Thank you for purchasing the i-pulse dispenser.
This manual functions as maintenance guide. Please be sure to read this manual before servicing the
machine.
After reading this manual, keep it at a fixed location so that it will be available at any time.
Features:
z This manual consists of four sections; Installation, Periodical Checks, Mechanical Section, and
Electrical Section.
z Index at the end of the manual makes topic finding quick and easy.
Style Conventions:
z Action: Shows steps to perform a certain task.
z Example: Shows an example.
z Note: Shows an important point that calls for attention.
z
)
Shows the reference page or manual.
[ ]: Tab titles and sub-titles in the MMI windows are enclosed in these brackets.
< >: Buttons in the MMI windows are enclosed in these brackets.
“ “: User entries for the MMI windows are enclosed in double quotations.
: Controls on the machine control panel are boxed.
z An especially important point is highlighted as shown below:
Do not use alcohol (e.g. isopropyl alcohol) for nozzle cleaning.
Using alcohol may harden the dispensing fluid in the nozzle.
2
z Dangerous operations are noted in two levels: Warning and Caution.
Warning:
Failing to comply with the action suggested in a “Warning” will lead to a fatal injury or a death. (A “fatal
injury” means an injury, a scald, an electric shock, or a bone fracture,
leading to a persisting aftereffect, also means one requiring a long-term hospital treatment as an inpatient or
an outpatient.) An example follows:
Example:
When performing teach entry in which driving axes are allowed to move, do not stick your
head, hands, or other parts of the body inside the machine. Serious injury can result. Also
make sure non-operators are a safe distance from the machine.
Caution:
Failing to comply with the action suggested in a “Caution” will lead to a serious injury or a machine
damage. (A “serious injury” means an injury, a scald, or an electric shock, not requiring a long-term
hospital treatment as a inpatient or an outpatient.) An example follows:
Example:
Before starting teach entry, make sure no foreign obstacles are left in the machine or tray
feeder. Otherwise, costly machine damage can occur.
Caution
Warning
