Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 101 21 1FE945 BRACKET 2 2 2 2 1091403A04-001 102 23G10001 SENSOR_PHOTO 2 2 2 2 1091403A04-002 105 21 1G6416 BLOCK 4 4 4 4 1091403A04-005 106 216C1038 ROD 4 4 4 4 1091403A0…
Fig. E1
1104-003
Fig. E1-2
170
157
159
167
168
169
116
106
105
101
105
106
121
107
117
185
186
118
112
113
156
147
155
145
160
183
142
153
154
148
165
142
150
157
159
171
157
159
172
173
187
174
142
153
154
162
151
152
162
151
152
157
150
159
147
155
156
142
153
154
102
101
147
155
156
120
112
118
117
102
See Fig E1-3
Key No.201,202
142
153
154
See Fig E1-1
Key No.19
See Fig E4
See Fig E2
See Fig E3
185
186
B2201
E191-194(2)
B61(2)
B2203
UNIT-4
Fig. E1
BEAM
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
101 211FE945 BRACKET 2 2 2 2 1091403A04-001
102 23G10001 SENSOR_PHOTO 2 2 2 2 1091403A04-002
105 211G6416 BLOCK 4 4 4 4 1091403A04-005
106 216C1038 ROD 4 4 4 4 1091403A04-006
107 0914DA0Q BRACKET 2 2 2 2 1091403A04-007
112 0914DA0W MOTOR_AC-SERVO 4 4 4 4 1091403A04-012
113 0914DA0X MOTOR_AC-SERVO 2 2 2 2 1091403A04-013
116 211FD946 BRACKET 2 2 2 2 1091403A04-016
117 0914DA11 COVER 4 4 4 4 1091403A04-017
118 211AD653 COVER 4 4 4 4 1091403A04-018
120 0914DA2U PLATE 2 2 2 2 1091403A04-020
121 0914DA2V PLATE 2 2 2 2 1091403A04-021
142 221AA016 ROHS:BOLT_HEX-SCT 38 38 38 38 M4L8 1091403A04-042
145 221AA020 ROHS:BOLT_HEX-SCT 8 8 8 8 M4L16 1091403A04-045
147 221AA031 ROHS:BOLT_HEX-SCT 16 16 16 16 M5L16 1091403A04-047
148 221AA047 ROHS:BOLT_HEX-SCT 176 176 176 176 M6L35 1091403A04-048
150 221AA058 ROHS:BOLT_HEX-SCT 8 8 8 8 M8L30 1091403A04-050
151 221HA203 WASHER 4 4 4 4 FWS3 1091403A04-051
152 221HA003 WASHER 4 4 4 4 SW3 1091403A04-052
153 221HA104 WASHER 16 16 16 16 FW4 1091403A04-053
154 221HA004 WASHER 16 16 16 16 SW4 1091403A04-054
155 221HA105 WASHER 16 16 16 16 FW5 1091403A04-055
156 221HA005 WASHER 16 16 16 16 SW5 1091403A04-056
157 221HA107 WASHER 24 24 24 24 FW8 1091403A04-057
159 221HA007 WASHER 24 24 24 24 SW8 1091403A04-059
160 221FA007 NUT_HEX 8 8 8 8 M4 1091403A04-060
162 221DA013 MACHINE SCREW 4 4 4 4 PAN M3L12 1091403A04-062
165 221DA208 MACHINE SCREW 12 12 12 12 TRS M4L8 1091403A04-065
167 221AA041 ROHS:BOLT_HEX-SCT 4 4 4 4 M6L10 1091403A04-067
168 221HA106 WASHER 4 4 4 4 FW6 1091403A04-068
169 221HA006 WASHER 4 4 4 4 SW6 1091403A04-069
170 221AA057 ROHS:BOLT_HEX-SCT 8 8 8 8 M8L25 1091403A04-070
171 221AA061 ROHS:BOLT_HEX-SCT 8 8 8 8 M8L45 1091403A04-071
172 221AA069 ROHS:BOLT_HEX-SCT 8 8 8 8 M10L35 1091403A04-072
173 221HA108 WASHER 8 8 8 8 FW10 1091403A04-073
174 221HA008 WASHER 8 8 8 8 SW10 1091403A04-074
183 221DA221 MACHINE SCREW 18 18 18 18 M5L8 1091403A04-083
185 0914DA0S GASKET_BRACKET 4 4 4 4 1091403A04-085
186 0913F20Y EMC_GASCKET_A 4 4 4 4 1091403A04-086
187 221AA043 ROHS:BOLT_HEX-SCT 4 4 4 4 M6L16 1091403A04-087
Fig. E1-2
Fig. E1
1104-004
UNIT-4
Fig. E1
BEAM
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
