Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 901 0948C107 BLOCK 1 1 1 1 1091702403-001 902 0948C106 BLOCK 1 1 1 1 1091702403-002 903 4M140178 MOT OR_STEPPING 2 2 2 2 1091702403-003 904 223Q0663 PULLEY_TIMING 4 4 4 4 …
Fig. H1-10
可動シュート１
Moved Chute 1
1104-003
Fig. H1
シングルコンベア部
SINGLE CONVEYOR SECTION
904
901
907
904
902
904
904
907
906
908
903
905
909
910
911
912
913
914
916
917
918
915
906
908
903
905
909
910
911
912
913
914
916
917
918
915
M45
M51
UNIT-7
Fig. H1
CONVEYOR
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
901 0948C107 BLOCK 1 1 1 1 1091702403-001
902 0948C106 BLOCK 1 1 1 1 1091702403-002
903 4M140178 MOTOR_STEPPING 2 2 2 2 1091702403-003
904 223Q0663 PULLEY_TIMING 4 4 4 4 1091702403-004
905 223Q0749 PULLEY_TIMING 2 2 2 2 1091702403-005
906 223M0059 PULLEY_FLAT 4 4 4 4 1091702403-006
907 223L0384 BELT_TIMING 2 2 2 2 1091702403-007
908 0948C419 BRACKET 2 2 2 2 1091702403-008
909 221FA009 NUT_HEX 4 4 4 4 M5 1091702403-009
910 221HA005 WASHER 4 4 4 4 SW5 1091702403-010
911 221HA105 WASHER 4 4 4 4 FW5 1091702403-011
912 221AA006 ROHS:BOLT_HEX-SCT 4 4 4 4 M3L8 1091702403-012
913 221HA003 WASHER 4 4 4 4 SW3 1091702403-013
914 221HA103 WASHER 4 4 4 4 FW3 1091702403-014
915 221CA005 SET SCREW 4 4 4 4 SET M4L6 1091702403-015
916 221AA017 ROHS:BOLT_HEX-SCT 4 4 4 4 M4L10 1091702403-016
917 221HA004 WASHER 4 4 4 4 SW4 1091702403-017
918 221HA104 WASHER 4 4 4 4 FW4 1091702403-018
Fig. H1
1104-004
Fig. H1-10
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
UNIT-7
Fig. H1
CONVEYOR
Fig. H1-11
可動シュート２
Moved Chute 2
1104-003
Fig. H1
シングルコンベア部
SINGLE CONVEYOR SECTION
A03
A10
A11
A09
A12
A08
A01
A02
A19
A19
A19
A21
A19
A19
A19
A20
A20
A20
A20
A20
A20
A02
A14
A16
A15
A18
A13
A18
A13
A18
A13
A18
A13
A07
A30
A30
A30
A30
A04
A29
A33
A32
A17
A31
A33
A34
A14
A34
A06
A05
A17
A31
A17
A31
B4701
B4801
UNIT-7
Fig. H1
CONVEYOR
