1OM-1603
4-13
1. Specications : Chap.4
Item
Description
25. Power Supply
200 ±
20 V AC, 3-Phase, 50/60Hz
Connected to the power supply unit (3-phase 3-wire system)
(The grounding cable should be connected to the PE terminal).
26. Maximum 7.4 kVA
Apparent Power
27. Power
Consumption/
Hour
Approx. 1.80 kWh
28. Dimensions
Approx. 1,280 (Width) mm (Including Input/Output Conveyor)
× 2,200 (Depth) mm
(Including Bank Feeder Change Cart)
× 1,450 (Height) mm
(1,910 mm : Including Tower)
29. Mass
Approx. 1,800 kg
(excluding. the Bank Feeder Change Carts and the tape feeders)
30. Environmental
Requirements for
Bank Feeder
Change Cart
Floor Gradient : 10/1000 or less
Note : The floor should be hard enough for the casters of the cart to move
smoothly.
32. Others
Standard Functions
• Component Library Teaching Function (GS-TR100)
• Placement Position Teaching Function (GS-TZ100)
• Application for BGA/CSP (GS-TB100)
• Automatic Recovery Function for Component Pickup Errors
• Component Pick-Up Position Teaching Function
• Delayed Recovery Function (Recovery Mode)
• Alternate Component Supply Function
• Pick-Up and Placement Up/Down-Axis (L-Axis) Control Function
• Pick-UP Position (X/Y) Correction Control Function
• Pocket outline recognition
• Two-stage placement Z-Axis speed reduction
• Nozzle existence check before pick-up
31. Input and Output
Conforming to the specifications of the SMEMA communications.
Interfaces
T1E1-13
1012-005
1OM-1603
4-14
1. Specications : Chap.4
1.2 Standard Accessory Parts List
No. Product Name Part No. Q'ty Remarks
1
Lens Cleaning Cloth
15 cm × 15 cm
226J1560 5
2
Glass Tube Fuse (6.3 A) 4S300023 1 • Spare
3
Glass Tube Fuse (5 A) 4S300024 1 • Spare
4
Glass Tube Fuse (3.15 A) 4V320011 1 • Spare
5
Glass Tube Fuse (10 A) 4S301007 1 • Spare
6
Fuse with an Alarm Contact (5A) 4S300006 1 • Spare
7
Flat-Type Fuse (5 A) 4S300010 1 • Spare
8
Fuse (2 A) 0916D207 1 • Spare
9
Splicing Joint Detector Cleaning Long
Stick with a Rope
0926B109 1 • For Cleaning the Splicing Joint
Detector
10
Splicing Joint Detector Cleaning
Cotton Applicator
0926B10A 1 • For Cleaning the Splicing Joint
Detector
11
Flame Leg Receiver 216R0353 4
12
Collar (BS Spacer) 216A0334 4 • Flame Leg Receiver
13
Set Screw 221CA010 4 • Flame Leg Receiver
14
Padlock 226J0574 2 • For Locking Power Breaker and Air
Source
15
QFP Glass Plate Jig (JG-0188) 211D9639 1 • For Offset Teaching
16
Nozzle (PK01) PK01---- 1 • For Support Pin Pick-up
17
PCB Support Pin 0974J00U 20 • For PCB Support Pin
18
Cable (3M) 0964B000 1
T1E2-1
1012-005
1OM-1603
4-15
1. Specications : Chap.4
1007-004
1.2.1 Head Accessory List
Note
These head accessories are attached for each head.
• High Speed Head
No. Product Name Part No. Q'ty Remarks
1
Vacuum Filter
225B0572 90
2
High-Speed Nozzle Stocker
Replacement
Section
09198000 1
3
Nozzle (HA09C)
HA09C--- 1
4
Filter
225A0045 480
T1E2-2
• Multi-Functional Head
No. Product Name Part No. Q'ty Remarks
1
Multi-Functional Head Filter
225B0313 18
2
Nozzle (FF01)
FF01---- 1
T1E2-3
