Fig. C1-6 クランプレバー Clump Lever 1 104-003 542 543 535 537 538 536 537 538 546 547 548 539 545 537 540 549 532 531 541 533 533 534 544 503 502 502 502 502 502 501 504 503 504 503 504 503 504 503 504 504 521 525 522 523 512 …
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
402 222M1468 SPRING_COMP 60 30 30 30 1092004109-002
407 216C1035 ROD 2 1 1 1
1092004109-007
410 0920E10R FEEDER_GUIDE_L 2 1 1 1
1092004109-010
411 0920E10S FEEDER_GUIDE_R 2 1 1 1
1092004109-011
412 211K3703 SUPPORT 2 1 1 1
1092004109-012
413 211K3704 SUPPORT 2 1 1 1
1092004109-013
414 211DE956 PLATE 4 2 2 2
1092004109-014
415 221DA010 MACHINE SCREW 4 2 2 2
PAN M3L6 1092004109-015
416 211AD669 COVER 2 1 1 1
1092004109-016
418 221AA031 ROHS:BOLT_HEX-SCT 8 4 4 4
M5L16 1092004109-018
419 221AA029 ROHS:BOLT_HEX-SCT 8 4 4 4
M5L10 1092004109-019
420 221AA030 ROHS:BOLT_HEX-SCT 12 6 6 6
M5L12 1092004109-020
421 221DA209 MACHINE SCREW 6 3 3 3
1092004109-021
422 221AA032 ROHS:BOLT_HEX-SCT 24 12 12 12
M5L20 1092004109-022
423 221CA044 SET SCREW 6 3 3 3
SET M4L10 1092004109-023
424 221AA036 ROHS:BOLT_HEX-SCT 12 6 6 6
M5L40 1092004109-024
425 221AA261 ROHS:BOLT_HEX-SCT 4 2 2 2
M5L55 1092004109-025
426 221AA057 ROHS:BOLT_HEX-SCT 8 4 4 4
M8L25 1092004109-026
427 221HA003 WASHER 4 2 2 2
SW3 1092004109-027
428 221HA103 WASHER 4 2 2 2
FW3 1092004109-028
431 221HA005 WASHER 44 22 22 22
SW5 1092004109-031
432 221HA105 WASHER 44 22 22 22
FW5 1092004109-032
433 221HA007 WASHER 8 4 4 4
SW8 1092004109-033
434 221HA103 WASHER 8 4 4 4
FW8 1092004109-034
436 213A1338 SHAFT 4 2 2 2
1092004109-036
437 226J2598 MECH PARTS 4 2 2 2
1092004109-037
438 211G6364 BLOCK 2 1 1 1
1092004109-038
439 211G6365 BLOCK 2 1 1 1
1092004109-039
440 221AA141 ROHS:BOLT,HEX-SCT 8 4 4 4
M6L10 1092004109-040
441 0920E112 BLOCK 2 1 1 1
1092004109-041
442 0920E113 BLOCK 2 1 1 1
1092004109-042
443 0920E111 SHAFT 4 2 2 2
1092004109-043
445 0920E10N BALL PLANGERS 4 2 2 2
1092004109-045
446 221FA016 ROHS:NUT,HEX 4 2 2 2
M10 1092004109-046
448 216C1034 ROD 2 1 1 1
1092004109-048
449 221DA107 MACHINE SCREW 8 4 4 4
FLT M3L8 1092004109-049
451 0920E10F BASE 2 1 1 1
2092004108-001
452 211G5359 BLOCK 12 6 6 6
2092004108-002
453 211DB811 PLATE 62 31 31 31
2092004108-003
454 221AA031 ROHS:BOLT_HEX-SCT 24 12 12 12
M5L16 2092004108-004
455 221HA005 WASHER 24 12 12 12
SW5 2092004108-005
456 221HA105 WASHER 24 12 12 12
FW5 2092004108-006
457 221AA007 ROHS:BOLT_HEX-SCT 186 93 93 93 M3L10 2092004108-007
Fig. C1
1104-004
Fig. C1-5
UNIT-2
Fig. C1
CART
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
Fig. C1-6
クランプレバー
Clump Lever
1104-003
542
543
535
537
538
536
537
538
546
547
548
539
545
537
540
549
532
531
541
533
533
534
544
503
502
502
502
502
502
501
504
503
504
503
504
503
504
503
504
504
521
525
522
523
512
511
514
513
See Fig C1-5
Key No.451
Y6913
B6910
B6914
09204101
0920410Q
09204103
09204102
Fig. C1
カート部
CART SECTION
UNIT-2
Fig. C1
CART
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
501 213A1024 SHAFT 2 1 1 1 3092004101-001
502 211DE170 PLATE 10 5 5 5
3092004101-002
503 211E1085 SPACER 20 10 10 10
3092004101-003
504 221K0079 RING C 15 20 10 10 10
RING C 15 3092004101-004
511 09204400 ASSY_CYLINDER 2 1 1 1
3092004102-001
512 0921A058 AIR LINE EQPT 4 2 2 2
3092004102-002
513 216C0713 ROD 2 1 1 1
3092004102-003
514 221FA014 NUT_HEX 2 1 1 1
M8 3092004102-004
521 09204401 ASSY_VALVE 2 1 1 1
3092004103-001
522 225F0467 PIPE FITTINGS 2 1 1 1
3092004103-002
523 225B0059 AIR LINE EQPT 4 2 2 2
3092004103-003
525 0920E114 TUBE D6 2 1 1 1
3092004103-005
531 213A1613 SHAFT 2 1 1 1
109200410Q-001
532 222Q0211 SPRING_FLAT 24 12 12 12
109200410Q-002
533 211E1181 SPACER 4 2 2 2
109200410Q-003
534 214A0065 BUSH_BEARING 6 3 3 3
109200410Q-004
535 221A0446 BOLT,HEX-SCT 24 12 12 12
BUTTAN M5L12 109200410Q-005
536 221AA033 ROHS:BOLT_HEX-SCT 2 1 1 1
M5L25 109200410Q-006
537 221HA005 WASHER 28 14 14 14
SW5 109200410Q-007
538 221HA105 WASHER 26 13 13 13
FW5 109200410Q-008
539 221FA008 NUT_HEX 2 1 1 1
M4 109200410Q-009
540 221FA010 NUT_HEX 2 1 1 1
M5 109200410Q-010
541 216S3266 LEVER 2 1 1 1
109200410Q-011
542 222H0132 CAM FOLLOWER 2 1 1 1
109200410Q-012
543 222N0157 SPRING_TENSION 2 1 1 1
109200410Q-013
544 211FE156 BRACKET 2 1 1 1
109200410Q-014
545 221AA021 ROHS:BOLT_HEX-SCT 2 1 1 1
M4L20 109200410Q-015
546 221AA017 ROHS:BOLT_HEX-SCT 4 2 2 2
M4L10 109200410Q-016
547 221HA004 WASHER 4 2 2 2
SW4 109200410Q-017
548 221HA104 WASHER 4 2 2 2
FW4 109200410Q-018
549 222A0168 BUSH,BEARING 6 3 3 3
109200410Q-019
Fig. C1
1104-004
Fig. C1-6
UNIT-2
Fig. C1
CART
SIGMA-G5SA
SIGMA-G5SB
SIGMA-G5SC
SIGMA-G5SD
