KKX-1306 MET AL ASSY ,3S 250 1 MET AL 3S SQG. SELECTION MET AL ASSY ,3S 300 14 MET AL ASSY ,3S 400 20 MET AL ASSY ,3S 440 23 MET AL ASSY ,3S 530 26 MET AL ASSY ,3S 350 17 2 4 5 12 9 9 5 12 6 7 8 6 4 10 10 1 1 3 35 15 4 5…

100%1 / 87
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
$NK-2N NYLON CLIP 3
/
39
2
90990-11J003 SCREW, PAN HEAD W/W
3
40
3
90K63-021448 AC SERVO MOTOR 1
B
Í
41
4
91312-03010 BOLT HEX,SOCKET HEAD 1
42
5
91312-03012 BOLT HEX,SOCKET HEAD 4
43
6
91312-03020 BOLT HEX,SOCKET HEAD 1
44
7
91312-04010 BOLT HEX,SOCKET HEAD 5
45
8
91312-04014 BOLT HEX,SOCKET HEAD 4
46
9
91312-04020 BOLT HEX,SOCKET HEAD 3
47
10
91312-04050 BOLT HEX,SOCKET HEAD 2
48
11
91312-05010 BOLT HEX,SOCKET HEAD 2
49
12
91312-05012 BOLT HEX,SOCKET HEAD 3
50
13
92012-04012 BOLT, BOTTON HEAD 2
51
14
KGJ-M3169-00 DAMPER,R 2
/
Í
52
15
KGJ-M7116-01 BALL PLUNGER 1
/
53
16
KGY-M7177-00 DAMPER 3 1
/
54
17
KHT-M7119-00 HOLDER R,SHAFT 2 1
/
Í
55
18
KHT-M7119-10 HOLDER L,SHAFT 2 1
/
Í
56
19
KHT-M7120-00 PLATE,SQG. 1
/
Í
57
20
KHT-M7121-00 BRKT.,3S ORG. SENSOR 1
/
Í
58
21
KHT-M7122-00
DOG,SR 1
/
Í
59
22
KHT-M7123-00 SPACER,DOG SR 1
/
Í
60
23
KKX-M7124-00 DOG,FX SAFETY 1
/
Í
61
24
KHT-M7125-00 DAMPER,SR 1
/
Í
62
25
KHT-M7128-00 WEIGHT 1,3S 1
/
Í
63
26
KHT-M7129-00 WEIGHT 2,3S 8
/
Í
64
27
90990-41J156 COLLAR 5
/
65
28
KKX-M653K-00 SENSOR SRORG ASSY 1
B
Í
66
29
KKX-M653L-00 SENSOR SRSAFE ASSY 1
B
Í
67
30
92902-03200 WASHER,PLAIN 1
68
31
92902-04600 WASHER,PLAIN 2
69
32
95302-05700 NUT HEXAGON 1
70
33
98902-03008 SCREW BINDING HEAD 2
71
34
99480-04010 PIN,PARALLEL 4
72
35
99480-06018 PIN,PARALLEL 1
73
36
KKX-M7108-00 PLATE,3S STOPPER 1
/
Í
74
37
91312-05014 BOLT HEX,SOCKET HEAD 4
75
38 76
4
1
3S-Motor / Sensor
Head
KKX-1306
METAL ASSY,3S 250
1
METAL 3S SQG. SELECTION
METAL ASSY,3S 300
14
METAL ASSY,3S 400
20
METAL ASSY,3S 440
23
METAL ASSY,3S 530
26
METAL ASSY,3S 350
17
2
4
5
12
9
9
5
12
6
7
8
6
4
10
10
11
3
35
15
4
5
12
9
9
5
12
6
7
8
6
4
10
10
11
16
35
18
4
5
12
9
9
5
12
6
7
8
6
4
10
10
11
19
35
21
4
5
12
9
9
5
12
6
7
8
6
4
10
10
11
22
35
24
4
5
12
9
9
5
12
6
7
8
6
4
10
10
11
25
35
27
4
5
12
9
9
5
12
6
7
8
6
4
10
10
11
28
13
29
30
31
32
33
34
4
2
SQG-3S-Metal
Head
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M71A0-50 METAL ASSY,3S 250
1 /
39
2
KGY-M71A1-02 METAL HOLDER 1,3S 25
1 /
40
3
KGY-M71AA-00 METAL SQG.WELD,3S 25
1 E
41
4
KGY-M71A4-00 STOPPER,3S SIDE PLAT
12 /
42
5
KGY-M71A5-00 BUSH,SQG.SIDE PLATE
12 /
43
6
KHT-M71A6-00 SIDE PLATE,3S
12 /
44
7
KGJ-M710B-C0 SPACER PIPE
12
/
45
8
KGJ-M710B-D1 KNOB 1
12
/
46
9
90563-03J100 SPACER BOLT
12
/
47
10
91312-03005 BOLT HEX.SOCKET HEAD
24
M3X5
/
48
11
91312-04010 BOLT HEX.SOCKET HEAD
26
M4X10
/
49
12
92012-04016 BOLT,BUTTON HEAD
12
M4X16
/
50
13
99480-04012 PIN PARALLEL
4
4X12
/
51
14
KHT-M71A0-40 METAL ASSY,3S 300
1
φ4X12
/
52
15
KGY-M71B1-02 METAL HOLDER 1,3S 30
1 /
53
16
KGY-M71BA-00 METAL SQG.WELD,3S 30
1 E
54
17
KHT-M71A0-30 METAL ASSY,3S 350
1 /
55
18
KGY-M71C1-02 METAL HOLDER 1,3S 35
1
/
56
19
KGY-M71CA-00 METAL SQG.WELD,3S 35
1
E
57
20
KHT-M71A0-20 METAL ASSY,3S 400
1
/
58
21
KGY-M71D1-02
METAL HODLER 1,3S 40
1 /
59
22
KGY-M71DA-00 METAL SQG.WELD,3S 40
1 /
60
23
KHT-M71A0-10 METAL ASSY,3S 440
1 /
61
24
KGY-M71E1-02 METAL HOLDER 1,3S 44
1 /
62
25
KGY-M71EA-00 METAL SQG.WELD,3S 44
1 E
63
26
KHT-M71A0-00 METAL ASSY,3S 530
1 /
64
27
KHT-M71A1-00 METAL HOLDER 1,3S530
1 /
65
28
KHT-M71AA-00 METAL SQG.WELD,3S530
1 E
66
29
KGY-M71AB-00 TRIM, 250
2 A
67
30
KGY-M71BB-00 TRIM, 300
2 A
68
31
KGY-M71CB-00 TRIM, 350
2 A
69
32
KGY-M71DB-00 TRIM, 400
2 A
70
33
KGY-M71EB-00 TRIM, 440
2 A
71
34
KHT-M71A5-00 TRIM, 530
2 A
72
35
99480-04010 PIN PARALLEL
2 /
73
36 74
37 75
38 76
4
2
SQG-3S-Metal
Head
