reading this instruction manual, be sure to keep it at hand for your quick reference.
