YS12P_12F_mpl_je - 第21页
39 40 34 30 36 33 39 38 32 39 31 30 15 36 33 39 37 39 37 37 37 37 37 37 23 28 35 1 1 24 13 24 42 7 26 41 24 1 1 24 13 7 26 41 14 21 18 21 20 19 20 18 37 19 17 16 24 39 12 5 29 26 6 2 5 26 29 4 29 22 3 24 1 8 9 25 12 27 2…
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rev. Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1 KHY-M221A-A0 COVER,DUCT ASSY. 1 /
Í
39 98902-03006 SCREW BINDING HEAD 4
2 KGT-M2266-10 PLATE,NUT 1 /
Í
40 98902-04006 SCREW BINDING HEAD 4
3 KHY-M2268-00 BRACKET 1,TAPE 1 /
Í
41 90990-11J003 SCREW,PAN HEAD W/W 6
4 KHY-M2269-00 BRACKET 2,TAPE 1 /
Í
42
5 KHY-M220A-00 TAPE ,X DUCT 1 /
Í
43
6 KHY-M220B-00 TAPE 2,X DUCT 1 /
Í
44
7 KHY-M220C-00 TAPE 3,X DUCT 1 /
Í
45
8 KHY-M2252-02 STOPPER 1 for shipment /
46
9 KHY-M2265-00 JOINT 1 /
47
10 KHY-M2267-00 GUIDE,X AXIS 1 B
Í
48
11 KHY-M226B-01 COVER, BACK,X-AXIS 1
/
49
12 KHY-M227G-00 COVER,B.S. 1 /
50
13 KHY-M2282-00 DOG.ORIGIN 1 /
Í
51
14 KHY-M2283-00 DOG,SECOND LIMIT 2 /
Í
52
15 KHY-M2284-00 BRACKET,SENSOR 1 B
Í
53
16 KHY-M652W-00
SENSOR, XORG ASSY 1 B
Í
54
17 KHY-M652X-00 SENSOR, XOT ASSY 1 /
Í
55
18 $UL10 JOINT 1 /
56
19 KHY-M223V-00 COVER,PCB 1 /
57
20 KHY-M220D-00 TAPE, X-AXIS 2 /
Í
58
21 90K63-511403 AC SERVO MOTOR 1 /
Í
59
22 KHY-M2266-00 PLATE,NUT 1 B
Í
60
23 KHY-M2271-00 BALL SCREW 1 A
r
61
24 KHN-M2221-00 SUPPORT UNIT 1 /
Í
62
25 KHN-M224D-00 SPACER 1 /
Í
63
26 KHN-M2248-00 SPACER 2 /
Í
64
27 KGS-M2628-00 LOCK NUT 1 /
Í
65
28 KG2-M9173-00 LOCK NUT 1 /
Í
66
29 90990-26J008 BEARING 1 /
Í
67
30 KHY-M224H-00 DAMPER 2 /
68
31 KHN-M224J-00 COLLAR A 4 /
69
32 KHN-M224K-00 COLLAR B 4 /
70
33 97602-03108 SCREW,PAN HEAD W/W 4 71
34 91312-04008 BOLT HEX.SOCKET HEAD 26 M4X8 72
35 91312-04020 BOLT HEX.SOCKET HEAD 2 M4X20 73
36 92012-04025 BOLT BUTTON HEAD 4 M4X25 74
37 91312-06020 BOLT HEX.SOCKET HEAD 4 M6X20 75
38 90990-01J032 BOLT HEX.SOCKET HEAD 8 76
Rev. :It is the parts which a change was in in the past. Please be careful at the time of the parts ordering.
Rev.: 過去に変更が入った部品を示します。部品発注時は注意してください。
KKD/KKJ-1204
4
1
X-axis
Moving-axis
39
40
34
30
36
33
39
38
32
39
31
30
15
36
33
39
37
39
37
37
37
37
37
37
23
28
35
11
24
13
24
42
7
26
41
24
11
24
13
7
26
41
14
21
18
21
20
19
20
18
37
19
17
16
24
39
12
5
29
26
6
2
5
26
29
4
29
22
3
24
1
8
9
25
12
27
22
1
8
9
25
27
10
43
44
46
45
43
44
46
45
KKD/KKJ-1204
4
2
Y-axis
Moving-axis
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q'ty Remarks Rev Rank Level No. Part No. Part Name Q'ty Remarks Rev. Rank Level
1 KHY-M2648-00 DAMPER 2 /
39 92902-05200 WASHER PLAIN 24
2 KHY-M652A-00 SENSOR,Y ORG ASSY 1 B
Í
40 90172-00J050 WASHER,EXTL.TOOTHED 8
3 KHY-M652F-00 SENSOR,Y OT ASSY 1 B
Í
41 92902-05200 WASHER PLAIN 4
4 KHY-M2682-00 DOG,ORIGIN 1 B
Í
42 KHY-M2658-01 PLATE FIX Y AXIS 1 /
Í
5 KHY-M2683-00 DOG,SECOND LIMIT 2 /
Í
43 KHY-M2671-00 BALL SCREW 2 A
r
6 KHY-M2691-00 BRACKET,SENSOR 1 /
Í
44 KHW-M224A-A0 SUPPORT UNIT 2 /
Í
7 KHW-M2654-00 PLATE , DAMPER 2 /
45 90990-26J008 BEARING 2 /
Í
8 KHN-M224J-00 COLLAR A 4 /
46 KG2-M9173-00 LOCK NUT 2 /
Í
9 KHN-M224K-00 COLLAR B 4 /
47
10 KGS-M2256-00 GRIP 1 /
Í
48
11 KV7-M2651-00 DAMPER,STOPPER 2 /
Í
49
12 90K63-611F04 AC SERVO MOTOR 2 B
Í
50
13 KHW-M2656-00 SPACER 4 /
51
14 KHY-M26C1-01 COVER TOP,BALL SCREW 1
/
52
15 KHY-M26C8-01 COVER TOP L,BS 1
/
53
16 KHY-M266A-00 PLATE,PIPE R 1 /
Í
54
17 KHY-M266B-00 PLATE,PIPE L 1 /
Í
55
18 KHY-M266C-00 BLOCK,JOINT 2 /
Í
56
19 KHY-M266D-00 JOINT 2 /
Í
57
20 KHY-M266E-00 JOINT 2 /
Í
58
21 KHN-M22AD-00 GREASE NIPPLE 2 /
Í
59
22 91312-03006 BOLT HEX.SOCKET HEAD 4 M3X6 60
23 61
24 91312-04008 BOLT HEX.SOCKET HEAD 21 M4X8 62
25 91312-04025 BOLT HEX.SOCKET HEAD 4 M4X25 63
26 91312-05010 BOLT HEX.SOCKET HEAD 14 M5X10 64
27 91312-06018 BOLT HEX.SOCKET HEAD 8 M6X18 65
28 66
29 92902-05600 WASHER PLAIN 10 67
30 KHY-M26C2-01 COVER1,BALL SCREW 2 68
31 KHY-M26C3-00 COVER2,BALL SCREW 1 69
32 KHY-M26C4-00 COVER3,BALL SCREW 1 70
33 KHY-M26C5-00 HEX. POST 6 /
Í
71
34 KHY-M26C6-01 BRKT. 2R,COVER Y 1
/
Í
72
35 KHY-M26C7-01 BRKT. 2L,COVER Y 1
/
Í
73
36 KHY-M2655-01 BRKT. COVER Y AXIS 2
/
Í
74
37 91312-05008 BOLT HEX.SOCKET HEAD 30 M5X8
75
38 91312-06010 BOLT HEX.SOCKET HEAD 20 M6X10 76
KKD/KKJ-1204
4
2
Y-axis
Moving-axis
