15.コンベア(DBPP)
15.Conveyor(DBPP)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
216 DBPP0670 1 BKT, ENCODER BKT ｴﾝｺｰﾀﾞ Auto conveyor width adjustment Option FE
217 H5300A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L Auto conveyor width adjustment Option FE
218 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M Auto conveyor width adjustment Option FE
219 W1050A 2 WASHER, FLAT ﾜｯｼｬ 平 1W-5 Auto conveyor width adjustment Option FE
220 DBPP0680 1 PULLEY ﾌﾟｰﾘ Auto conveyor width adjustment Option OT
221 N4026A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X4L Auto conveyor width adjustment Option FE
222 DBPP0690 1 PULLEY ﾌﾟｰﾘ Auto conveyor width adjustment Option OT
223 N4026A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X4L Auto conveyor width adjustment Option FE
224 DBPP0700 1 SPROCKET ｽﾌﾟﾛｹｯﾄ Auto conveyor width adjustment Option OT
225 N4026A 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X4L Auto conveyor width adjustment Option FE
226 N4028D 2
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M4X6L Auto conveyor width adjustment Option FE
227 DBPP0710 1 SHAFT ｼｬﾌﾄ Auto conveyor width adjustment Option FE
228 M50492 1 MOTOR, STEPPING ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ TS3653N2E5 Auto conveyor width adjustment Option OT
229 H5288A 4
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X10L Auto conveyor width adjustment Option FE
230 W1011A 4
WASHER, CONICAL
ﾜｯｼｬ 皿         
M-4-L Auto conveyor width adjustment Option FE
231 A4091T 1 ENCODER ｴﾝｺｰﾀﾞ NAR-H11M-AD(058-050-C01) Auto conveyor width adjustment Option OT
232 H5274A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X6L Auto conveyor width adjustment Option FE
233 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M Auto conveyor width adjustment Option FE
234 W1040A 2 WASHER, FLAT ﾜｯｼｬ 平 3M/MX0.5X7(1W-3) Auto conveyor width adjustment Option FE
235 N4021A 1
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め M3X6L Auto conveyor width adjustment Option FE
236 H4475N 1 BELT ﾍﾞﾙﾄ 195-3GT-9 Auto conveyor width adjustment Option OT
237 H4175H 1 BEARING ﾍﾞｱﾘﾝｸﾞ 6000ZZ Auto conveyor width adjustment Option FE
238 W10046 1 WASHER ﾜｯｼｬ MRSB 8-0.5 Auto conveyor width adjustment Option FE
239 H3051B 1 COVER 蓋 MG-5 OT
240 DBPP0570 1 BKT BKT FE
241 K5359E 2
SCREW, HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿 M4X8L FE
242 DBPP0580 1 BKT, SENSOR BKT ｾﾝｻ FE
243 H5289A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M4X12L FE
244 W1022A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
245 W1041A 2 WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
246 DBPP0590 1 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
247 H5299A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M5X12L FE
248 W1023A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
249 H5275A 2
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴 M3X8L FE
250 W1021A 2
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
251 DBAB0241 1 RAIL ﾚｰﾙ OT
252 K5209A 2
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X8L FE
253 DBPP0760 1 BKT, SENSOR BKT ｾﾝｻ FE
254 H5290A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
255 DBPP0770 1 BKT, SENSOR BKT ｾﾝｻ FE
256 H5290A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L FE
QP-341E-MM PARTS LIST
15 - 8
15.コンベア(DBPP)
15.Conveyor(DBPP)
15.コンベア(DBPP)
15.Conveyor(DBPP)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
257 DBPP0790 1 BKT BKT FE
258 K41505 1 FLEXIBLE, TRACK ｹｰﾌﾞﾙ ﾍﾞｱ TKP0130-10R20-19LINK OT
259 K5255H 4 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ 六角穴ﾎﾞﾀﾝ M3X5L FE
260 W1021A 4 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
261 W1040A 4 WASHER, FLAT ﾜｯｼｬ 平 1W-3 FE
262 S40585 1 SENSOR ｾﾝｻ E3T-ST11R 2M OT
263 DBPP0780 2 NUT ﾅｯﾄ FE
264 DBPP0740 1 BKT BKT FE
265 H5273A 2 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M3X5L FE
266 W1021A 2 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
267 DBPP0750 1 BKT, WIRING BKT ﾊｲｾﾝ FE
268 W1022A 2 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
269 W1022A 2 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE .
注1.これらのﾊﾟｰﾂは標準仕様時、取付けられるﾊﾟｰﾂです。コンベア自動幅替えオプションでは取付けられていません。
Note.1: These parts are installed only when the standard are used. They are not present in AUTO CONVEYOR WIDTH ADJUSTMENT OPTION installations.
QP-341E-MM PARTS LIST
15 - 9
15.コンベア(DBPP)
15.Conveyor(DBPP)
ﾀﾃx173.205
Ref.31-1
Ref.31-1
Ref.31-1
Ref.33-7
Vacuum back
up pins(Option)
Vacuum back
up pins(Option)
Vacuum back
up pins(Option)
x7.5
G
A
B
109
79
33
34
35
36
32
31
38
39
41
42
44
83
122
63
82
62
81
45
11
15
96
95
6
7
5
97
76
76
8
14
13
12
18
17
16
44
45
85
84
10
9
85
84
32
31
58
57
58
57
46
46
89
88
89
88
58
57
58
57
119
56
56
56
52
52
52
56
52
55
55
55
54
54
54
53
114
115
113
110
111
66
67
112
99
93
65
72
72
72
28
48
50
47
49
66
67
65
93
99
19
113
110
87
87
74
87
87
60
61
59
75
75
73
111
100
100
100
100
100
100
114
115
113
19
99
93
66
67
65
49
91
92
90
90
50
72
28
27
27
25
25
26
26
72
72
110
111
112
2
3
66
67
65
99
93
112
110
23
24
20
21
22
94
76
76
76
76
116
117
118
116
77
77
80
80
80
78
19
113
114
115
111
4
112
115
114
1
19
55
54
53
53
53
108
43
43
51
51
37
29
30
120
120
30
120
30
40
36
34
35
68
105
104
103
101
106
106
107
102
70
71
69
F
F
D
C
B
A
D
E
E
C
G
30
30
120
30
120
120
121
64
121
16 - 1
16.Board lifter(DBPP)
16.基板リフタ(DBPP)
16.Board lifter(DBPP)
16.基板リフタ(DBPP)
QP-341E -MM PARTS LIST
