AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-44

2757

PCB recognition error (23)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Invalid recognition parameter

SOLUTION

Check for any abnormality in the recognition parameter.

NOTE

2758

PCB recognition error (16)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Outline detection error occurred with the recognition hole.

SOLUTION

Check the condition of the PCB hole.

NOTE

2759

PCB recognition error (17)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper hole search area

SOLUTION

Check the value of the search area size in the recognition initial setting. Check the condition of the target hole.

NOTE

2760

PCB recognition error (19)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Scanned image is abnormal.

SOLUTION

Check the camera for proper condition. Check the condition of the target hole.

NOTE

2761

PCB recognition error (45)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper shape of the target hole

SOLUTION

Check the condition of the target hole.

NOTE

2762

PCB recognition error (47)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper diameter of the target hole

SOLUTION

Check the condition of the target hole.

NOTE

AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-45

2763

PCB recognition error (48)

DESCRIPTION

PCB recognition error was detected.

CAUSE

Improper area of the target hole

SOLUTION

Check the condition (any burrs) of the target hole.

NOTE

2764

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

2765

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

2766

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

2767

PCB recognition error

DESCRIPTION

PCB recognition error was detected.

CAUSE

Trouble occurred in PCB recognition.

SOLUTION

Check the condition of the target hole.

NOTE

4066

This is write protected disk.

Please release write protect. Refer to Help for detail.

DESCRIPTION

Unable to write signature to the floppy disk.

CAUSE

Floppy disks formatted by old machine or unformatted disks require a signature.

SOLUTION

Release write protect then operate again.

NOTE

AV131

ERROR CODE LIST

2.4 Errors

D79EEC-91-210-A0

2.4-46

4067

There is no signature on boot sector. Refer to Help for detail.

DESCRIPTION

Access to unsigned floppy disk

CAUSE

Unsigned floppy disk was used.

SOLUTION

Reformat the floppy disk.

NOTE

9293

Driver soft interlock

DESCRIPTION

Driver soft interlock occurred.

CAUSE

Something is wrong with the software processing.

SOLUTION

Check the conditions of the time when the error occurred, and the details of the error, and then contact us.

NOTE

9294

Soft task comm. Error

DESCRIPTION

Soft task comm. Error occurred.

CAUSE

Something is wrong with the software processing.

SOLUTION

Check the conditions of the time when the error occurred, and the details of the error, and then contact us.

NOTE

9295

Soft calculation error

DESCRIPTION

Soft calculation error occurred.

CAUSE

Something is wrong with the software processing.

SOLUTION

Check the conditions of the time when the error occurred, and the details of the error, and then contact us.

NOTE

9304

Motion incomplete

DESCRIPTION

Axis motion is incomplete.

CAUSE

Movement on the Table X-axis is not completed within a specified time.

SOLUTION

Turn off the servo switch, and manually move the faulty axis. When the axis does not move smoothly, lubricate the

ball screw.

Move the faulty axis with a inching, and inform the manufacturer about its moving condition.

NOTE

9305

Soft parameter error

DESCRIPTION

Axis motion is incomplete.

CAUSE

Movement on the Table X-axis is not completed within a specified time.

SOLUTION

Check the contents of invalid software parameter on the error screen and correct the production data or parameter

data if necessary. In addition, inform us of the problem.

NOTE
