Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE Fig. D3-12 1 104-002 Fig. D3 UNIT -3 Fig. D3 ELEC2 SIGMA-G5SA SIGMA-G5SB SIGMA-G5SC SIGMA-G5SD BB2 23N201 15 TUBE WIRING 9 9 9 9 3.5-white 1091401300-652 BB6 23N20121 TUBE…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
B03 0914B33X CORD 1 1 1 1 14-black 1091401300-503
B04 9W310112 CORD 1 1 1 1 14-green/yellow 1091401300-504
B05 9W310113 CORD 1 1 1 1 18-black 1091401300-505
B06 9W310114 CORD 1 1 1 1 18-blue 1091401300-506
B07 0914B33Y CORD 1 1 1 1 20-black 1091401300-507
B08 0914B33Z CORD 1 1 1 1 20-blue 1091401300-508
B10 0914B33W CORD 1 1 1 1 26-blue 1091401300-510
B16 4J300049 CABLE JOINT TERMINAL 3 3 3 3 2Y-3.5S 1091401300-516
B17 4J300050 CABLE JOINT,TERMINAL 18 18 18 18 1.25Y-3.5 1091401300-517
B21 23K10147 CASE CONN 2 2 2 2 1091401300-521
B22 4J300139 CABLE JOINT TERMINAL 4 4 4 4 1091401300-522
B23 23K10002 CASE CONN 1 1 1 1 1091401300-523
B24 4J300002 CABLE JOINT,TERMINAL 2 2 2 2 1091401300-524
B25 23K10263 CASE_CONN 4 4 4 4 1091401300-525
B26 4J300193 CABLE JOINT TERMINAL 8 8 8 8 1091401300-526
B31 23K10300 CASE CONN 1 1 1 1 1091401300-531
B33 4J300125 CABLE JOINT TERMINAL 4 4 4 4 1091401300-533
B37 23K10149 CASE_CONN 3 3 3 3 1091401300-537
B38 4J300057 CABLE JOINT_TERMINAL 6 6 6 6 1091401300-538
B46 0914B31H CORD(AE-POWER) 1 1 1 1 1091401300-546
B47 9W210342 CABLE 1 1 1 1 1091401300-547
B48 9W210343 CABLE 1 1 1 1 1091401300-548
B49 9W210386 CABLE 1 1 1 1 1091401300-549
B50 9W210387 CABLE 1 1 1 1 1091401300-550
B51 9W210388 CABLE 1 1 1 1 1091401300-551
B52 4W205275 CORD 1 1 1 1 1091401300-552
B53 4W205276 CORD 1 1 1 1 1091401300-553
B54 4W205288 CORD 2 2 2 2 1091401300-554
B60 9W210348 CABLE 1 1 1 1 1091401300-560
B61 9W210349 CABLE 1 1 1 1 1091401300-561
B64 9W210352 CABLE 1 1 1 1 1091401300-564
B65 9W210353 CABLE 1 1 1 1 1091401300-565
B70 4W205279 CORD 2 2 2 2 1091401300-570
B71 9W210389 CABLE 1 1 1 1 1091401300-571
B72 9W210390 CABLE 1 1 1 1 1091401300-572
B73 9W210391 CABLE 1 1 1 1 1091401300-573
B74 9W210392 CABLE 1 1 1 1 1091401300-574
B75 4W205287 CORD 1 1 1 1 1091401300-575
B76 4W205285 CORD 1 1 1 1 1091401300-576
B77 0914B306 CORD(G01) 1 1 1 1 1091401300-577
B78 4W204747 CORD(24G3A) 1 1 1 1 1091401300-578
B79 4W204748 CORD(24G3B) 1 1 1 1 1091401300-579
BA5 0914B34N TUBE,WIRING 10 10 10 10 RBT-5080 1091401300-645
BA6 23N20103 TUBE_WIRING 25 25 25 25 RBT-3048 1091401300-646
BB1 23N20109 TUBE WIRING 4 4 4 4 4-white 1091401300-651
UNIT-3
Fig. D3
ELEC2
1104-004
Fig. D3
Fig. D3-12
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. D3-12
1104-002
Fig. D3
UNIT-3
Fig. D3
ELEC2
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
BB2 23N20115 TUBE WIRING 9 9 9 9 3.5-white 1091401300-652
BB6 23N20121 TUBE WIRING 2 2 2 2 1091401300-656
BB7 23N20122 TUBE WIRING 1 1 1 1 1091401300-657
BB8 23N20123 TUBE WIRING 1 1 1 1 1091401300-658
BB9 23N20124 TUBE WIRING 1 1 1 1 1091401300-659
BC6 4J310004 CABLE JOINT_SLEEVE 4 4 4 4 1091401300-666
BC7 0914B311 CORD 1 1 1 1 1091401300-667
