25.固定デバイス(MFタイプ)(DBUF)
25.Fixed device(MF type)(DBUF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DBUF3010 1 BASE ﾍﾞｰｽ FE
2 H5345A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M8X40L FE
3 W1014A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-8-H FE
4 DBUF3020 2 CLAMPER ｸﾗﾝﾊﾟ FE
5 H5321A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X12L FE
6 W1013A 6
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
7 DBUF3030 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
8 DBUF3040 1 BOX, DUST BOX ﾀﾞｽﾄ OT
9 DBUF3052 1 DUCT ﾀﾞｸﾄ FE
10 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
11 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
12 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
13 DBUF3061 1 DUCT ﾀﾞｸﾄ FE
14 DBUF4013 1 DUCT ﾀﾞｸﾄ FE
15 K5209A 2 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X8L FE
16 DBUF5011 1 DUCT ﾀﾞｸﾄ FE
17 K5209A 2 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X8L FE
18 IPA5411 24 CLAMPER ｸﾗﾝﾊﾟ FE
19 IPA5421 24 BOLT ﾎﾞﾙﾄ FE
20 IPA5430 24 SPRING ｽﾌﾟﾘﾝｸﾞ FE
21 IPA5460 24 PIN ﾋﾟﾝ FE
22 S2171B 1
JOINT, ONE-TOUCH
ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-01(NYﾒｯｷ） OT
23 S5021M 24
SOCKET
ｿｹｯﾄ SMK-015 OT
24 DBUF3070 1 COVER, BLIND 蓋 ﾒｸﾗ FE
25 K5216A 2 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M6X10L FE .
QP-341E-MM PARTS LIST
25 - 2
25.固定デバイス(MFタイプ)(DBUF)
25.Fixed device(MF type)(DBUF)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
39
37
9
11
6
7
88
6
7
68
54
Option
38
107
108
2
3
5
4
69
84
83
84
80
85
66
70
71
46
5
4
13
35
34
31
31
49
50
69
70
71
64
63
40
40
10
8
E
30
104
12
81
81
62
14
79
79
61
97
61
97
67
67
D
D
57
58
59
76
76
76
48
53
53
7
68
52
51
7
45
44
82
82
C
C
B
A
B
A
56
77
75
73
74
72
56
78
106
33
33
1
86
94
残テ−プカッタ（オプション）
Waste tape cutter(Option)
F
E
20
21
F
Waste tape cutter
(Option)
残テ−プカッタ（オプション）
43
95
47
42
24
41
92
93
105
Waste tape cutter(Option)
残テ−プカッタ（オプション）
22
残テ−プカッタ（オプション）
Waste tape cutter(Option)
19
29
89
87
90
89
91
90
28
98
65
93
92
27
65
91
60
26
Waste tape cutter(STU1)(Option)
残テ−プカッタ（ＳＴＵ１）（オプション）
Waste tape cutter(Option)
残テ−プカッタ（オプション）
32
25
23
55
15
H
H
99
100
102
103
96
101
16
17
17
16
G
G
G
X10
109
101
26 - 1
26.1.MFU-6E(DBUN)
26.1.MFU-6E(DBUN)
QP-341E -MM PARTS LIST
26.1.MFU-6E(DBUN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DBUN0052 1 BASE ﾍﾞｰｽ FE
2 H5334T 4 BOLT, HEX ﾎﾞﾙﾄ 六角 M6X75L FE
3 W1013A 4
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
4 H5300A 2 BOLT, HEX ﾎﾞﾙﾄ 六角 M5X15L FE
5 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
6 N4038A 2 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M5X10L FE
7 N4045A 4 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M6X5L FE
8 DBUN0070 1 COVER, FRONT ｶﾊﾞｰ ﾌﾛﾝﾄ FE
9 K5171L 4
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M4X６L FE
10 DBUN0080 1 PLATE, BLIND ﾌﾟﾚｰﾄ 盲 FE
11 K5171L 2
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M4X６L FE
12 DBUN0090 1 COVER, CONNECTOR ｶﾊﾞｰ ｺﾈｸﾀ FE
13 K51721 2
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M3X5L FE
14 DBUN0110 1 BASE ﾍﾞｰｽ FE
15 H5322A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M10X100 10.9ｾﾞﾝﾈｼﾞ FE
16 W1026A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
17 N1092A 4
NUT, HEX
ﾅｯﾄ 六角 M10 FE
19 DBUN1021 1 DUCT ﾀﾞｸﾄ FE
20 H5287A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
21 W1022A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
22 DBUN1033 1 DUCT ﾀﾞｸﾄ FE
23 K5172Z 2
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M6X10L FE
24 DBUN1050 1 NAMEPLATE, SOL 銘板 SOL PL
25 DBUN1061 1 DUCT ﾀﾞｸﾄ Option FE
26 ADBUN8100 1 DOOR 扉 OT
27 DBUN2010 1 DOOR 扉 PL
28 BHUF0800 1 NAMEPLATE, CAUTION 銘板 注意 Japanese/English PL
29 WWM0210 1 SEAL ｼｰﾙ PL
30 DBUN2030 1 GUIDE, TAPE ｶﾞｲﾄﾞ ﾃｰﾌﾟ FE
31 K5172Z 2
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M6X10L FE
32 K5208A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
33 DBUF3020 2 CLAMPER ｸﾗﾝﾊﾟ FE
34 H5321A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X12L FE
35 W1013A 6
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
37 DBVH0010 3 STAND ｽﾀﾝﾄﾞ FE
38 K5255T 3
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L FE
39 W1021A 3
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
40 N1085A 6
NUT, HEX
ﾅｯﾄ 六角 M6 P=1.0 FE
41 DBVH0180 1 VALVE, SOL ﾊﾞﾙﾌﾞ SOL OT
42 H5263A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X18L FE
43 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
QP-341E-MM PARTS LIST
26 - 2 26.1.MFU-6E(DBUN)
