P-310-004(1_2) - 第277页
Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 10 221AA030 ROHS:BOL T_HEX-SCT 5 5 5 5 M5L12 1091401B00-010 1 1 221HA005 W ASHER 5 5 5 5 SW5 1091401B00-01 1 12 221HA303 ROHS:W ASHER 2 2 2 2 BW5 1091401B00-012 13 221HA20…
Fig. E5-1
I/F
コネクタ
I/F Connector
1104-004
Fig. E5
電装部３
ELECTRICAL SECTION 3
65
52
53
57
58
59
60
10
12
11
61
62
63
64
54
55
71
77
74
78
79
75
76
73
10
11
13
35
22
23
28
29
30
10
11
12
31
32
33
24
27
45
46
48
43
44
47
41
49
10
13
11
34
25
25 or 55
X300
X1300F1
X1300B1
S111R
X1300B2
X1300C
X1300D1
X1300D2
X1300D3
X1811F
X1811R
X1811F
X1811R
X1300F2
X1300F3
X1300F1
X1300B1
X1300B2
S111F
S111F
S111B
X1300C
X1300D1
X1300D2
X1300D3
X1300F2
X1300F3
X300
X300
X140
X140
UNIT-4
Fig. E5
CONNECTOR
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
10 221AA030 ROHS:BOLT_HEX-SCT 5 5 5 5 M5L12 1091401B00-010
11 221HA005 WASHER 5 5 5 5 SW5 1091401B00-011
12 221HA303 ROHS:WASHER 2 2 2 2 BW5 1091401B00-012
13 221HA205 WASHER 3 3 3 3 1091401B00-013
22 211FE413 BRACKET 2 2 2 2 3091401G00-002
23 9W210506 CABLE 1 1 1 1 3091401G00-003
24 9W210505 CABLE 1 1 1 1 3091401G00-004
25 0914BG0E CORD 1 1 1 1 3091401G00-005
27 221DA053 MACHINE SCREW 2 2 2 2 PAN M4L16 SW+FW
3091401G00-007
28 221AA030 ROHS:BOLT_HEX-SCT 2 2 2 2 M5L12 3091401G00-008
29 221HA005 WASHER 2 2 2 2 SW5 3091401G00-009
30 221HA303 ROHS:WASHER 2 2 2 2 BW5 3091401G00-010
31 221DA002 MACHINE SCREW 4 4 4 4 PAN M2L6 3091401G00-011
32 221HA002 WASHER 4 4 4 4 SW2.5 3091401G00-012
33 221HA102 WASHER 4 4 4 4 FW2.5 3091401G00-013
34 221DA057 MACHINE SCREW 4 4 4 4 PAN M3L14 SW+FW
3091401G00-014
35 0914BG0D BRACKET 1 1 1 1 3091401G00-015
41 4S1B0032 SWITCH,BUTTON 1 1 1 1 3091401G00-021
43 9W310128 CORD 1 1 1 1 3091401G00-023
44 9W310129 CORD 3 3 3 3 3091401G00-024
45 23K10402 CASE,CONN 1 1 1 1 3091401G00-025
46 4J300175 CABLE JOINT,TERMINAL 4 4 4 4 3091401G00-026
47 23N20117 TUBE WIRING 4 4 4 4 3091401G00-027
48 23N20103 TUBE WIRING 1 1 1 1 3091401G00-028
49 23N30737 ACCESSORY,WIRING(M 1 1 1 1 3091401G00-029
52 211FE413 BRACKET 1 1 1 1 3091401G02-002
53 9W210506 CABLE 1 1 1 1 3091401G02-003
54 9W210505 CABLE 1 1 1 1 3091401G02-004
55 0914BG0E CORD 1 1 1 1 3091401G02-005
57 221DA053 MACHINE SCREW 2 2 2 2 M4L6 SW+FW 3091401G02-007
58 221AA030 ROHS:BOLT_HEX-SCT 1 1 1 1 M5L12 3091401G02-008
59 221HA005 WASHER 1 1 1 1 SW5 3091401G02-009
60 221HA303 ROHS:WASHER 1 1 1 1 BW5 3091401G02-010
61 221DA002 MACHINE SCREW 4 4 4 4 PAN M2L6 3091401G02-011
62 221HA002 WASHER 4 4 4 4 SW2.5 3091401G02-012
63 221HA102 WASHER 4 4 4 4 FW2.5 3091401G02-013
64 221DA057 MACHINE SCREW 4 4 4 4 PAN M3L14 SW+FW
3091401G02-014
65 0914BG0B BRACKET 1 1 1 1 3091401G02-015
71 4S1B0032 SWITCH,BUTTON 1 1 1 1 3091401G02-021
73 9W310128 CORD 1 1 1 1 3091401G02-023
74 9W310129 CORD 3 3 3 3 3091401G02-024
75 23K10402 CASE,CONN 1 1 1 1 3091401G02-025
Fig. E5
1104-004
Fig. E5-1
UNIT-4
Fig. E5
CONNECTOR
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
Fig. E5-1
1007-003
Fig. E5
UNIT-4
Fig. E5
CONNECTOR
79 23N30737 ACCESSORY,WIRING(M 1 1 1 1 3091401G02-029
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
