36.MTU-9E リフタ(DBTN) 36.MTU-9E Lifter(DBTN) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 42 DBTN4120 1 BKT BKT FE 43 H5288A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X10L FE 44…
36.MTU-9E リフタ(DBTN)
36.MTU-9E Lifter(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DBTN1390 1 BKT BKT FE
2 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
3 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
4 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
5 H5211A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X12L FE
6 N1080A 2
NUT, HEX
ﾅｯﾄ 六角 M4 P=0.7 FE
7 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
8 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
9 DBTN1402 1 COVER ｶﾊﾞｰ FE
10 K5208A 3
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
11 DBTN1410 1 BKT, SUPPORT BKT 支え FE
12 H5299A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
13 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
14 W1044A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
15 K5215C 1
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X12L FE
16 N1082A 1
NUT, HEX
ﾅｯﾄ 六角 M5 P=0.8 FE
17 DBTN1420 1 COVER ｶﾊﾞｰ FE
18 K5203A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M3X6L FE
19 DBVH0010 3 STAND ｽﾀﾝﾄﾞ FE
20 N1085A 6
NUT, HEX
ﾅｯﾄ 六角 M6 P=1.0 FE
21 W1090A 6 WASHER ﾜｯｼｬ WSSB20-8-3 FE
22 H5131M 2 BOLT, STUD ﾎﾞﾙﾄ ｽﾀｯﾄﾞ SBD-03-20 OT
23 K5255T 2 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X6L FE
24 K5358H 3
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M3X15L FE
25 DBTN4090 1 COVER ｶﾊﾞｰ FE
26 H5321A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X12L FE
27 W1024A 4
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
28 DBTN4020 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
29 H5332T 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X55L FE
30 N1085A 1
NUT, HEX
ﾅｯﾄ 六角 M6 P=1.0 FE
31 N40256 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X3L FE
32 DBTN4030 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
33 H5332T 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X55L FE
34 N1085A 1
NUT, HEX
ﾅｯﾄ 六角 M6 P=1.0 FE
35 DBTN4100 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
36 DBTN4110 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ FE
37 DBTN4060 1 COVER, BELT ｶﾊﾞｰ ﾍﾞﾙﾄ FE
38 H5287A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
39 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
40 K5208A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
41 DBTN4071 1 BOX, DUST BOX ﾀﾞｽﾄ OT
QP-341E-MM PARTS LIST
36 - 2
36.MTU-9E リフタ(DBTN)
36.MTU-9E Lifter(DBTN)
36.MTU-9E リフタ(DBTN)
36.MTU-9E Lifter(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
42 DBTN4120 1 BKT BKT FE
43 H5288A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
44 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
45 DBVH0020 2 BKT, ROLLER BKT ﾛｰﾗ FE
46 H5322A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X15L H=900mm FE
47 H5333T 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X65L FE
48 W1024A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
49 DBVH0090 1 LEVER, LINK ﾚﾊﾞｰ ﾘﾝｸ FE
50 DBVH0100 2 LEVER, LINK ﾚﾊﾞｰ ﾘﾝｸ FE
51 DBVH0111 1 JACK ｼﾞｬｯｷ OT
52 DBVH0120 1 PIN ﾋﾟﾝ FE
53 DBVH0390 2 SPACER ｽﾍﾟｰｻ Option FE
54 DDUF0500 2 SPACER ｽﾍﾟｰｻ Option FE
55 DBVH0410 1 SEAL ｼｰﾙ English PL
56 DBVH0420 1 NAMEPLATE 銘板 OT
57 BHUF0650 2 NAMEPLATE, CAUTION 銘板 注意 English PL
58 KPA0890 2 SEAL ｼｰﾙ PL
59 K5203A 7
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M3X6L FE
60 K5208A 3
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
61 A10381 1 AMPLIFIER ｱﾝﾌﾟ AP-80A Option OT
62 DBVH0440 2 SPACER ｽﾍﾟｰｻ Option FE
63 S1038A 10
CIR-CLIP
ｻｰｸﾘｯﾌﾟ STW20 FE
64 W1091A 8 WASHER ﾜｯｼｬ WSSB40-20-3 FE
65 K20240 2 CASTER, UNIVERSAL ｷｬｽﾀ 自在 No.104WHB-P(9117) OT
66 H5359A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M8X15L H=900mm FE
67 H5369A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M10X70L FE
68 W1026A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
69 K2178A 2 CASTER ｷｬｽﾀ No.6HB-PA(B)ｼｬｼﾞｸﾂｷ OT
70 W1027A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M FE
71 N10731 2
NUT, HEX
ﾅｯﾄ 六角 M12 P=1.75(3種) FE
72 K5154T 1 CONNECTOR, FLOATING ｺﾈｸﾀ ﾌﾛｰﾃｨﾝｸﾞ TBS-6 OT
73 K5268C 1 BLOCK, CLAMP 駒 ｸﾗﾝﾌﾟ SEPN-4 OT
74 S4069A 1 SENSOR, AREA ｾﾝｻ ｴﾘｱ PJ-S12 OT
75 H5288A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
76 W1022A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
77 W1043A 8 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
78 K1181A 1 FIXTURE, FIXING 金具止め TL-55-1 OT
79 H5274A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6L FE
80 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
81 W1040A 2 WASHER, FLAT ﾜｯｼｬ 平 1W-3 FE
82 K5202A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M3X3L FE
QP-341E-MM PARTS LIST
36 - 3
36.MTU-9E リフタ(DBTN)
36.MTU-9E Lifter(DBTN)
36.MTU-9E リフタ(DBTN)
36.MTU-9E Lifter(DBTN)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
83 W1043A 2 WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
84 DBTN3410 1 NAMEPLATE, CAUTION 銘板 注意 Japanese/English PL
85 DBTN3450 1 NAMEPLATE, CAUTION 銘板 注意 English/French PL
86 H5326A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X25L FE
87 W1024A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
88 DDUF0480 2 SPACER ｽﾍﾟｰｻ Option FE
89 H5361A 8 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M10X30L FE
91 DBVH0460 2 SPACER ｽﾍﾟｰｻ Option FE
92 H5331A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X45L FE
93 W1024A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
94 DDUF0490 2 SPACER ｽﾍﾟｰｻ Option FE
95 H5365A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M10X50L FE
97 DBVH0480 2 SPACER ｽﾍﾟｰｻ Option FE
98 H5334T 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M6X75L FE
99 W1024A 8
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
100 DDUF0510 2 SPACER ｽﾍﾟｰｻ M10X80L Option FE
101 H5371A 8
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 FE
103 DBVH0510 1 SEAL ｼｰﾙ French PL
104 BHUF0830 2 NAMEPLATE, CAUTION 銘板 注意 French PL
105 S3237A 3 SPACER ｽﾍﾟｰｻ SB-04-60 OT
106 S3236A 7 SPACER ｽﾍﾟｰｻ SB-03-10 OT .
QP-341E-MM PARTS LIST
36 - 4
36.MTU-9E リフタ(DBTN)
