Page 1-71 REGULAR MAINTENANCE 1 Check Every 1000 Hours (Once T wo Months) 1-6-3 Cleaning and Greasing the Cam Box 2 This unit has two cams which carry out tape feeding and adhesive tape (option) feeding. 1 . Remove upper…
Page 1-70
Check Every 1000 Hours (Once Two Months)
1-6-2 Cleaning and Greasing the Cam Box 1
This unit has two cams which carry out the nozzle extension and nozzle retraction.
Clean the cam follower, lever fulcrum,
spring and cam face, then apply
grease.
(Oil : VALIANT U2)
1.Cam follower
Grease cam follower through grease nipple.
2.Lever fulcrum
Grease lever fulcrum through the grease
nipple.
3.Spring
Directly apply grease to hook and joint.
4.Cam face
Directly apply grease to cam face.
Rear side
2.
4.
Rear side
1.
3.
4G3C-AD01
01DKC2AA
01DKC2AB
3Y3C-E-MMD01-A06-03
Page 1-71
REGULAR
MAINTENANCE
1
Check Every 1000 Hours (Once Two Months)
1-6-3 Cleaning and Greasing the Cam Box 2
This unit has two cams which carry out tape feeding and adhesive tape (option) feeding.
1. Remove upper 2 screws of 4 ones
fixing the cover.
2. Remove 2 lower screws, holding the
cover by hand.
3. Clean the lever fulcrum, spring, and
cam face, then apply grease.
(Oil : VALIANT U2)
1.Lever fulcrum
Grease lever fulcrum through grease nipple.
2.Spring
Directly apply grease to hook and joint.
3.Cam face
Directly apply grease to cam face.
∗ After finishing to grease, set the cover removed
at the procedure 2.
Upper screws
Rear side
1.
2.
3.
01DLC2AA
3Y3C-E-MMD01-A06-02
Lower screws
3Y3C-AI01
Page 1-72
Rear side
1.
3.
2.
4.
Check Every 1000 Hours (Once Two Months)
1-6-4 Cleaning and Greasing the Cam Box 3
This unit has three cams which drive the take-up, mount, and cutter.
Clean the cam follower, lever fulcrum,
spring and cam face, then apply
grease.
(Oil : VALIANT U2)
1.Cam follower
Grease cam follower through grease nipple.
2.Lever fulcrum
Grease lever fulcrum through grease nipple.
3.Spring
Directly apply grease to the hook and joint.
4.Cam face
Directly apply grease to cam face.
3Y3C-AI01
01DMC2AA
3Y3C-E-MMD01-A06-02
