32.残テープカッタ(固定デバイス)(オプション)(DBVC) 32.Waste tape cutter(Fixed device)(Option)(DBVC) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 1 DBVC0012 1 BKT BKT FE 2 H5359A 4 BO…
32 - 2
32.残テープカッタ(固定デバイス)(オプション)(DBVC)
32.Waste tape cutter(Fixed device)(Option)(DBVC)
32.残テープカッタ(固定デバイス)(オプション)(DBVC)
32.Waste tape cutter(Fixed device)(Option)(DBVC)
QP-341E -MM PARTS LIST
C
B
B
C
A
A
x7
LOCTITE262
LOCTITE262
ThreeBond1373B
ThreeBond1390E
ThreeBond1373B
ThreeBond1390E
1.96N･m
3.9N･m
64.7N･m
64.7N･m
32.4N･m
32.4N･m
32.4N･m
32.4N･m
32.残テープカッタ(固定デバイス)(オプション)(DBVC)
32.Waste tape cutter(Fixed device)(Option)(DBVC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DBVC0012 1 BKT BKT FE
2 H5359A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X20L FE
3 W1026A 4 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
4 DBVC0021 1 BKT BKT FE
5 H5342A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
6 W1014A 2 WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H FE
7 DBVC0031 1 CUTTER, STATIONARY ｶｯﾀ 固定 FE
8 H5391A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M12X40L FE
9 W1016A 2 WASHER, CONICAL ﾜｯｼｬ 皿 M-12-H FE
10 DBVC0041 1 PLATE ﾌﾟﾚｰﾄ FE
11 H5302A 22 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L FE
12 W1023A 22 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
13 DBVC0110 1 BLOCK ﾌﾞﾛｯｸ FE
14 N4021A 1 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X6L FE
15 H5263C 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X16L FE
16 W1012A 2 WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L FE
17 DBVC0121 1 BOLT ﾎﾞﾙﾄ FE
18 S1031A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW10 FE
19 DBVC0130 1 PIN, PIVOT ﾋﾟﾝ 支点 FE
20 N1096A 1 NUT, HEX ﾅｯﾄ 六角 M12 P=1.75 FE
21 W1027A 1 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M FE
22 DBVC0151 2 BLOCK ﾌﾞﾛｯｸ FE
23 H5342A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
24 W1014A 4 WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H FE
25 DBVC0161 2 BLOCK ﾌﾞﾛｯｸ FE
26 H5342A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
27 W1025A 4 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
28 DBVC0190 2 LEVER ﾚﾊﾞｰ FE
29 DBVC0201 2 BLOCK ﾌﾞﾛｯｸ FE
30 H5299A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L FE
31 W1012A 4 WASHER, CONICAL ﾜｯｼｬ 皿 M-5-L FE
32 DBVC0210 1 BAR ﾊﾞｰ FE
33 DBVC0220 2 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
34 H5263B 6 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X16L FE
35 W1011A 6 WASHER, CONICAL ﾜｯｼｬ 皿 M-4-L FE
36 DBVC0240 4 CUTTER, MOVABLE ｶｯﾀ 可動 FE
37 DBVC0250 1 CUTTER, MOVABLE ｶｯﾀ 可動 FE
38 DBVC0260 2 PLATE ﾌﾟﾚｰﾄ FE
39 H5304A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X25L FE
40 W1023A 4 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
41 W1044A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
QP-341E-MM PARTS LIST
32 - 3
32.残テープカッタ(固定デバイス)(オプション)(DBVC)
32.Waste tape cutter(Fixed device)(Option)(DBVC)
32.残テープカッタ(固定デバイス)(オプション)(DBVC)
32.Waste tape cutter(Fixed device)(Option)(DBVC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
42 DBVC0270 2 DAMPER ﾀﾞﾝﾊﾟ PL
43 DBVC0280 2 ROLLER ﾛｰﾗ FE
44 DBVC0290 2 COLLAR ｶﾗｰ FE
45 H5324A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X20L FE
46 W1013A 4 WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H FE
47 DBVC0300 2 PIN, PIVOT ﾋﾟﾝ 支点 FE
48 N4025A 2 SCREW, HEX SOCKET SET ﾈｼﾞ 六角穴止め M3X16L FE
49 DBVC0310 1 BKT BKT FE
50 H5342A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X25L FE
51 W1014A 2 WASHER, CONICAL ﾜｯｼｬ 皿 M-8-H FE
52 DBVC0320 1 PLSTE ﾌﾟﾚｰﾄ PL
53 K5255T 3 SCREW, HEX SOCKET 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X6L FE
54 CGUF2032 2 PIN, PIVOT ﾋﾟﾝ 支点 FE
56 N1096A 2 NUT, HEX ﾅｯﾄ 六角 M12 P=1.75 FE
57 W1027A 2 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M FE
58 WPU0130 1 WASHER ﾜｯｼｬ FE
59 H5321A 1 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X12L FE
60 W1024A 1 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
61 S2205A 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ MDUC40-150DM-A73HLS OT
62 S21593 1 JOINT ｼﾞｮｲﾝﾄ I-MU04 OT
63 K5348D 2 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS3001F-06 OT
64 Y3020F 2 UNION ﾕﾆｵﾝ TL6-01M OT
65 H4570A 2 BEARING, DRY ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ 54B-101606 FE
66 H4571A 2 BEARING, DRY ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ 54B-152115 FE
67 W1001W 4 WASHER ﾜｯｼｬ FTRC-1528 FE
68 K1091M 2 CAM FOLLOWER ｶﾑﾌｫﾛｱ CF6UUR-A OT
69 N1085A 2 NUT, HEX ﾅｯﾄ 六角 M6 P=1.0 FE
70 W1024A 2 WASHER, SPRING ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE .H119
QP-341E-MM PARTS LIST
32 - 4
32.残テープカッタ(固定デバイス)(オプション)(DBVC)
32.Waste tape cutter(Fixed device)(Option)(DBVC)
