YSP20_mpl - 第47页
KKX-1306 Conv 1 Conv 2 32 14 8 21 5 26 31 14 3 15 16 24 19 20 27 18 2 9 12 1 1 10 22 8 23 17 7 25 4 6 30 3 13 33 1 28 13 28 29 34 Conv 2 7 1 Conv.1/2 Stand L Conveyor Unit
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 $UY4 JOINT 4 39 KLB-M5126-D0 SAFETY SW 2
The down stream
B
Í
2 $SC4-01A SPEED CONTROLLER 4 40
3 $TL4-01 JOINT 2 41
4 $TS4-01 JOINT 2 42
5 90933-02J685 BEARING 1 43
6 90990-28J098
WASHER,PLAIN
4
44
7 91312-03025
BOLT HEX,SOCKET HEAD
2
45
8 91312-04010
BOLT HEX,SOCKET HEAD
8
46
9 91312-05045 BOLT HEX,SOCKET HEAD 8
47
10 91312-06025 BOLT HEX,SOCKET HEAD 16 48
11 91312-06030 BOLT HEX,SOCKET HEAD 16 49
12 91317-04012 BOLT HEX,SOCKET HEAD 12 50
13 92012-05016 BOLT BUTTON HEAD 31 51
14 92012-06010 BOLT BUTTON HEAD 2 52
15 92902-04200 WASHER,PLAIN 4 53
16 92902-06200 WASHER,PLAIN 32 54
17 95302-05700 NUT HEXAGON
1
55
18
98902-03010 SCREW BINDING HEAD
1
56
19
KGJ-M3201-00 POWER LOCK
1
/
Í
57
20 KGS-M1360-00 BOLT 4
/
Í
58
21 KHT-M2691-01 KNURLED SCREW 1 /
Í
59
22 KHT-M9B00-01 BALL SCREW,Z 4 /
Í
60
23 KKX-M211P-00 STAY,HNS.MZ 1 2 /
Í
61
24 KKX-M2134-00 PLATE,PW LOCK 4 /
Í
62
25 KKX-M2135-00 BLOCK,PW LOCK 4 /
Í
63
26 KKX-M214E-01 BRKT.,MAGNET 2 /
Í
64
27 KKX-M2151-00 CYL.,MASK CLAMP 4 /
65
28 KKX-M2152-00 BRKT.,CYLINDER 4 /
Í
66
29
KKX-M2154-00 DOG,MASK CLAMP 1
/
Í
67
30 KKX-M2156-00 COVER,HNS. 1 /
68
31 KKX-M2156-10 COVER,HNS. 1 /
69
32 KKX-M2157-00 SEAL,MASK STOPPER 1 /
70
33 KKX-M653M-00 SENSOR M.CLAMP ASSY 1 B
Í
71
34 KLB-M5126-C0 SAFETY SW 2
The upper reaches.
B
Í
72
35 98902-04008 SCREW BINDING HEAD 6 73
36 98907-03008 SCREW BINDING HEAD 1 74
37 KKX-M653N-20 SENSOR M.FLAME3 ASSY 1 B
Í
75
38
90K41-001300 LABEL,CAUTION 4
76
6
1
MZ-Moving Clamp
Mask Table
KKX-1306
Conv 1
Conv 2
32
14
8
21
5
26
31
14
3
15
16
24
19
20
27
18
2
9
12
11
10
22
8
23
17
7
25
4
6
30
3
13
33
1
28
13
28
29
34
Conv 2
7
1
Conv.1/2 Stand L
Conveyor Unit
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 90990-11J001 SCREW, PAN HEAD W/W 2 39
2 91312-03010 BOLT HEX,SOCKET HEAD 4 40
3 91312-04006 BOLT HEX,SOCKET HEAD 4 41
4 91312-04050 BOLT HEX,SOCKET HEAD 4 42
5 91312-05010 BOLT HEX,SOCKET HEAD 1 43
6 91312-05012 BOLT HEX,SOCKET HEAD
2
44
7
91312-06016 BOLT HEX,SOCKET HEAD
2
45
8
91312-06020 BOLT HEX,SOCKET HEAD
4
46
9 KG2-M9108-11 COLLAR CONVEYOR 1
/
Í
47
10 KGK-M9170-00 DC MOTOR ASSY. 1
B
Í
48
11 KGT-M9135-00 PULLEY 1, SPLINE 1 /
Í
49
12 KGT-M9193-00 NUT PLATE 4 /
Í
50
13 KH2-M9105-11 PULLEY,MOTOR:P30-3GT 2 /
Í
51
14 KH2-M9121-00 BEARING 2 /
Í
52
15 KHT-M9111-02 PULLEY 1,MOTOR 1 /
Í
53
16 KHT-M9113-00 COUPLING 1 /
Í
54
17 KKX-M9107-00 BRKT.,CONV. MOTOR
1
/
Í
55
18
KKX-M9108-01
SPLINE 1
/
Í
56
19
KKX-M910A-00 PLATE,CONV. 1
1
/
Í
57
20 KKX-M910B-10 PLATE,CONV. 2 1
Conv 1
/
Í
58
21 KKX-M910B-60 PLATE,CONV. 2 1
Conv 2
/
Í
59
22 KKX-M910G-10 BRKT.,CONV. 2L 1
Conv 1
/
Í
60
23 KKX-M910H-10 BRKT.,CONV. 3L 1 /
Í
61
24 91312-06025 BOLT HEX,SOCKET HEAD 2 62
25 92902-04200 WASHER,PLAIN 4 63
26 92902-05200 WASHER,PLAIN 1 64
27 92902-06200 WASHER,PLAIN 2 65
28 92A08-04306 SCREW SET 4 66
29
KLH-M91AH-00 BELT 219-3GT-91 1
A
Í
67
30 $CTAM1 ANCHOR MOUNT 2 68
31 KKX-M910G-00 BRKT.,CONV. 2R 1
Conv 2
/
Í
69
32 90990-28J018 WASHER,PLAIN 1 70
33 90990-41J106 COLLAR 1 71
34 91312-04012 BOLT HEX,SOCKET HEAD 1 72
35 73
36 74
37 75
38 76
7
1
Conv.1/2 Stand L
Conveyor Unit
