Gantry system electrical system
Page 17 / 22 24.11.2021
Gantry system electrical system
Page 18 / 22 24.11.2021
Pos. Item no. Description Part marking
1 03009210-04 TRAILING CABLE ANALOGOUS 1P
2 03012225-02 MOUNT Y-POWER TRACK CHAIN
BOTTOM COMPL.
3 03012194-02 PRESSURE PLATE Y-POWER TRACK
CHAIN COMPL.
4 03012071-02 HOLDER Y-POWER TRACK CHAIN
COMPL.
5 03010360-02 PRESSURE PLATE POWER TRACK
CHAIN TOP
6 03010598-01 INTERMEDIATE PIECE
7 03003646-01 TRAILING CABLE ANALOG 1P
ELECTR.
03001721-01 TRAILING CABLE 1 1P: Y-MOTOR
8 00305458-01 BK-MOD421/2 CONNECTOR PLUG
34POLE
*
03001722-01 TRAILING CABLE 2 1P: Y-MOTOR
03001723-01 TRAILING CABLE 3 1P: Y-MOTOR
03001724-01 TRAILING CABLE 4 1P: X-MOTOR
03001725-01 TRAILING CABLE 5 1P: X-MOTOR
03001726-01 TRAILING CABLE 6 1P: S/Z2-MOTOR
03001727-02 TRAILING CABLE 7 1P:
Z1/DP1-MOTOR
03001728-02 TRAILING CABLE 8 1P:
DP1/DP2-MOTOR
03001729-01 TRAILING CABLE 9 ANALOG 1P:
CAMERAS
26 03011982-02 PROFILE QM 45 H 23, ANALOG 1P
27 03012081-01 7-FOLD TUBE
28 03012067-01 PRESSURE PLATE 7-FOLD TUBE 6/4
29 03011003-01 PROTECTION TAPE EXTERIOR,
ANALOG 1P
30 03011004-01 PROTECTION TAPE INTERIOR,
ANALOG 1P
31 03012468-01 PROTECTION TAPE COOLING TUBE,
ANALOG 1P
32 03005846-01 CLAMPING PLATE 6.0
34 03002241-02 MOUNT X-TRAILING UNIT
35 03002242-02 PRESSURE PLATE X-TRAILING UNIT
36 03006507-01 MOUNT X-TRAILING UNIT TOP
Gantry system electrical system
Page 19 / 22 24.11.2021
Pos. Item no. Description Part marking
37 03002082-01 PRESSURE PLATE 7-FOLD TUBE 6/4
38 03006509-01 PRESSURE PLATE X-TRAILING UNIT
TOP
39 03020955S01 COOLING HOSE W. MOUNTING CONSUMABLE
40 03016214-01 SUPPORT ROLLER
03005863-01 ADHESIVE TAPE CABLE TRAILING
41 03018027-01 CLAMPING PLATE 2.0
42 03018071-01 COOLING TUBE Y-MOTOR ANALOG
1P AND 2P U
43 03018114-01 COOLING TUBE, DISTRIBUTOR
CLAMPING
48 03003921-03 Y-TRAILING CABLE MOUNT, RIGHT
SIDE
49 03003919-06 CONSOLE RIGHT, WELDED PART
50 03003915-03 COVER Y-TRAILING CABLE TOP
51 03003977-04 Y-TRAILING CABLE, MOUNT,
INTERFACE BOARD
52 03012067-01 PRESSURE PLATE 7-FOLD TUBE 6/4
53 03005003-01 CLAMPING PLATE 10.0
54 03012368-03 CABLE DUCT
55 03014038-01 EDGE PROTECTION
03005863-01 ADHESIVE TAPE CABLE TRAILING
58 00369157-01 DISTANCE BOLT M3*25 I/A 6KT5.5
ST ZINC-C.
59 03013642-03 TRAILING CABLE ANALOGOUS 2P U
60 03012225-02 MOUNT Y-POWER TRACK CHAIN
BOTTOM COMPL.
61 03012194-02 PRESSURE PLATE Y-POWER TRACK
CHAIN COMPL.
62 03012071-02 HOLDER Y-POWER TRACK CHAIN
COMPL.
63 03010360-02 PRESSURE PLATE POWER TRACK
CHAIN TOP
64 03010598-01 INTERMEDIATE PIECE
65 03013610-01 TRAILING CABLE ANALOG 2P U
ELECTR.
03013612-01 TRAILING CABLE 2 2PU: Y-MOTOR
66 00305458-01 BK-MOD421/2 CONNECTOR PLUG
34POLE
*
