AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-35

2646

H axis Servo ON error

DESCRIPTION

H axis servo is not ready condition.

CAUSE

H axis motor driver detect low voltage.

SOLUTION

Please check H axis condition. If servo alarm occurs, turn machine off and on.

NOTE

2647

Handle detection error

DESCRIPTION

Pushing H axis rotation wheel was detected.

CAUSE

H axis wheel detection (800C3:bit2) was detected while H axis was running.

SOLUTION

Please return H axis rotation wheel to original position.

NOTE

2648

No PCB on XY table

DESCRIPTION

XY table failed to detect PCB.

CAUSE

Reference pin has not been positioned to the reference hole of the PCB correctly.

Faulty PCB detection sensor

Bent PCB detection lever

SOLUTION

Check if the PCB is positioned properly to the XY table.

Check that the PCB detection sensor functions properly.

Check the PCB detection lever for any bent.

NOTE

2649

Carry miss

DESCRIPTION

PCB loading or unloading failure was detected.

CAUSE

Pin of the PCB transfer arm may not have been positioned properly.

Rail width may be not wide enough to feed PCB smoothly.

Orientation of PCB may be incorrect.

SOLUTION

Check the transfer arm for proper condition.

Check for correct PCB rail width.

Check the PCB for proper condition.

NOTE

2652

Rear left safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the left feeder cover.

CAUSE

The cover of the left feeder has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-36

2653

Rear right safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the right feeder cover.

CAUSE

The cover of the right feeder has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

2654

Rear left center safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the left center feeder cover.

CAUSE

The cover of the left center feeder has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

2655

Rear right center safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the right center feeder cover.

CAUSE

The cover of the right center feeder has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

2656

Front cover safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the front cover.

CAUSE

The cover of the front has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

2657

Right rail cover safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the right rail cover.

CAUSE

The cover of the right rail has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

2658

Left rail cover safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the left rail cover.

CAUSE

The cover of the left rail has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-37

2659

Rear upper cover safety detection

DESCRIPTION

The machine became a safety stop condition by the safety detection in the rear upper cover.

CAUSE

The cover of the rear upper has been opened.

SOLUTION

Press [Return] after closing the cover. Then please release the safety stop condition to push <Start> with

<ENABLING>.

NOTE

2663

Cancel replacement completion input (open rear left cover)

DESCRIPTION

Part replacement completion input was canceled.

CAUSE

Rear left cover was opened.

SOLUTION

Please close the rear left cover then input part replacement completion switch again.

NOTE

2664

Cancel replacement completion input (open rear right cover)

DESCRIPTION

Part replacement completion input was canceled.

CAUSE

Rear right cover was opened.

SOLUTION

Please close the rear right cover then input part replacement completion switch again.

NOTE

2665

Cancel replacement completion input (float left feeder)

DESCRIPTION

Part replacement completion input was canceled.

CAUSE

Feeder in the left part supply floats.

SOLUTION

Please confirm feeder condition then input part replacement completion switch again.

NOTE

2666

Cancel replacement completion input (float right feeder)

DESCRIPTION

Part replacement completion input was canceled.

CAUSE

Feeder in the right part supply floats.

SOLUTION

Please confirm feeder condition then input part replacement completion switch again.

NOTE

2668

Cancel replacement completion input (never open rear left cover)

DESCRIPTION

Part replacement completion input was canceled.

CAUSE

Part replacement completion operation was done without opening the rear left cover.

SOLUTION

Please close the cover after opening the cover once then input part replacement completion switch again.

NOTE
