Fig. D2-2 CPU 1 ボックス CPU 1 Box 120 132 123 127 105 106 104 1 13 103 101 107 126 122 108 102 1 10 1 12 1 14 124 121 131 130 133 133 132 134 133 133 133 1 1 1 109 1 104-003 Fig. D2 CPU ボックス部 CPU BOX SECTION UNIT -3 Fi…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
21 221AA028 ROHS:BOLT_HEX-SCT 3 3 3 3 M5L8 1091401E00-021
22 221HA006 WASHER 3 3 3 3 SW6 1091401E00-022
23 221HA303 ROHS:WASHER 3 3 3 3 BW5 1091401E00-023
24 221DA062 MACHINE SCREW 5 5 5 5 PAN M4L8 SW+FW 1091401E00-024
51 4U260363 EQUIP_(BUSRACK) 1 1 1 1 309140150J-001
52 4B111622 PCB_MOUNT 1 1 1 1 309140150J-002
53 4U200334 UNIT_POWER(ATX) 2 2 2 2 309140150J-003
54 4B111612 P_C_B_MOUNT 1 1 1 1 309140150J-004
55 4B111613 PCB_MOUNT 1 1 1 1 309140150J-005
56 4U250248 UNIT_I/O(CF) 1 1 1 1 309140150J-006
57 24110007 PROGRAM,CD 1 1 1 1 309140150J-007
58 23L00068 RACK_P_C_B 1 1 1 1 309140150J-008
59 4M130041 MOTOR_DC(FAN MOTOR) 1 1 1 1 309140150J-009
60 23M00062 ACCESSORY_MOT-M 2 2 2 2 309140150J-010
61 0914B50F BOX 1 1 1 1 309140150J-011
62 0914B50G COVER 1 1 1 1 309140150J-012
66 211FE291 BRACKET 1 1 1 1 309140150J-016
68 0914B50H SUPPORT 1 1 1 1 309140150J-018
72 23L10063 ACCESSORY_P_C_B 1 1 1 1 309140150J-022
73 23K10390 CASE,CONN 1 1 1 1 309140150J-023
74 4J300191 CABLE JOINT,TERMINAL 1 1 1 1 309140150J-024
75 23N20103 TUBE_WIRING 1 1 1 1 309140150J-025
76 23N20106 TUBE_WIRING 1 1 1 1 309140150J-026
77 23N20109 TUBE,WIRING 1 1 1 1 309140150J-027
78 23N30737 ACCESSORY,WIRING(M 5 5 5 5 309140150J-028
79 226J0373 MOUNTING_BASE 1 1 1 1 309140150J-029
80 221DA053 MACHINE SCREW 19 19 19 19 PAN M4L6 SW+FW 309140150J-030
81 221DA056 MACHINE SCREW 6 6 6 6 PAN M3L8 SW+FW 309140150J-031
83 221DA031 MACHINE SCREW 4 4 4 4 PAN M4L40 309140150J-033
84 221HA004 WASHER 8 8 8 8 SW4 309140150J-034
85 221HA104 WASHER 8 8 8 8 FW4 309140150J-035
86 221FA007 NUT_HEX 4 4 4 4 M4 309140150J-036
Fig. D2
1104-004
Fig. D2-1
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-3
Fig. D2
CPU
Fig. D2-2
CPU 1
ボックス
CPU 1 Box
120
132
123
127
105
106
104
113
103
101
107
126
122
108
102
110
112
114
124
121
131
130
133
133
132
134
133
133
133
111
109
1104-003
Fig. D2 CPU
ボックス部
CPU BOX SECTION
UNIT-3
Fig. D2
CPU
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
101 4B111614 PCB_MOUNT(CPU) 1 1 1 1 309140140R-001
102 4B111620 PCB_MOUNT 1 1 1 1 309140140R-002
103 4B111572 PCB_MOUNT 1 1 1 1 309140140R-003
104 4B111484 PCB_MOUNT 1 1 1 1 309140140R-004
105 0914B40D UNIT_IO(DOM4G) 1 1 1 1 309140140R-005
106 4W204861 CORD 1 1 1 1 309140140R-006
107 4W204580 CORD 1 1 1 1 309140140R-007
108 0914B40P ATX_CABLE 1 1 1 1 309140140R-008
109 24100033 PROG_FLOPPYDISK 1 1 1 1 309140140R-009
110 23L10107 ACCESSORY_PCB 2 2 2 2 309140140R-010
111 23L10108 ACCESSORY_PCB 1 1 1 1 309140140R-011
112 0921E204 ACCESS_WIRING 1 1 1 1 309140140R-012
113 23N30719 ACCESS_WIRING 1 1 1 1 309140140R-013
114 23N300727 ACCESS_WIRING 1 1 1 1 309140140R-014
120 0914B40E CPU1_BOX 1 1 1 1 309140140R-020
121 0914B40H FLONTPANEL 1 1 1 1 309140140R-021
122 0914B40Q USB_BRACKET 1 1 1 1 309140140R-022
123 0914B40K CPU1_COVER 1 1 1 1 309140140R-023
124 0914B40F CPU1_STAY 1 1 1 1 309140140R-024
126 0914B40M PCI_BRACKET_F 1 1 1 1 309140140R-026
127 0914B40N PCI_BRACKET_R 1 1 1 1 309140140R-027
130 221DA107 MACHINE_SCREW 2 2 2 2 FLT M3L8 309140140R-030
131 23N30738 ACCESS_WIRING(M 3 3 3 3 309140140R-031
132 221DC002 MACHINE_SCREW 12 12 12 12 PAN M3L6 SW+FW 309140140R-032
133 221DA056 MACHINE_SCREW 13 13 13 13 PAN M3L8 SW+FW 309140140R-033
134 221DA057 MACHINE_SCREW 3 3 3 3 PAN M3L14 SW+FW
309140140R-034
1104-004
Fig. D2-2
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-3
Fig. D2
CPU
