34.MTU-9E TZ軸(DBTN)
34.MTU-9E TZ-axis(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
84 IPA5260 2 COLLAR ｶﾗｰ FE
85 IPB0420 1 COLLAR ｶﾗｰ FE
86 ABHTA2080 60 GUIDE, SIDE ｶﾞｲﾄﾞ ｻｲﾄﾞ OT
87 ABHTB1030 20 GUIDE, SIDE ｶﾞｲﾄﾞ ｻｲﾄﾞ OT
88 SAM6590 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT
89 H5300A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
90 W1012A 4
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-5-L FE
91 N4001W 1 SCREW ﾈｼﾞ M4X8 No.1型(ﾕﾘｱﾈｼﾞ) FE
92 H4567A 2
BEARING UNIT
ﾍﾞｱﾘﾝｸﾞﾕﾆｯﾄ WBK08-11-DB FE
93 H5276A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X10L FE
94 W1010A 8
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-3-L FE
95 H30712 2 BUSHING ﾌﾞｼｭ PL006X017KE OT
96 A10105 1 ADJUSTER ｱｼﾞｬｽﾀ AJST6-30 OT
97 H4116D 2
BEARING
ﾍﾞｱﾘﾝｸﾞ RF-2280ZZ FE
98 S1024A 1
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-6 FE
99 A10624 1 AMPLIFIER, SENSOR ｱﾝﾌﾟ ｾﾝｻ PS-T1 OT
100 A10627 3 AMPLIFIER, SENSOR ｱﾝﾌﾟ ｾﾝｻ PS-T2 OT
102 H4567H 1 BELT ﾍﾞﾙﾄ 1422-3GT-5 OT
103 H3001T 1 FIBER, UNIT ﾌｧｲﾊﾞ ﾕﾆｯﾄ E32-M21 2M OT
104 A1038D 1 AMPLIFIER ｱﾝﾌﾟ E3X-DA11-N 2M OT
105 N4016A 8
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M2X2L FE
106 H5299A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
107 W1023A 9
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
108 DBTN0340 1 GUIDE ｶﾞｲﾄﾞ FE
109 K5257A 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X8L FE
110 W1011A 2
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L FE
111 DBTN0360 1 GUIDE ｶﾞｲﾄﾞ FE
112 K5257A 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X8L FE
113 W1011A 2
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L FE
114 H5300A 3 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
115 DBTN0391 1 GUIDE ｶﾞｲﾄﾞ FE
116 K5257A 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X8L FE
117 W1011A 2
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L FE
118 DBTN0401 1 GUIDE ｶﾞｲﾄﾞ FE
119 K5257A 2
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M4X8L FE
120 W1011A 2
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L FE
121 DBTN0430 8 BKT, SENSOR BKT ｾﾝｻ FE
122 K5255T 16
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ   M3X6L FE
123 W1010A 16
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-3-L FE
124 H5324A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X20L FE
125 W1024A 3
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
QP-341E-MM PARTS LIST
34 - 4
34.MTU-9E TZ軸(DBTN)
34.MTU-9E TZ-axis(DBTN)
34.MTU-9E TZ軸(DBTN)
34.MTU-9E TZ-axis(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
126 W1013A 3 WASHER, CONICAL ﾜｯｼｬ 皿 M-6-H FE
127 DBTN0470 60 SHAFT, ECCENTRIC ｼｬﾌﾄ 偏心 FE
128 DBTN0450 70 ROLLER ﾛｰﾗ PL
129 W1004G 140 WASHER, FLAT ﾜｯｼｬ 平 LRB6-0.5 FE
130 H45836 70 BEARING, ROLLER ﾍﾞｱﾘﾝｸﾞ ﾛｰﾗ SSFY6-12ZZ FE
131 DBTN0440 2 SEAL ｼｰﾙ . PL
QP-341E-MM PARTS LIST
34 - 5
34.MTU-9E TZ軸(DBTN)
34.MTU-9E TZ-axis(DBTN)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
Antistatic
108
36
37
70
D
Option
41
41
121
119
118
120
104
103
49
29
25
26
87
92
95
97
96
84
85
93
94
91
82
83
100
99
99
98
90
88
86
89
27
28
104
41
39
40
38
1
115
122
41
41
41
104
41
41
1
46
107
106
105
114
113
124
81
123
45
101
103
102
125
78
109
79
80
110
111
112
6
5
117
7
8
3
42
43
10
11
126
71
71
74
73
72
74
73
72
75
77
76
75
77
76
8
7
30
31
32
126
4
C
D
B
A
A
7
8
X10
133
29
29
2
C
24
24
47
127
47
127
53
52
51
17
18
19
50
16
47
127
47
127
56
57
16
54
17
18
19
34
35
33
35
34
15
14
13
128
129
12
130
131
132
B
22
67
68
69
127
47
24
127
47
62
65
64
63
66
20
67
68
69
127
59
60
61
58
66
24
127
47
47
135
136
137
134
134
134
134
35 - 1
35.MTU-9E カバー(DBTN)
35.MTU-9E Cover(DBTN)
35.MTU-9E カバー(DBTN)
35.MTU-9E Cover(DBTN)
QP-341E -MM PARTS LIST
