MEMO
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
101 0916D20J P_C_B_MOUNT 2 2 1 1 1091603M00-001
102 225F0656 PIPE FITTINGS 2 2 1 1 1091603M00-002
103 225F0566 PIPE FITTINGS 2 2 1 1 1091603M00-003
104 09163N00 ASSY_VALVE 2 2 1 1 1091603M00-004
105 225B0573 AIR LINE EQPT 2 2 1 1 1091603M00-005
106 0916DM17 BRACKET 2 2 1 1 1091603M00-006
107 0916DM18 BOX 2 2 1 1 1091603M00-007
108 221DA051 SEMS_PANHEADSCR 36 36 18 18 M3L6 1091603M00-008
109 221DA057 MACHINE_SCREW 8 8 4 4 PAN M3L14 SW+FW
1091603M00-009
110 221A0245 BOLT_HEX-SCT 4 4 2 2 M2L10 1091603M00-010
113 221AA021 ROHS_HEX-SCT 2 2 1 1 M4L20 1091603M00-013
114 221HA001 WASHER 4 4 2 2 SW2 1091603M00-014
116 221HA004 WASHER 2 2 1 1 SW4 1091603M00-016
117 221HA101 WASHER 4 4 2 2 FW2 1091603M00-017
119 221HA104 WASHER 2 2 1 1 FW4 1091603M00-019
120 221DA056 MACHINE SCREW 8 8 4 4 PAN M3L8 SW+FW 1091603M00-020
131 4W204782 CORD 2 2 1 1 1091603M00-101
132 4W204987 CORD 2 2 1 1 1091603M00-102
133 0916D50B CORD 2 2 1 1 1091603M00-103
134 4W204984 CORD 2 2 1 1 1091603M00-104
135 4W204985 CORD 2 2 1 1 1091603M00-105
136 4W204786 CORD 2 2 1 1 1091603M00-106
139 23N30632 WIRING 24 24 12 12 1091603M00-109
141 0916D209 ACCESSORY_WRING 50 50 25 25 1091603M00-111
142 0916D20D ACCESSORY_WRING 2 2 1 1 1091603M00-112
151 0916D20A TUBE D4 2 2 1 1 3091603J0C-001
152 0916D20Q TUBE D8 2 2 1 1 3091603J0C-002
1104-002
Fig. G1'-2
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
GS-HH150(DDH V6)
UNIT-6
Fig. G1'
HEAD
1'
Fig. G1'
高速ヘッド部
(DDH V6)
HIGH SPEED HEAD SECTION(DDH V6)
MEMO
Fig. G1'-3
ベース部
Base Section
1104-002
224
201
226
208
204
219
220
217
218
229
217
218
229
220
205
227
228
211
222
223
230
222
223
221
217
218
216
203
212
210
202
215
213
214
206
209
225
B3106
B3103
M32
GS-HH150(DDH V6)
UNIT-6
Fig. G1'
HEAD
1'
Fig. G1'
高速ヘッド部
(DDH V6)
HIGH SPEED HEAD SECTION(DDH V6)
