KMB-1606 4 / 5 Contents 7 Conveyor Section 7-10 Clamp Board 2 7-1 1 Extension 8 Camera Section 8-1 Multi Camera & Light Assy 8-2 Fiducial Camera 9 Blow Station Section 9-1 Blow Station (Fix) 10 T ape Cutter Section 1…
KMB-1606
3 / 5
Contents
6 Nozzle Section
6-1 Nozzle
6-2 Nozzle Changer (Holder) RS
6-3 Nozzle Changer (Stand) RS
6-4 Nozzle Changer (Holder) MU
6-5 Nozzle Changer (Stand) MU
6-6 Nozzle Changer (Base)
6-7 Dump Box (4-Beam)
7 Conveyor Section
7-1 Push-UP A / C 7-2 Push-UP B / D 7-3 Transport
7-4 Width Adjust-Guide / Motor
7-5 Base / Plate / Ball Screw
7-6 Sensor
7-7 Stay / Pin Sensor 7-8 Frame Assy 7-9 Clamp Board 1
KMB-1606
4 / 5
Contents
7 Conveyor Section
7-10 Clamp Board 2 7-11 Extension
8 Camera Section
8-1 Multi Camera & Light Assy
8-2 Fiducial Camera
9 Blow Station Section
9-1 Blow Station (Fix)
10 Tape Cutter Section
10-1 Main Cutter Assy 46-Fix
Cylinder / Valve
10-2 Main Cutter Assy 46-Fix
Cutter / Guide
10-3 FES Joint Assy / Upper Cover
10-4 Base / Side Block
10-5 RMV (Desorption) / Clamp
10-6 RMV (Desorption) / R Base
