P-310-004(1_2) - 第142页

MEMO

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

101 4B111614 PCB_MOUNT(CPU) 1 1 1 1 309140140R-001

102 4B111620 PCB_MOUNT 1 1 1 1 309140140R-002

103 4B111572 PCB_MOUNT 1 1 1 1 309140140R-003

104 4B111484 PCB_MOUNT 1 1 1 1 309140140R-004

105 0914B40D UNIT_IO(DOM4G) 1 1 1 1 309140140R-005

106 4W204861 CORD 1 1 1 1 309140140R-006

107 4W204580 CORD 1 1 1 1 309140140R-007

108 0914B40P ATX_CABLE 1 1 1 1 309140140R-008

109 24100033 PROG_FLOPPYDISK 1 1 1 1 309140140R-009

110 23L10107 ACCESSORY_PCB 2 2 2 2 309140140R-010

111 23L10108 ACCESSORY_PCB 1 1 1 1 309140140R-011

112 0921E204 ACCESS_WIRING 1 1 1 1 309140140R-012

113 23N30719 ACCESS_WIRING 1 1 1 1 309140140R-013

114 23N300727 ACCESS_WIRING 1 1 1 1 309140140R-014

120 0914B40E CPU1_BOX 1 1 1 1 309140140R-020

121 0914B40H FLONTPANEL 1 1 1 1 309140140R-021

122 0914B40Q USB_BRACKET 1 1 1 1 309140140R-022

123 0914B40K CPU1_COVER 1 1 1 1 309140140R-023

124 0914B40F CPU1_STAY 1 1 1 1 309140140R-024

126 0914B40M PCI_BRACKET_F 1 1 1 1 309140140R-026

127 0914B40N PCI_BRACKET_R 1 1 1 1 309140140R-027

130 221DA107 MACHINE_SCREW 2 2 2 2 FLT M3L8 309140140R-030

131 23N30738 ACCESS_WIRING(M 3 3 3 3 309140140R-031

132 221DC002 MACHINE_SCREW 12 12 12 12 PAN M3L6 SW+FW 309140140R-032

133 221DA056 MACHINE_SCREW 13 13 13 13 PAN M3L8 SW+FW 309140140R-033

134 221DA057 MACHINE_SCREW 3 3 3 3 PAN M3L14 SW+FW

309140140R-034

1104-004

Fig. D2-2

SIGMA-G5SA

SIGMA-G5SB

SIGMA-G5SC

SIGMA-G5SD

UNIT-3

Fig. D2

CPU

MEMO

CONTENTS

Fig. D3

電装部２

ELECTRICAL

SECTION 2

Fig. D3-A1

全体図１

PARTS LAYOUT-1

Fig. D3-A2

全体図２

ARTS LAYOUT-2

Fig. D3-1



パネル２

Panel 2

Fig. D3-2



パネル１、３

Panel 1, 3

Fig. D3-3



ドライバ、基板

Driver, PCB

Fig. D3-4

照明基板、

LAN

パネル

Lighting PCB, LAN Panel

Fig. D3-5

中継パネル

Relay Panel

Fig. D3-6

ドライバケーブル

Driver Cable

Fig. D3-7

I/O

ケーブル

I/O Cable

Fig. D3-8 CPU1

ケーブル

CPU1 Cable

Fig. D3-9 CPU2

ケーブル

CPU2 Cable

1104-003

Fig. D3

UNIT-3

Fig. D3

ELEC2
