YS12P_12F_mpl_je - 第11页
42>38 26 25 37 24 10 9 9 10 8 8 23 34 40 5 43 31 4 29 37 1 38 38 40 30 12 15 48 48 47 31 2 35 45 47 6 6 7 44 13 13 20 7 1 1 15 32 32 39 47 48 44 16 36 41 28 33 46 48 47 31 2 35 45 28 17 18 21 33 46 22 43 19 49 39 29 2…
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rev Rank Level No. Part No. Part Name Q'ty Remarks Rev Rank Level
1 KHY-M1309-A1 COVER 9 ASSY. 1 /
38 90990-12J001 SCREW BIN.HEAD W/W 4 /
2 KHY-M1309-01 COVER 9-1 2 /
39 90990-46J001 BOLT,THIN HEAD 9 /
3 KHY-M130A-02 COVER 9-2 1 /
40
4 KHY-M1340-01 BRKT.1,COVER 9 1 /
41 KHY-M13D8-00 STKKER 1 /
5 KHY-M1341-01 BRKT.2,COVER 9 1 /
42 90990-12J002 SCREW BIN.HEAD W/W 4 /
6 KHY-M1343-01 BRKT.4, COVER 9 2 /
43 KHY-M1309-B2 COVER 9 ASSY. 1
/
7 KV7-M1349-00 PLATE 2,NUT 4 /
44 KHY-M130A-12 COVER 9-2 1 /
8 KV2-M1351-00 PLATE 2 NUT 2 /
45 KHY-M1340-12 BRKT.1,COVER 9 1
/
9 KH2-M1324-01 GRIP 2 /
46 KHY-M1341-12 BRKT.2,COVER 9 1
/
10 KM0-M1331-01 BRACKET GAS DAMPER 4 /
47
11 KGS-M1348-00
GAS SPRING 4 /
48
12 90990-31J006 BOLT,SHOULDER 8 /
49
13 KL0-M1373-01 BRACKET 1 SCHMEASAL 2 /
50
14 KL0-M1374-00 PLATE 1 SCHMESAL 2 /
51
15 KJJ-M1348-00 STOPPER 65 4 /
52
16 KGS-M1360-00 BOLT 8 /
53
17 90990-46J001 BOLT,THIN HEAD 14 54
18 90990-46J003 BOLT,THIN HEAD 6 55
19 91312-04006 BOLT HEX.SOCKET HEAD 4 M4X6 56
20 91312-04008 BOLT HEX.SOCKET HEAD 12 M4X8 57
21 91312-05014 BOLT HEX.SOCKET HEAD 4 M5X14 58
22 92902-04200 WASHER PLAIN 4 59
23 95302-04600 NUT HEXAGON 2 60
24 95302-06600 NUT HEXAGON 2 61
25 90K41-000420 LABEL,ALERT 1 /
62
26 90K41-000360 LABEL,ALERT 1 /
63
27
KKJ-M13D6-00 SEAL 1 (YS12F) 1 /
64
KKD-M13D6-00 SEAL 1 (YS12P) 1 /
65
28 KW7-M13D7-01 SEAL 2(YAMAHA) 1 /
66
29 KKJ-M1309-B0 COVER 9 ASSY 1 /
67
30 KKJ-M130A-00 COVER 9 1 /
68
31 KL3-M1348-10 GAS SPRING
2 /
69
32 95307-06600 NUT HEXAGON 2 /
70
33 KKJ-M1310-10 COVER REAR ASSY. 1 /
71
34 KKJ-M1316-10 COVER 16 1 /
72
35 KKJ-M131A-00 COVER 1A 1 /
73
36 KKJ-M1317-00 BRACKET,COVER 16 2 /
74
37 KKJ-M1318-00 BRACKET,COVER 16 1 /
75
KKD/KKJ-1204
2
2
Acryl Door
Cover
42>38
26
25
37
24
10
9
9
10
8
8
23
34
40
5
43
31
4
29
37
1
38
38
40
30
12
15
48
48
47
31
2
35
45
47
6
6
7
44
13
13
20
7
11
15
32
32
39
47
48
44
16
36
41
28
33
46
48
47
31
2
35
45
28
17
18
21
33
46
22
43
19
49
39
29
29
14
14
KKD/KKJ-1204
3
1
Feeder Holder (60)
Feeder Holder
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rev. Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1 KHY-M3401-01 PLATE,FEEDER 60 1 /
Í
39 91312-03018 BOLT HEX.SOCKET HEAD 16 M3X18
2 KHY-M3405-S0 STAND ;1/2 SET 1 /
Í
40 91312-03016 BOLT HEX.SOCKET HEAD 12 M3X16
3 /
Í
41 91312-03010 BOLT HEX.SOCKET HEAD 4 M3X10
4 KHY-M340C-01 PLATE,FRONT 2 /
Í
42 91312-03006 BOLT HEX.SOCKET HEAD 4 M3X6
5 KHY-M371R-00 RAIL GUIDE 12P 5 /
43 98702-03006 SCREW FLAT HEAD 90
6 KHY-M340F-00 BRACKET,BOARD 2 /
Í
44 98902-03006 SCREW BINDING HEAD 16
7 KHY-M4476-16 FDR.CTRL.BOARD ASSY 2 /
Í
45 92902-06200 WASHER PLAIN 4
8 KHY-M37E1-00 LIGHT GUIDE 4 /
Í
46 92902-08600 WASHER PLAIN 6
9 KHY-M37E1-10 LIGHT GUIDE,L 2 /
Í
47 $NK-3N NYLON CLIP 4 /
10 KHY-M37E1-20 LIGHT GUIDE,R 2 /
Í
48 90990-11J003 SCREW,PAN HEAD W/W 4
11 KHY-M340G-00 SHAFT GUIDE 2 /
Í
49 KHY-M6187-00 FAN MOTOR ASSY 4 /
Í
12 KHY-M340H-01 PLATE,INDICATOR 1 /
Í
50
13 KHY-M349J-40 LABEL,INDICATOR 1 1-30 /
51
14 KHY-M379L-00 LABEL,LED 2 /
52
15 KHY-M379K-01 LABEL,LED POSI. 2 /
53
16 KHY-M340J-00 PLATE,CONNECTOR 1 /
Í
54
17 KHY-M66TE-00 HNS,F.CTRL - FDR. 60 /
Í
55
18 KHY-M372M-00 SCREW,STAD 120 /
Í
56
19 KHY-M340K-03 BRACKET,MANIFOLD 1
/
Í
57
20 KHY-M372R-00 GUIDE,FEEDER UNDER 5 /
Í
58
21 KHY-M372P-00 SUPPORT,LEVER 60 /
Í
59
22 KHY-M372S-01 SPRING,SUPPORT 60 /
Í
60
23 KHY-M340N-01 COVER,BOARD 2 /
Í
61
24 90990-42J047 JOINT 2
/
Í
62
25 $UBD6-4 JOINT 1 /
Í
63
26 $USD8-6 JOINT 1 /
Í
64
27 65
28 KHY-M34J1-00 BLOCK,FEEDER POSI. 2 /
Í
66
29 KHY-M3430-10 LABEL,FEEDER 60-12P 1 1-60 /
67
30 99480-06020 PIN,PARALLEL 4 /
Í
68
31 99480-06012 PIN,PARALLEL 4 /
Í
69
32 99480-04012 PIN,PARALLEL 2 /
Í
70
33 91312-08020 BOLT HEX.SOCKET HEAD 6 M8X20 71
34 91312-06020 BOLT HEX.SOCKET HEAD 4 M6X20 72
35 91312-06018 BOLT HEX.SOCKET HEAD 4 M6X18 73
36 91312-06012 BOLT HEX.SOCKET HEAD 4 M6X16 74
37 91312-06012 BOLT HEX.SOCKET HEAD 18 M6X12 75
38 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8 76
KKD/KKJ-1204
3
1
Feeder Holder (60)
Feeder Holder
