AV131
ERROR CODE LIST
2.4 Errors
D79EEC-91-210-A0
2.4-3
39
(-) Overrun
DESCRIPTION
Axis (-) overrun sensor is ON.
CAUSE
Trouble of sensor
SOLUTION
Execute return to origin in the [Ret orig] of [Machine adjustment].
Confirm I/O sensor status in the [Input check] of [Machine adjustment].
Confirm setting of CPU box board (MCMJEX) and connection of connector.
Please inform us the axis name and the situation.
NOTE
40
Driver error
DESCRIPTION
A motor driver error was detected
CAUSE
The motor drive detected an error.
SOLUTION
Confirm the error code on the 7-segment LED of the motor driver of the axis concerned.
Turn power OFF and ON, and leave 5 minutes with the main menu displayed. Then, restart the system.
Contact us along with the axis name, displayed error code and the situation.
NOTE
47
Interlock error
DESCRIPTION
Unregistered interlock error occurred.
CAUSE
NC board detected an error of an unregistered axis number.
SOLUTION
Contact us along with the axis name and the situation.
If the system cannot be restarted, turn power OFF once and turn it back ON.41307
NOTE
49
Axis controller communication error
DESCRIPTION
No response from axis controller.
CAUSE
No response against command to axis controller.
SOLUTION
Please inform us the axis name and the situation.
NOTE
51
Conveyor width adjust error
DESCRIPTION
Unable to width adjust because PCB exist on the conveyor.
CAUSE
Width cannot be adjusted when there is a PCB on the conveyor because it may drop or get caught.
SOLUTION
Remove PCB.
NOTE
53
Power box over heat
DESCRIPTION
Temperature in power box is high.
CAUSE
Temperature in power box is over the reference value.
SOLUTION
Check fan moving.
NOTE
AV131
ERROR CODE LIST
2.4 Errors
D79EEC-91-210-A0
2.4-4
54
CPU box over heat
DESCRIPTION
Temperature in CPU box is high.
CAUSE
Temperature in CPU box is over the reference value.
SOLUTION
Check fan moving.
NOTE
61
Safety relay error
DESCRIPTION
Problem occurs in safety relay.
CAUSE
Safety relay may be faulty.
SOLUTION
Power OFF and ON. Please inform us situation.
NOTE
112
Illegal product data
DESCRIPTION
Production data check detects an error in self diagnosis.
CAUSE
Production data has an error.
SOLUTION
Check the error item at [Data check] in [Data modification] and correct data.
NOTE
1203
PCB Recognition Error
DESCRIPTION
A PCB recognition error was detected.
CAUSE
Insertion position may be incorrect.
Part may already have been inserted.
Lighting for recognition may not be lit.
SOLUTION
Modify the insertion position to the correct coordinates.
Check the condition of the insertion position.
Check the condition of the lighting.
NOTE
1236
Momentary power failure error
DESCRIPTION
Low voltage, power failure, Momentary power failure was detected.
CAUSE
The voltage of the R-S phase or the S-T phase is lack of phase more than 24ms.
SOLUTION
Please turn off the main switch and turn on the main switch again. Please confirm the voltage of power supply when
the error occurs repeatedly.
NOTE
1239
Code Error
DESCRIPTION
Software error was occurred.
CAUSE
Software codes may be abnormal.
SOLUTION
Call the Servicing Department of our company.
NOTE
AV131
ERROR CODE LIST
2.4 Errors
D79EEC-91-210-A0
2.4-5
1250
DriverReadyTimeOut
DESCRIPTION
The axis driver condition does not become Ready.
CAUSE
The axis controller or servo driver may have failed.
SOLUTION
Call the Servicing Department of our company.
NOTE
1300
Emergency stop switch
DESCRIPTION
Emergency stop switch is kept pressed.
CAUSE
Emergency stop signal was detected.
SOLUTION
Please pull and release the emergency stop switch.
NOTE
1301
Servo switch
DESCRIPTION
Servo switch is OFF.
CAUSE
Servo switch OFF signal was detected.
SOLUTION
Turn ON the servo switch.
NOTE
1302
Cover open
DESCRIPTION
Cover is open.
CAUSE
Safety cover is left open.
SOLUTION
Close the cover.
NOTE
1303
Air pressure
DESCRIPTION
Air pressure is down.
CAUSE
Air pressure is lower than the standard value or the air is not supplied.
SOLUTION
Feed the air at the pressure between 0.49MPa - 0.78MPa.
NOTE
1304
Pre Process Production End
DESCRIPTION
Ending signal from preceding process has been detected.
CAUSE
Preceding machine is sending the signal of ending the production.
SOLUTION
Turn OFF the Ending signal from preceding process.
NOTE
