27.MFU-6E NGパーツ排出コンベア(M)(オプション)(DBQN)
27.MFU-6E Parts eject conveyor(M)(Option)(DBQN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
42 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
43 BHQN0120 1 GEAR, MITER ｷﾞﾔ ﾏｲﾀ OT
44 N4027A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X5L FE
45 BHQN0130 1 GEAR, MITER ｷﾞﾔ ﾏｲﾀ OT
46 N4027A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X5L FE
47 BHQN0140 2 SPROCKET ｽﾌﾟﾛｹｯﾄ OT
48 K5261H 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X12L FE
49 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
50 N4027A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X5L FE
51 BHQN0150 2 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ FE
52 BHQN0180 1 ROLLER ﾛｰﾗ FE
53 H41152 4 BEARING ﾍﾞｱﾘﾝｸﾞ R-1980ZZ FE
54 T2005A 1
CHAIN
ﾁｪｰﾝ RS25NP36ﾘﾝｸﾂｷﾞﾃﾘﾝｸﾂｷ OT
55 S4045M 1 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX872A OT
56 K5184H 2 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M3X8L FE
57 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
58 M5046E 1 MOTOR, GEAR ﾓｰﾀ ｷﾞﾔ RB-54B2GM-FST2-24 1/40 OT
59 H5296E 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X50L FE
60 W1022A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
61 S1024A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-6 FE
62 H3005T 1 FIBER UNIT ﾌｧｲﾊﾞﾕﾆｯﾄ FU-35F OT
63 . 1 LENS UNIT ﾚﾝｽﾞﾕﾆｯﾄ F3HA OT
64 S3132A 1
SW, PHOTOELECTRIC
SW 光電 PS-56 OT
65 A1040H 1 AMPLIFIER ｱﾝﾌﾟ PS2-61 OT
66 H5273T 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X4L FE
67 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
68 A1039Z 1 AMPLIFIER ｱﾝﾌﾟ FS-V11 OT
69 H5274A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6L FE
70 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
71 N1076T 1 NUT, HEX ﾅｯﾄ 六角 M3 P=0.5 ｽﾃﾝﾚｽ FE
72 H5172Z 2 BOLT, HEX ﾎﾞﾙﾄ 六角 M4X30Lｾﾞﾝﾈｼﾞ FE
73 H4227E 2 BEARING ﾍﾞｱﾘﾝｸﾞ 688ZZ FE
74 K52631 2 BLOCK 駒 SEPN4 OT
75 H31332 1 PLUG ﾌﾟﾗｸﾞ TM-96-12 OT
76 BHQN0240 1 BKT, SENSOR BKT ｾﾝｻ FE
77 K5257E 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X10L FE
78 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
79 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE .
QP-341E-MM PARTS LIST
27 - 3
27.MFU-6E NGパーツ排出コンベア(M)(オプション)(DBQN)
27.MFU-6E Parts eject conveyor(M)(Option)(DBQN)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
43
72
73
41
39
38
3
B
C
36
52
49
23
22
21
51
48
33
59
62
61
63
58
65
2
1
37
40
45
42
4
14
44
66
17
18
15
16
7
7
13
12
12
19
A
31
20
47
32
B
6
45
26
29
28
27
71
55
50
35
45
57
60
56
46
8
30
45
34
5
11
6
24
34
53
64
56
54
67
70
69
68
10
9
A
C
X5
28 - 1
28.MFU-6E NGパーツ排出コンベア(L)(オプション)(DBQN)
28.MFU-6E Parts eject conveyor(L)(Option)(DBQN)
28.MFU-6E NGパーツ排出コンベア(L)(オプション)(DBQN)
28.MFU-6E Parts eject conveyor(L)(Option)(DBQN)
QP-341E -MM PARTS LIST
28.MFU-6E NGパーツ排出コンベア(L)(オプション)(DBQN)
28.MFU-6E Parts eject conveyor(L)(Option)(DBQN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DBQN0140 1 PLATE, RETAINING ﾌﾟﾚｰﾄ 押え FE
2 K52565 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X6L FE
3 DBQN2040 1 PLATE, GUIDE ﾌﾟﾚｰﾄ ｶﾞｲﾄﾞ FE
4 K5357M 3
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X6L FE
5 DBQN3010 1 FRAME ﾌﾚｰﾑ FE
6 K5255T 8
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M3X6L FE
7 K52565 4
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X6L FE
8 N4028A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X6L FE
9 DBQN3020 1 GUIDE, BELT ｶﾞｲﾄﾞ ﾍﾞﾙﾄ FE
10 DBQN3030 1 BELT ﾍﾞﾙﾄ OT
11 DBQN3041 1 COVER ｶﾊﾞｰ FE
12 K5208A 4
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
13 DBQN3051 1 COVER ｶﾊﾞｰ FE
14 K5208A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
15 DBQN3060 1 STOPPER, WORK ｽﾄｯﾊﾟ ﾜｰｸ FE
16 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
17 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
18 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
19 DBQN3070 1 BKT SW BKT SW FE
20 DBQN3080 1 BKT, MOTOR BKT ﾓｰﾀ FE
21 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
22 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
23 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
24 DBQN3090 1 ROLLER ﾛｰﾗ FE
26 BHQN0100 1 BKT, SENSOR BKT ｾﾝｻ FE
27 K5257E 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X10L FE
28 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
29 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
30 BHQN0140 1 SPROCKET ｽﾌﾟﾛｹｯﾄ OT
31 K5261H 1
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M5X12L FE
32 W1044A 1 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
33 N4027A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X5L FE
34 BHQN0150 2 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ FE
35 BHTA4030 1 SPROCKET ｽﾌﾟﾛｹｯﾄ OT
36 N4027A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X5L FE
37 BHTA4060 1 ROLLER ﾛｰﾗ FE
38 BHTA4070 1 SHAFT ｼｬﾌﾄ FE
39 BHQN0010 1 BLOCK, REFERENCE ﾌﾞﾛｯｸ 基準 FE
40 H5288A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
41 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
42 BHTB0590 1 BLOCK ﾌﾞﾛｯｸ FE
QP-341E-MM PARTS LIST
28 - 2
28.MFU-6E NGパーツ排出コンベア(L)(オプション)(DBQN)
28.MFU-6E Parts eject conveyor(L)(Option)(DBQN)
