No. Part No. Part Name Q'ty Remarks Rev. Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1 KHY-M3S00-00 REEL HOLDER 60 ASSY 1 /
39
2 KHY-M3R01-00 SIDE PLATE,R 1 /
40
3 KHY-M3R02-00 SIDE PLATE,L 1 /
41
4 KHY-M3S06-04 STOPPER PLATE 1
/
42
5 KHY-M3S0A-01 STAY,SHAFT 2
/
43
6 KHY-M3S07-01 TRIM 2 /
44
7 KHY-M3S08-00 UNDER COVER 1 /
45
8 KHY-M3S09-00 SHAFT,ROLLER 4 /
46
9 KHY-M3R10-02 REEL PUT 30 /
47
10 KHY-M3R14-01 COLLAR 2
φ30
/
48
11 KHY-M3R14-11 WASHER 32
φ21
/
49
12 KHY-M3R15-00 ROLLER 98 /
50
13 KHY-M3S15-00 ROLLER 2 2 /
51
14 KHY-M3R16-00 PARTITION 15 /
52
15 KHY-M3R22-00 GUIDE,PARTITION 7 /
53
16 KHY-M3S22-00 GUIDE 2,PARTITION 1 /
54
17 KHY-M3R23-00 COLLAR,PARTITION 29 /
55
18 KHY-M3S23-00 COLLAR 2,PARTITION 1 /
56
19 91312-06012 BOLT HEX.SOCKET HEAD 8 57
20 91312-04008 BOLT HEX.SOCKET HEAD 6 58
21 91312-03012 BOLT,HEX.SOCKET HEAD 16 59
22 91312-03005 BOLT HEX.SOCKET HEAD 12 60
23 92902-04200 WASHER PLAIN 6 61
24 92902-03200 WASHER PLAIN 8 62
25 KHY-M3S20-00 RH. FRAME ASSY 1 /
63
26 KHY-M3S20-S1 RH. FRAME SUB ASSY 1 /
64
27 KHY-M374C-00 CASTER 2 /
65
28 KM0-M3741-00 CASTER 63 2 /
66
29 KHY-M373C-10 CHAIN ASSY 1 /
67
30 90172-00J040 WASHER,EXTL.TOOTHED 17 68
31 91312-04008 BOLT HEX.SOCKET HEAD 17 69
32 91312-06008 BOLT HEX.SOCKET HEAD 16 70
33 92902-04200 WASHER PLAIN 16 71
34
91312-04008 BOLT HEX.SOCKET HEAD
4
72
35
92902-04600 WASHER PLAIN
4
73
36 74
37 75
38 76
Rev. :It is the parts which a change was in in the past. Please be careful at the time of the parts ordering.
Rev.: 過去に変更が入った部品を示します。部品発注時は注意してください。
KKD/KKJ-1204
3
3
Reel Holder
Feeder Holder
10
16
8
14
11
6
7
1
11
8
13
5
13
8
11
3
4
2
9
8
12
7
1
10
1
10
7
15
13
8
11
3
4
2
9
8
12
1
9
8
11
12
4
10
7
3
8
14
2
18
17
17
17
Fix60
Fix60
Front Left
Front Right
Fix24
Fix24
Front Left
Front Right
8
11
KKD/KKJ-1204
3
4
Feeder Set Sensor
Feeder Holder
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rank Level No. Part No. Part Name Q'ty Remarks Rank Level
1 KHY-M3901-00 BRACKET SENSOR 2 4 /
r
39
2 KHY-M3910-00 BRACKET SENSOR 1 4 /
r
40
3 KGS-M3906-00 BRACKET 6 4 /
r
41
4 KHY-M3951-00 PLATE SENSOR 4 /
r
42
5 KHY-M3952-00 PLATE SENSOR 2 /
r
43
6 KHY-M3953-00 BRACKET SENSOR 3 2 /
r
44
7 91312-05014 BOLT HEX.SOCKET HEAD 8 M5X14 45
8 91312-04010 BOLT HEX.SOCKET HEAD 16 M4X10 46
9 91312-03010 BOLT HEX.SOCKET HEAD 8 M3X10 47
10 92902-05200 WASHER PLAIN 8 48
11 92902-04200 WASHER PLAIN 12 49
12 92902-03200 WASHER PLAIN 8 50
13 90112-02J006 BOLT HEX.SOCKET HEAD 8 51
14 KG2-M3903-10 SEAL LASER 4 /
r
52
15 KJJ-M3790-00 COVER,HNS 1 /
r
53
16 KJJ-M3790-10 COVER,HNS 1 /
r
54
17 KHY-M652Y-00 SENSOR,FEE.FLT.ASSY 2 B
r
55
18 KHY-M652Y-10 SENSOR,FES1 FLT.ASSY 2 B
r
56
19 57
20 58
21
59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
