26.1.MFU-6E(DBUN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
44 DBVH0290 1 PACKING, RUBBER ﾊﾟｯｷﾝ ｺﾞﾑ PL
45 DBVH0300 1 PLATE ﾌﾟﾚｰﾄ FE
46 K5257A 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X8L FE
47 DBVH0330 1 NAMEPLATE, CAUTION 銘板 注意 Japanese/English PL
48 DBVH0340 1 COVER, BLIND 蓋盲 FE
49 H5274A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6L FE
50 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
51 DBVH0360 1 PIN, LOCATING ﾋﾟﾝ 位置決め FE
52 DBVH0370 1 PIN, LOCATING ﾋﾟﾝ 位置決め FE
53 DBVH0380 2 STOPPER ｽﾄｯﾊﾟ PL
54 DBVH0430 1 BKT, RETAINER BKT 押え Option(100V/200V用) FE
55 DBWM1410 1 SEAL ｼｰﾙ PL
56 DBWM1220 2 SEAL ｼｰﾙ PL
57 BHUF0590 1 PUMP ﾎﾟﾝﾌﾟ OT
58 H5298A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X10L FE
59 W1023A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
60 BHUF0640 1 PLATE ﾌﾟﾚｰﾄ FE
61 BHUF0650 2 NAMEPLATE, CAUTION 銘板 注意 Japanese/English PL
62 BHUF0720 1 BKT BKT FE
63 H5298A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X10L FE
64 W1023A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
65 BHUF0810 2 NUT ﾅｯﾄ FE
66 BHUF6170 1 HOSE, HYDRAULIC ﾎｰｽ 油圧 FE
67 KPA0890 2 SEAL ｼｰﾙ PL
68 KPA2240 2 COLLAR ｶﾗｰ FE
69 H5289A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12L FE
70 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
71 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
72 IPA5411 24 CLAMPER ｸﾗﾝﾊﾟ FE
73 IPA5421 24 BOLT ﾎﾞﾙﾄ FE
74 IPA5430 24 SPRING ｽﾌﾟﾘﾝｸﾞ FE
75 IPA5460 24 PIN ﾋﾟﾝ FE
76 K1089E 4
CAM FOLLOWER
ｶﾑﾌｫﾛｱ CF-SFU-10 OT
77 S5021M 24
SOCKET
ｿｹｯﾄ SMK-015 OT
78 S2171A 1
JOINT, ONE-TOUCH
ｼﾞｮｲﾝﾄ ﾜﾝﾀｯﾁ TL6-01 OT
79 H3085T 2
BUSHING, RUBBER
ﾌﾞｯｼｭ ｺﾞﾑ G-12 OT
80 H1051Z 1
VALVE, CHECK
ﾊﾞﾙﾌﾞ ﾁｪｯｸ HT-720-02 OT
81 W1089A 6 WASHER ﾜｯｼｬ WSSB20-6-3 FE
82 T50127 2
HANDLE
取手 0052-60ｸﾛ OT
83 A10208 1 ADAPTER ｱﾀﾞﾌﾟﾀ 1010-6-1/4 OT
84 A1022E 2 ADAPTER ｱﾀﾞﾌﾟﾀ 1034-6-1/4 OT
QP-341E-MM PARTS LIST
26 - 3 26.1.MFU-6E(DBUN)
26.1.MFU-6E(DBUN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
85 A1022C 1 ADAPTER ｱﾀﾞﾌﾟﾀ 1033-6-1/4 OT
86 Y3069H 1 UNION ﾕﾆｵﾝ KQ2R06-08 OT
87 H1018G 1
HANDLE
ﾊﾝﾄﾞﾙ THA-225-1 OT
88 Y3079A 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L06-02S OT
89 T2123E 2
HINGE
蝶番 TH-10R OT
90 K5357H 4
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X5L FE
91 K5358A 4
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X10L FE
92 N1076A 4
NUT, HEX
ﾅｯﾄ 六角 M3 P=0.5 FE
93 W1021A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
94 Y3081K 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2VD08-02S OT
95 DBVH0500 1 NAMEPLATE, CAUTION 銘板 注意 French/English PL
96 DBVH0510 1 SEAL ｼｰﾙ French/English PL
97 BHUF0830 2 NAMEPLATE, CAUTION 銘板 注意 French/Japanese PL
98 BHUF0840 1 NAMEPLATE, CAUTION 銘板 注意 French/Japanese PL
99 DBUN1070 1 COVER ｶﾊﾞｰ FE
100 K5208A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
101 DBVH0540 2 NAMEPLATE 銘板 PL
102 DBVH0410 1 SEAL ｼｰﾙ Japanese/English PL
103 DBVH0420 1 MANEPLATE 銘板 OT
104 Y3079A 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KQL06-02S OT
105 Y3071T 1 UNION ﾕﾆｵﾝ KQ2T08-06 OT
106 DBUF3030 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ AL
107 K51721 4
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M3X5L FE
108 K5215N 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X25L FE
109 DBVH0560 1 SEAL ｼｰﾙ PL .
QP-341E-MM PARTS LIST
26 - 4 26.1.MFU-6E(DBUN)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
x9
26
43
41
11
13
23
43
H=962mm
2
2
4
3
14
10
13
11
38
4
3
21
18
39
39
33
12
10
38
13
14
33
42
43
40
45
44
22
20
1
28
28
19
35
16
36
37
17
34
27
27
41
24
32
40
29
30
5
25
2
25
32
39
39
6
26
26
31
15
31
31
15
31
26
31
15
31
15
31
31
8
Waste tape cutter(Option)
残テ−プカッタ（オプション）
26 - 5
26.2.MFU-6E(DBUN)
26.2.MFU-6E(DBUN)
QP-341E -MM PARTS LIST
