P-310-004(1_2) - 第267页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 302 0929E00R BASE 2 2 2 2 109290400C-002 303 222L0694 GUIDE_LINEAR 2 2 2 2 109290400C-003 305 0929E01C BASE 2 2 2 2 109290400C-005 306 221AA020 ROHS:BOL T_HEX-SCT 32 32 32…
Fig. E4-4
フレームＲ
Frame R
306
316
324
322
306
306
315
327
302
317
303
321
320
305
319
323
326
325
311
329
328
312
313
314
329
371
355
356
371
355
356
362
363
361
366
355
356
370
369
364
318
364
371
355
356
365
367
368
359
365
367
368
358
360
309
372
373
334
340
313
314
353
313
314
354
339
341
340
345
331
343
332
343
344
333
346
352
348
349
350
352
330
336
374
354
312
375
316
357
347
349
350
B0613(F)
B0913(B)
B0614,0615(F)
B0914,0915(B)
B0611(F)
B0911(B)
Y0642(F)
Y0942(B)
1104-004
Fig. E4
位置決め部
POSITIONING UNIT
UNIT-4
Fig. E4
POSITION
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
302 0929E00R BASE 2 2 2 2 109290400C-002
303 222L0694 GUIDE_LINEAR 2 2 2 2
109290400C-003
305 0929E01C BASE 2 2 2 2
109290400C-005
306 221AA020 ROHS:BOLT_HEX-SCT 32 32 32 32
M4L16 109290400C-006
309 221AA030 ROHS:BOLT_HEX-SCT 4 4 4 4
M5L12 109290400C-009
311 09141D03 ASSY_SENSOR 1 1 1 1
front 109290400C-011
311 09141D01 ASSY_SENSOR 1 1 1 1
rear 1092904016-011
312 221FA011 NUT_HEX 4 4 4 4
M6 109290400C-012
313 221HA006 WASHER 6 6 6 6
SW6 109290400C-013
314 221HA106 WASHER 6 6 6 6
FW6 109290400C-014
315 216F0999 PIN_GUIDE 2 2 2 2
109290400C-015
316 221CA007 SETSCREW 4 4 4 4
SET M5L6 109290400C-016
317 213A1568 SHAFT 2 2 2 2
109290400C-017
318 09141D09 ASSY_SENSOR 1 1 1 1
front 109290400C-018
318 09141D08 ASSY_SENSOR 1 1 1 1
rear 1092904016-018
319 09141D05 ASSY_CYLINDER 1 1 1 1
front 109290400C-019
319 09141D04 ASSY_CYLINDER 1 1 1 1
rear 1092904016-019
320 221AA069 ROHS:BOLT_HEX-SCT 2 2 2 2
M10L35 109290400C-020
321 221HA008 WASHER 2 2 2 2
SW10 109290400C-021
322 221HA108 WASHER 2 2 2 2
FW10 109290400C-022
323 225F0558 PIPEFITTINGS 4 4 4 4
109290400C-023
324 221AA151 ROHS:BOLT_HEX-SCT 4 4 4 4
M8L12 109290400C-024
325 211DD872 PLATE 2 2 2 2
109290400C-025
326 211DD870 PLATE 2 2 2 2
109290400C-026
327 216B1382 HOLDER 2 2 2 2
109290400C-027
328 221DA011 MACHINESCREW 2 2 2 2
PAN M3L8 109290400C-028
329 221AA018 ROHS:BOLT_HEX-SCT 12 12 12 12
M4L12 109290400C-029
330 0929E00X LEVER 2 2 2 2
109290400C-030
331 0929E00W SHAFT 2 2 2 2
109290400C-031
332 0929E00Y COLLAR 2 2 2 2
109290400C-032
333 0929E01D PLATE 2 2 2 2
109290400C-033
334 0929E00V BRACKET 2 2 2 2
109290400C-034
336 0929E01H TENSIONSPRING 2 2 2 2
109290400C-036
339 0929E01L PINCYLINDER 2 2 2 2
109290400C-039
340 225F0260 PIPEFITTINGS 4 4 4 4
109290400C-040
341 0929E01M DKNUCKLEJOINT 2 2 2 2
109290400C-041
343 222D0008 BEARING_RADIAL 4 4 4 4
109290400C-043
344 221K0079 RINGC15 2 2 2 2
RING C 15 109290400C-044
345 221KB001 RING E 2 2 2 2
109290400C-045
346 09294020 ASSY_SENSOR 1 1 1 1
front 109290400C-046
346 0929401Y ASSY_SENSOR 1 1 1 1
rear 109290400C-046
347 221DA003 MACHINESCREW 2 2 2 2
PAN M2L8 1092904016-047
348 221AA001 ROHS:BOLT_HEX-SCT 4 4 4 4
M2L6 109290400C-048
349 221HA001 WASHER 6 6 6 6
SW2 109290400C-049
350 221HA101 WASHER 6 6 6 6
FW2 109290400C-050
Fig. E4
1104-004
Fig. E4-4
UNIT-4
Fig. E4
POSITION
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. E4-4
1104-004
Fig. E4
352 221DA207 MACHINESCREW 8 8 8 8 TRS M4L6 109290400C-052
353 221AA043 ROHS:BOLT_HEX-SCT 2 2 2 2
M6L16 109290400C-053
354 221AA046 ROHS:BOLT_HEX-SCT 4 4 4 4
109290400C-054
355 221HA003 WASHER 16 16 16 16
SW3 109290400C-055
356 221HA103 WASHER 16 16 16 16
FW3 109290400C-056
357 0929E010 BLOCK 2 2 2 2
109290400C-057
358 0929E00P SW-BK-1 2 2 2 2
109290400C-058
359 0929E00Q SW-BK-2 2 2 2 2
109290400C-059
360 09294023 ASSY_DOOR_SW 1 1 1 1
front 109290400C-060
360 09294024 ASSY_DOOR_SW 1 1 1 1
rear 1092904016-060
361 09294022 ASSY_VALVE 1 1 1 1
front 109290400C-061
361 09294021 ASSY_VALVE 1 1 1 1
rear 1092904016-061
362 225F0467 PIPEFITTINGS 2 2 2 2
109290400C-062
363 225B0059 AIRLINEEQPT 4 4 4 4
109290400C-063
364 23G00207 SENSOR_PELEC 4 4 4 4
109290400C-064
365 221AA016 ROHS:BOLT_HEX-SCT 8 8 8 8
M4L8 109290400C-065
366 221AA006 ROHS:BOLT_HEX-SCT 4 4 4 4
M3L8 109290400C-066
367 221HA004 WASHER 8 8 8 8
SW4 109290400C-067
368 221HA104 WASHER 8 8 8 8
FW4 109290400C-068
369 0929401W ASSY_SENSOR 1 1 1 1
front 109290400C-069
369 0929401V ASSY_SENSOR 1 1 1 1
rear 1092904016-069
370 0929E02C SOL_BKT 2 2 2 2
109290400C-070
371 221DA010 MACHINESCREW 12 12 12 12
PAN M3L6 109290400C-071
372 221HA005 WASHER 4 4 4 4
SW5 109290400C-072
373 221HA105 WASHER 4 4 4 4
FW5 109290400C-073
374 211AA031 ROHS:BOLT_HEX-SCT 2 2 2 2
M5L16 109290400C-073
375 221FA009 NUT_HEX 4 4 4 4
M5 109290400C-074
UNIT-4
Fig. E4
POSITION
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
