AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-43

2736

Arm carry condition not satisfies

DESCRIPTION

The transfer arm failed to move.

CAUSE

Lack of conditions required for moving the transfer arm.

SOLUTION

Check the conditions for moving the transfer arm.

NOTE

2737

Arm slowdown condition not satisfies

DESCRIPTION

The transfer arm failed to slow down.

CAUSE

Lack of conditions required for slowing down the transfer arm.

SOLUTION

Check the conditions for slowing down the transfer arm.

NOTE

2738

Rail up condition not satisfies

DESCRIPTION

The rail failed to be moved up.

CAUSE

Lack of conditions required for moving up the rail.

SOLUTION

Check the conditions for moving up the rail.

NOTE

2739

Arm return condition not satisfies

DESCRIPTION

The transfer arm failed to return.

CAUSE

Lack of conditions required for returning the transfer arm

SOLUTION

Check the conditions for returning the transfer arm.

NOTE

2748

Emergency stop switch ON safety stop

DESCRIPTION

Emergency switch was detected.

CAUSE

An emergency stop switch was pressed.

SOLUTION

Release the emergency stop switch. (There are five switches. Front; 2 Rear; 3) If the same message appears after

releasing the switch, the switch may be broken. Confirm emergency SW signal in the [Input check] of [Machine

adjustment].

NOTE

2756

Axis related error

DESCRIPTION

Axis fault detected.

CAUSE

An axis error has occurred; however its factors cannot be determined.

SOLUTION

Check the conditions of the time when the error occurred and the details of the error, and then contact us.

NOTE

AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-44

2757

PCB recognition error (23)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Invalid recognition parameter

SOLUTION

Check for any abnormality in the recognition parameter.

NOTE

2758

PCB recognition error (16)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Outline detection error occurred with the recognition hole.

SOLUTION

Check the condition of the PCB hole.

NOTE

2759

PCB recognition error (17)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper hole search area

SOLUTION

Check the value of the search area size in the recognition initial setting. Check the condition of the target hole.

NOTE

2760

PCB recognition error (19)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Scanned image is abnormal.

SOLUTION

Check the camera for proper condition. Check the condition of the target hole.

NOTE

2761

PCB recognition error (45)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper shape of the target hole

SOLUTION

Check the condition of the target hole.

NOTE

2762

PCB recognition error (47)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper diameter of the target hole

SOLUTION

Check the condition of the target hole.

NOTE

AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-45

2763

PCB recognition error (48)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper area of the target hole

SOLUTION

Check the condition (any burrs) of the target hole.

NOTE

2764

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

2765

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

2766

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

2767

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

4066

This is write protected disk.

Please release write protect. Refer to Help for detail.

DESCRIPTION

Unable to write signature to the floppy disk.

CAUSE

Floppy disks formatted by old machine or unformatted disks require a signature.

SOLUTION

Release write protect then operate again.

NOTE
