1OM-1603 0908-002 4-B

1OM-1603

1007-003 4-A

Chapter 4

Basic Information

This chapter describes the basic information.

 1.Specications

2. List of Vacuum Nozzle Types

3. Measured Noise Value

1OM-1603

0908-002 4-B

1OM-1603

4-1

1. Specications : Chap.4

1012-005

1. Specications

1.1 Specications of SIGMA-G5 Chip Mounter

Item Description

1. Model Name SIGMA-G5

High-Speed Head Multi-Functional Head2. Throughput

70,000 CPH / module

Note : The PCB transition time under

optimum conditions is

excluded.

Components : 14,500 CPH / 2 heads

Note : The PCB transition time under

optimum conditions is

excluded.

High-Speed Head Multi-Functional Head3. Placement

Accuracy

0603 / 0402 : 40μm (3 σ) IC : 30μm (3 σ)

4. PCB

Transition Time

Approx. 2 seconds (PCB Length : 260 mm or less)

(Under Optimum Conditions)

5. Machine Scope

This machine uses the double-sided operation system on the front and rear of

the machine and single PCB transfer method is used.

6. PCB Flow

Direction and

Transfer Reference

PCB Flow Direction : From Left to Right/From Right to Left

(Selected when shipped from the factory)

Transfer Reference

: Rear Left/Rear Right/Front Left/Front Right

(Selected when shipped from the factory)

T1E1-1
