Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 5A8 221HA105 W ASHER 8 8 4 4 FW5 1091603K03-108 5B1 0916DK20 SHAFT 2 2 1 1 2091603K01-001 5B2 23K10341 CASE_CONN 2 2 1 1 2091603K01-002 5B3 23K10287 CASE_CONN 2 2 1 1 2091…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
501 0916DK2A MOTOR 2 2 1 1 1091603K03-001
504 225F0702 PIPE FITTINGS 2 2 1 1 1091603K03-004
507 221C0080 SET SCREW 2 2 1 1 1091603K03-007
508 225F0612 PIPE FITTINGS 2 2 1 1 1091603K03-008
510 0916DK1Z GUIDE_LINEAR 2 2 1 1 1091603K03-010
517 0916D30T SLIP RING 2 2 1 1 1091603K03-017
518 222D0425 BEARING_RADIAL 2 2 1 1 1091603K03-018
519 222D0426 BEARING_RADIAL 2 2 1 1 1091603K03-019
520 222D0430 BEARING_RADIAL 4 4 2 2 1091603K03-020
522 226A0293 SEAL 4 4 2 2 1091603K03-022
523 226A0190 SEAL 4 4 2 2 1091603K03-023
524 09163N06 ASSY_SENSOR 2 2 1 1 1091603K03-024
535 0916DK21 ROD 2 2 1 1 1091603K03-035
536 0916DK2J BLOCK 2 2 1 1 1091603K03-036
537 0916DK22 BLOCK 2 2 1 1 1091603K03-037
546 211FD778 BRACKET 2 2 1 1 1091603K03-046
548 0916D333 COUPLING 2 2 1 1 1091603K03-048
549 211E1034 SPACER 4 4 2 2 1091603K03-049
551 225F0427 PIPE_FITTINGS 2 2 1 1 1091603K03-051
556 221G0206 NUT 2 2 1 1 1091603K03-056
557 0916DK2E HOLDER 2 2 1 1 1091603K03-057
558 222D0435 BEARING RADIAL 2 2 1 1 1091603K03-058
559 0916DK27 COLLAR 2 2 1 1 1091603K03-059
560 0916DK28 ROD 2 2 1 1 1091603K03-060
561 0916DK2F SPRING_COMP 2 2 1 1 1091603K03-061
562 221K0095 RING_E_2 2 2 1 1 RING E 2 1091603K03-062
563 216A1582 COLLAR 4 4 2 2 1091603K03-063
564 222D0439 BEARING_RADIAL 2 2 1 1 1091603K03-064
567 221H0266 WASHER 2 2 1 1 1091603K03-067
568 211AC769 COVER 2 2 1 1 1091603K03-068
569 211DE191 PLATE 4 4 2 2 1091603K03-069
575 221AA333 ROHS_HEX-SCT 6 6 3 3 M1.6L6 1091603K03-075
577 221AA001 ROHS_HEX-SCT 6 6 3 3 M2L6 1091603K03-077
582 221AA005 ROHS_HEX-SCT 4 4 2 2 M3L6 1091603K03-082
583 221AA006 ROHS_HEX-SCT 14 14 7 7 M3L8 1091603K03-083
584 221AA007 ROHS_HEX-SCT 16 16 8 8 M3L10 1091603K03-084
587 221AA031 ROHS_HEX-SCT 8 8 4 4 M5L16 1091603K03-087
589 221DA003 MACHINE SCREW 4 4 2 2 PAN M2L8 1091603K03-089
591 221CA026 SET SCREW 4 4 2 2 SET M3L3 1091603K03-091
597 221HA001 WASHER 16 16 8 8 SW2 1091603K03-097
598 221HA101 WASHER 16 16 8 8 FW2 1091603K03-098
5A2 221HA003 WASHER 34 34 17 17 SW3 1091603K03-102
5A3 221HA103 WASHER 26 26 13 13 FW3 1091603K03-103
5A5 221AA115 BOLT_HEX-SCT 12 12 6 6 M2L8 1091603K03-105
5A7 221HA005 WASHER 8 8 4 4 SW5 1091603K03-107
1104-002
Fig. G1'-6
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
GS-HH150(DDH V6)
UNIT-6
Fig. G1'
HEAD
1'
Fig. G1'
高速ヘッド部
(DDH V6)
HIGH SPEED HEAD SECTION(DDH V6)
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
5A8 221HA105 WASHER 8 8 4 4 FW5 1091603K03-108
5B1 0916DK20 SHAFT 2 2 1 1 2091603K01-001
5B2 23K10341 CASE_CONN 2 2 1 1 2091603K01-002
5B3 23K10287 CASE_CONN 2 2 1 1 2091603K01-003
5B4 4J300048 CAB_JOINTSLEEVE 22 22 11 11 2091603K01-004
5B5 23K10264 CASE_CONN 2 2 1 1 2091603K01-005
5B6 4J300047 CAB_JOINTSLEEVE 6 6 3 3 2091603K01-006
5B7 23K00012 CONTACT_PARTS_C 8 8 4 4 2091603K01-007
5B8 0916D305 CORD 2 2 1 1 2091603K01-008
5B9 0916D304 CORD 2 2 1 1 2091603K01-009
5C0 0916D303 CORD 2 2 1 1 2091603K01-010
5C1 0916D302 CORD 2 2 1 1 2091603K01-011
5C2 0916D30E CORD 2 2 1 1 2091603K01-012
5C3 0916D30F CORD 2 2 1 1 2091603K01-013
5C4 0916D30A CORD 2 2 1 1 2091603K01-014
5C5 0916D309 CORD 2 2 1 1 2091603K01-015
5C6 0916D308 CORD 2 2 1 1 2091603K01-016
5C7 0916DK2M BOARD 2 2 1 1 2091603K01-017
5C8 0916DK2N BOARD 2 2 1 1 2091603K01-018
5D0 23N20110 TUBE_WIRING 18 18 9 9 2091603K01-020
Fig. G1'
1104-002
Fig. G1'-6
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
GS-HH150(DDH V6)
UNIT-6
Fig. G1'
HEAD
1'
