P-310-004(1_2) - 第259页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 6 21 1G5956 BLOCK 2 2 2 2 109290400D-006 7 21 1G5957 BLOCK 2 2 2 2 109290400D-007 9 21 1AC878 COVER 2 2 2 2 109290400D-009 10 21 1AC879 COVER 2 2 2 2 109290400D-010 1 1 22…
Fig. E4-1
ギア
Gear
27
29
23
13
15
16
See Fig E4-2
Key No.101
See Fig E4-3
Key No.201
25
24
11
See Fig E4-3
Key No.201,204
13
15
16
27
12
See Fig E4-2
Key No.102
24
25
See Fig E4-4
Key No.302,305
29
23
13
9
7
26
26
15
16
13
15
16
6
10
32
31
32
33
34
34
33
0912-002
Fig. E4
位置決め部
POSITIONING UNIT
UNIT-4
Fig. E4
POSITION
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
6 211G5956 BLOCK 2 2 2 2 109290400D-006
7 211G5957 BLOCK 2 2 2 2
109290400D-007
9 211AC878 COVER 2 2 2 2
109290400D-009
10 211AC879 COVER 2 2 2 2
109290400D-010
11 223E0496 GEAR 2 2 2 2
109290400D-011
12 223E0497 GEAR 2 2 2 2
109290400D-012
13 221AA030 ROHS:BOLT_HEX-SCT 12 12 12 12
M5L12 109290400D-013
15 221HA005 WASHER 12 12 12 12
SW5 109290400D-015
16 221HA105 WASHER 12 12 12 12
FW5 109290400D-016
23 221AA015 ROHS:BOLT_HEX-SCT 8 8 8 8
M4L6 109290400D-023
24 211DE692 PLATE 4 4 4 4
109290400D-024
25 211DE693 PLATE 4 4 4 4
109290400D-025
26 222D0087 BEARING_RADIAL 4 4 4 4
109290400D-026
27 221AA055 ROHS:BOLT_HEX-SCT 8 8 8 8
M8L16 109290400D-027
29 221AA018 ROHS:BOLT_HEX-SCT 16 16 16 16
M4L12 109290400D-029
31 213A1569 SHAFT 4 4 4 4
3092904009-001
32 223E0498 GEAR 8 8 8 8
3092904009-002
33 221CA044 SETSCREW 8 8 8 8
SET M4L10 3092904009-003
34 221J0029 SPRINGPIN 8 8 8 8
3092904009-004
Fig. E4
1104-004
Fig. E4-1
UNIT-4
Fig. E4
POSITION
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
Fig. E4-2
センサ
Sensor
1104-003
Fig. E4
位置決め部
POSITIONING UNIT
See Fig E4-3
Key No.201
See Fig E4-4
Key No.302
110
1
11
112
110
11
1
112
110
111
112
106
107
107
110
111
112
110
111
112
103
104
103
105
104
101
106
110
111
112
110
111
112
107
107
109
108
109
108
110
111
112
110
111
112
107
103
102
106
110
111
112
109
108
109
108
105
110
111
112
107
104
110
111
112
109
108
109
108
105
B0521(F)
B0520(B)
B0521(F)
B0520(B)
B0515(F)
B0514(B)
B0515(F)
B0514(B)
B0515(F)
B0514(B)
B0515(F)
B0514(B)
UNIT-4
Fig. E4
POSITION
