Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rev. Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1 KJH-M3401-01 PLATE, FEEDER 12-24 1
/
Í
39 91312-03006 BOLT HEX. SOCKET HEAD 14
2 40 91312-03006 BOLT HEX. SOCKET HEAD 2
3 KKJ-M3405-S1 STAND ;1/2 SET 1
/
Í
41 91312-03016 BOLT HEX. SOCKET HEAD 6
4 42 91312-03018 BOLT HEX. SOCKET HEAD 14
5 KJH-M340F-02 BRACKET, 2,BOARD 1
/
Í
43 91312-04006 BOLT HEX. SOCKET HEAD 4
6 KJH-M340H-02 PLATE,INDICATOR 1
/
Í
44 91312-04008 BOLT HEX. SOCKET HEAD 10
7 KJH-M340J-00 PLATE, CONNECTOR 1 /
Í
45 KHY-M349J-40 LABEL,INDICATER 1 /
8 KJH-M340K-02 BRACKET,MANIFOLD 1
/
Í
46 91312-06012 BOLT HEX. SOCKET HEAD 9
9 47 KHY-M3430-00 LABEL,FEEDER 24-12P 1 /
10 KJH-M340N-02 COVER,BOARD 1
/
Í
48 91312-06018 BOLT HEX. SOCKET HEAD 4
11 49 91312-06020 BOLT HEX. SOCKET HEAD 12
12 50 91312-08030 BOLT HEX. SOCKET HEAD 6
13
90990-42J047 JOINT
2
/
Í
51 98702-03006 SCREW, FLAT HEAD 36
14
$UBD6-4
JOINT
1
/
Í
52 98902-03004 SCREW, BINDING HEAD 12
15
$USD8-6 JOINT
1
/
Í
53 98902-03006 SCREW, BINDING HEAD 6
16 54 92902-06200 WASHER, PLAIN 4
17 KHY-M34J1-00 BLOCK, FEEDER POSI. 2 /
Í
55 92902-04600 WASHER, PLAIN 4
18 KHY-M371A-01 PLATE, FRONT 1 /
Í
56 92902-08600 WASHER, PLAIN 6
19 KHY-M371B-00 SHAFT GUIDE 1 /
Í
57 91312-06016 BOLT HEX.SOCKET HEAD 4
20 KHY-M371R-00 RAIL GUIDE 12P 2 /
58 KJH-M340K-00 COVER,PLATE 1 1
21 KHY-M372M-00 SCREW, STAD 48 /
Í
59
22 KHY-M372P-00 SUPPORT, LEVER 24 /
Í
60
23 KHY-M372R-00 GUIDE,FEEDER UNDER 2 /
Í
61
24 KHY-M372S-01 SPRING, SUPPORT 24 /
Í
62
25 63
26 KHY-M379K-01 LABEL,LED POSI. 1 /
64
27 KHY-M379L-00 LABEL,LED 1 /
65
28 KHY-M37E1-00 LIGHT GUIDE 3 /
Í
66
29 KHY-M4476-06 FDR.CTRL.BOARD ASSY 1 /
Í
67
30 KHY-M6187-00 FAN MOTOR ASSY 2 /
Í
68
31 KHY-M66TE-00 HNS, F. CTRL - FDR. 24
/
Í
69
32 KV8-M3758-00 SEAL DUMP 1 /
70
33 KJJ-M3T0X-20 STAY L 1 /
Í
71
34 KJJ-M3T0X-30 STAY R 1 /
Í
72
35 99480-04012 PIN, PARALLEL 1 /
Í
73
36 KHY-M3T25-10 VALVE COVER 2 1
/
74
37 99480-06012 PIN, PARALLEL 3 /
Í
75
38 99480-06020 PIN, PARALLEL 4 /
Í
76
Rev. :It is the parts which a change was in in the past. Please be careful at the time of the parts ordering.
Rev.: 過去に変更が入った部品を示します。部品発注時は注意してください。
KKD/KKJ-1204
3
2
Feeder Holder (24)
Feeder Holder
7
8
8
8
8
4
20
23
22
1
3
2
20
23
22
19
19
9
10
20
23
19
19
19
32
27
32
24
22
20
23
10
12
11
12
17
18
12
12
14
13
13
16
21
21
15
32
27
28
31
30
29
26
25
32
28
31
33
30
6
6
5
35
34
KKD/KKJ-1204
3
3
Reel Holder
Feeder Holder
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rev. Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1 KHY-M3S00-00 REEL HOLDER 60 ASSY 1 /
39
2 KHY-M3R01-00 SIDE PLATE,R 1 /
40
3 KHY-M3R02-00 SIDE PLATE,L 1 /
41
4 KHY-M3S06-04 STOPPER PLATE 1
/
42
5 KHY-M3S0A-01 STAY,SHAFT 2
/
43
6 KHY-M3S07-01 TRIM 2 /
44
7 KHY-M3S08-00 UNDER COVER 1 /
45
8 KHY-M3S09-00 SHAFT,ROLLER 4 /
46
9 KHY-M3R10-02 REEL PUT 30 /
47
10 KHY-M3R14-01 COLLAR 2
φ30
/
48
11 KHY-M3R14-11 WASHER 32
φ21
/
49
12 KHY-M3R15-00 ROLLER 98 /
50
13 KHY-M3S15-00 ROLLER 2 2 /
51
14 KHY-M3R16-00 PARTITION 15 /
52
15 KHY-M3R22-00 GUIDE,PARTITION 7 /
53
16 KHY-M3S22-00 GUIDE 2,PARTITION 1 /
54
17 KHY-M3R23-00 COLLAR,PARTITION 29 /
55
18 KHY-M3S23-00 COLLAR 2,PARTITION 1 /
56
19 91312-06012 BOLT HEX.SOCKET HEAD 8 57
20 91312-04008 BOLT HEX.SOCKET HEAD 6 58
21 91312-03012 BOLT,HEX.SOCKET HEAD 16 59
22 91312-03005 BOLT HEX.SOCKET HEAD 12 60
23 92902-04200 WASHER PLAIN 6 61
24 92902-03200 WASHER PLAIN 8 62
25 KHY-M3S20-00 RH. FRAME ASSY 1 /
63
26 KHY-M3S20-S1 RH. FRAME SUB ASSY 1 /
64
27 KHY-M374C-00 CASTER 2 /
65
28 KM0-M3741-00 CASTER 63 2 /
66
29 KHY-M373C-10 CHAIN ASSY 1 /
67
30 90172-00J040 WASHER,EXTL.TOOTHED 17 68
31 91312-04008 BOLT HEX.SOCKET HEAD 17 69
32 91312-06008 BOLT HEX.SOCKET HEAD 16 70
33 92902-04200 WASHER PLAIN 16 71
34
91312-04008 BOLT HEX.SOCKET HEAD
4
72
35
92902-04600 WASHER PLAIN
4
73
36 74
37 75
38 76
Rev. :It is the parts which a change was in in the past. Please be careful at the time of the parts ordering.
Rev.: 過去に変更が入った部品を示します。部品発注時は注意してください。
