3.ヘッド,マークカメラ(DBPH)
3.Head,Mark camera(DBPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
175 DBPH1042 3 HOLDER, LIGHT ﾎﾙﾀﾞ ﾗｲﾄ OT
176 H5275A 12
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
177 W1021A 12
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
178 W1040A 12 WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7(1W-3) FE
179 W1021A 6
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
180 DBPH1050 6 PIN, LOCATING ﾋﾟﾝ ｲﾁｷﾞﾒ FE
181 W1040A 6 WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7(1W-3) FE
182 N1080A 1
NUT, HEX
ﾅｯﾄ 六角 M4 P=0.7 FE
183 DBPH1121 3 STOPPER ｽﾄｯﾊﾟ FE
184 H5275A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
185 W1021A 9
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
186 S3059R 2 SPACER ｽﾍﾟｰｻ 4SQ-10 OT
187 W1041A 2 WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
188 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
189 W1010A 2
WASHER, CONICAL
ﾜｯｼｬ 皿 M-3-L FE
190 DBPH1060 3 SPACER ｽﾍﾟｰｻ AL
191 H5264T 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M2X4L FE
192 H5494A 3 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ UNAH3-10 FE
193 W1020A 6
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
194 W1039A 6 WASHER, FLAT ﾜｯｼｬ 平 1W-2 FE
195 K5175L 6 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2X3L FE
196 W1039A 6 WASHER, FLAT ﾜｯｼｬ 平 1W-2 FE
197 DBPH0940 6 SHEET ｼｰﾄ OT
198 ADBPH8082 3 HOLDER ﾎﾙﾀﾞ OT
199 H5268T 9
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M2.5X6L FE
201 W1042A 6 WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
203 DBPH1021 2 BKT, SENSOR BKT ｾﾝｻ AL
204 H5275A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
205 W1010A 6
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-3-L FE
206 S40544 3 SENSOR, FIBER ｾﾝｻ ﾌｧｲﾊﾞ HPF-S241-B OT
207 K51843 6 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2X9L(0ﾊﾞﾝ1ｼｭ) FE
208 DBPH1030 3 BKT, SENSOR BKT ｾﾝｻ FE
209 H5273A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X5L FE
210 W1021A 6
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
211 A1042T 3
AMPLIFIER
ｱﾝﾌﾟ HPX-T1 OT
212 ADBPH8014 3 GEAR ｷﾞﾔ OT
213 DBPH0054 3 GEAR ｷﾞﾔ FE
214 DBPH0063 3 GEAR ｷﾞﾔ FE
215 K5175N 12 SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M2X3L FE
216 EEPE1040 3 BOARD 基板 OT
217 R1009A 8
LAMP
ﾗﾝﾌﾟ 7376AS25 OT
QP-341E-MM PARTS LIST
3 - 7
3.ヘッド、マークカメラ(DBPH)
3.Head, Mark camera(DBPH)
3.ヘッド,マークカメラ(DBPH)
3.Head,Mark camera(DBPH)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
218 K5178L 3
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋 M3X5L FE
219 W1021A 3
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
220 N4021A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M3X6L FE
221 DBPH0190 1 BKT, SUPPORT BKT 支え FE
222 DBPH0630 1 BKT, WIRING BKT 配線 FE
223 S3148H 1 SW, PHOTOELECTRIC SW 光電 HPA-P21 OT
224 DBPH0964 1 BKT, SUPPORT BKT 支え FE
225 DBPH0971 1 RETAINER, WIRING 押え 配線 FE
226 S3148F 1 SW, PHOTOELECTRIC SW 光電 HPA-P11 OT
227 K5178T 2
SCREW, C/R PAN
小ﾈｼﾞ 十穴鍋 M3X12L FE
228 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
229 H5287A 1
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X8L FE
230 H5288A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L FE
231 W1022A 3
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
232 K5170T 2
SCREW, C/R TRUSS
小ﾈｼﾞ 十穴ﾄﾗｽ M3X6L FE
251 DBPH1070 3 SPACER ｽﾍﾟｰｻ AL
252 H5264T 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M2X4L FE
253 W1020A 6
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2M/M FE
254 W1039A 6 WASHER, FLAT ﾜｯｼｬ 平 1W-2 FE
255 DBPH1080 3 STOPPER ｽﾄｯﾊﾟ FE
256 H5275A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
257 W1021A 6
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
258 DBPH1090 3 STOPPER ｽﾄｯﾊﾟ FE
259 H5274A 6
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6L FE
260 W1021A 6
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
261 DBPH1151 3 STOPPER ｽﾄｯﾊﾟ FE
262 DBPH1171 3 STOPPER ｽﾄｯﾊﾟ FE
263 DBPH1181 3 STOPPER ｽﾄｯﾊﾟ FE
264 DBPH1191 3 STOPPER ｽﾄｯﾊﾟ FE
265 DBPH1201 3 STOPPER ｽﾄｯﾊﾟ FE
266 DBPH1211 3 STOPPER ｽﾄｯﾊﾟ FE
267 DBPH1221 3 STOPPER ｽﾄｯﾊﾟ FE
268 DBPH1231 3 STOPPER ｽﾄｯﾊﾟ FE
269 DBPH0400 1 DOG ﾄﾞｯｸﾞ FE
271 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
272 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
273 W1040A 2 WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7(1W-3) FE .
QP-341E-MM PARTS LIST
3 - 8
3.ヘッド、マークカメラ(DBPH)
3.Head, Mark camera(DBPH)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
47
9
10
29
39
33
7
2
3
44
43
26
30
40
9
10
5
6
37
35
36
45
41
B
34
34
37
35
36
B
A
A
8
8
38
42
24
24
11
48
46
25
4
4
32
50
31
28
49
49
22
19
15
12
14
13
18
17
16
23
20
21
1
5
6
X6
