AV131
ERROR CODE LIST
2.4 Errors
D79EEC-91-210-A0
2.4-28
2275
Arm carry condition not satisfies (transfer arm return limit)
DESCRIPTION
Transfer arm movement was not done because of the lack of the transfer arm movement condition.
CAUSE
Transfer arm return limit has been turned off.
SOLUTION
It is necessary to have turned on the transfer arm return limit to move transfer arm.
NOTE
2281
Arm carry condition not satisfies (XY origin)
DESCRIPTION
Transfer arm movement was not done because of the lack of the transfer arm movement condition.
CAUSE
X or Y axis origin sensor has been turned off.
SOLUTION
It is necessary to have turned on the X and Y axis origin sensor to move transfer arm.
NOTE
2282
Arm carry condition not satisfies (XY movement)
DESCRIPTION
Transfer arm movement was not done because of the lack of the transfer arm movement condition.
CAUSE
X or Y axis is moving.
SOLUTION
It is necessary to have stopped X and Y axis to move transfer arm.
NOTE
2308
Arm slowdown condition not satisfies (left rail traverse limit)
DESCRIPTION
Arm slowdown was not done because of the lack of the slowdown condition.
CAUSE
Left rail traverse limit has been turned off.
SOLUTION
It is necessary to have turned on the left rail traverse limit to slowdown.
NOTE
2320
Arm slowdown condition not satisfies (right rail traverse limit)
DESCRIPTION
Arm slowdown was not done because of the lack of the slowdown condition.
CAUSE
Right rail traverse limit has been turned off.
SOLUTION
It is necessary to have turned on the right rail traverse limit to slowdown.
NOTE
2323
Arm slowdown condition not satisfies (servo switch)
DESCRIPTION
Arm slowdown was not done, because of the lack of the slowdown condition.
CAUSE
Servo switch has been turned off.
SOLUTION
It is necessary to have turned on the servo switch to slowdown.
NOTE
AV131
ERROR CODE LIST
2.4 Errors
D79EEC-91-210-A0
2.4-29
2331
Arm slowdown condition not satisfies (XY origin)
DESCRIPTION
Arm slowdown was not done because of the lack of the slowdown condition.
CAUSE
X or Y axis origin sensor has been turned off.
SOLUTION
It is necessary to have turned on the X and Y axis origin sensor to slowdown.
NOTE
2332
Arm slowdown condition not satisfies (XY movement)
DESCRIPTION
Arm slowdown was not done because of the lack of the slowdown condition.
CAUSE
X or Y axis is moving.
SOLUTION
It is necessary to have stopped X and Y axis to slowdown.
NOTE
2358
Rail up condition not satisfies (left rail traverse limit)
DESCRIPTION
Rail up action was not done because of the lack of the rail up condition.
CAUSE
Left rail return limit has been turned off.
SOLUTION
It is necessary to have turned on the left rail return limit to up rail.
NOTE
2365
Rail up condition not satisfies (positioner lever traverse limit)
DESCRIPTION
Rail up action was not done because of the lack of the rail up condition.
CAUSE
Positioner lever traverse limit has been turned off.
SOLUTION
It is necessary to have turned on the positioner lever traverse limit to up rail.
NOTE
2370
Rail up condition not satisfies (right rail traverse limit)
DESCRIPTION
Rail up action was not done because of the lack of the rail up condition
CAUSE
Right rail return limit has been turned off.
SOLUTION
It is necessary to have turned on the right rail return limit to up rail.
NOTE
2373
Rail up condition not satisfies (servo switch)
DESCRIPTION
Rail up action was not done because of the lack of the rail up condition.
CAUSE
Servo switch has been turned off.
SOLUTION
It is necessary to have turned on the servo switch to up rail.
NOTE
AV131
ERROR CODE LIST
2.4 Errors
D79EEC-91-210-A0
2.4-30
2374
Rail up condition not satisfies (transfer arm traverse limit)
DESCRIPTION
Rail up action was not done because of the lack of the rail up condition.
CAUSE
Transfer arm traverse limit has been turned off.
SOLUTION
It is necessary to have turned on the transfer arm traverse limit to up rail.
NOTE
2381
Rail up condition not satisfies (XY origin)
DESCRIPTION
Rail up action was not done because of the lack of the rail up condition.
CAUSE
X or Y axis origin sensor has been turned off.
SOLUTION
It is necessary to have turned on the X and Y axis origin sensor to up rail.
NOTE
2382
Rail up condition not satisfies (XY movement)
DESCRIPTION
Rail up action was not done because of the lack of the rail up condition.
CAUSE
X or Y axis is moving.
SOLUTION
It is necessary to have stopped X and Y axis to up rail.
NOTE
2409
Arm return condition not satisfies (left rail return limit)
DESCRIPTION
Arm return action was not done because of the lack of the return condition.
CAUSE
Left rail return limit has been turned off.
SOLUTION
It is necessary to have turned on the left rail return limit to return arm.
NOTE
2416
Arm return condition not satisfies (positioner return limit)
DESCRIPTION
Arm return action was not done because of the lack of the return condition.
CAUSE
Positioner lever return limit has been turned off.
SOLUTION
It is necessary to have turned on the positioner lever return limit to return arm.
NOTE
2421
Arm return condition not satisfies (right rail return limit)
DESCRIPTION
Arm return action was not done because of the lack of the return condition.
CAUSE
Right rail return limit has been turned off.
SOLUTION
It is necessary to have turned on the right rail return limit to return arm.
NOTE
