YSP20_mpl - 第63页
KKX-1306 1 7 12 2 8 13 5 10 3 9 4 6 1 1 1 1 15 14 6 4 3 9 7 9 PCB Back Up (Op.) Conveyor Unit
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
90990-29J014 SHIM 10
39
2
91312-04010
BOLT HEX,SOCKET HEAD
4
40
3
91312-04030 BOLT HEX,SOCKET HEAD 4
41
4
91312-08012 BOLT HEX,SOCKET HEAD 2
42
5
92A08-03304 SCREW SET 1
43
6
98702-04012 SCREW,FLAT HEAD 2
44
7
99480-05016 PIN,PARALLEL 1
45
8
99480-06014 PIN,PARALLEL 1
46
9
KGY-M94A2-00 BLOCK, SUPPORT 2
/
47
10
KGY-M94A7-00
MAGNET 2
/
48
11
KKX-M9400-00 PCB VACUUM ASSY. 1
/
49
12
90990-43J009 PIN 2
/
50
13
KKX-M9401-00 BLOCK,MANIFOLD 1
/
Í
51
14
KKX-M9402-00 PAD,FITTING 1
/
Í
52
15
KKX-M9403-00 PAD,FITTING 2
/
Í
53
16
KKX-M9404-00 PAD,VACUUM 1
A
54
17
KKX-M9405-00 PAD,VACUUM 2
A
55
18
KKX-M9406-00 PLATE 1,MANIFOLD 1
/
56
19
KKX-M9407-00 PLATE 2,MANIFOLD 1
/
57
20
58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
7
8
PCB Vacuum (Op.)
Conveyor Unit
KKX-1306
1
7
12
2
8
13
5
10
3
9
4
6
11
11
15
14
6
4
3
9
7
9
PCB Back Up (Op.)
Conveyor Unit
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M3300-A1 BACK UP,A
9 /
39
2
KHT-M3301-A1
PLATE,BACK UP,A
1
/
40
3
KHT-M3302-01 LEG 1
2 /
41
4
KHT-M3303-01 LEG 2
2 /
42
5
91312-04010 BOLT HEX.SOCKET HEAD
8
M4X10
/
43
6
99480-03010 PIN,PARALLEL
2
M3X10
/
Í
44
7
KHT-M3300-B1 BACK UP,B
6 /
45
8
KHT-M3301-B1 PLATE,BUCK UP,B
1
/
46
9
KHT-M3305-00 LEG 2
2 /
47
10
91312-04010
BOLT HEX.SOCKET HEAD
8
M4X10
/
48
11
99480-03010 PIN,PARALLEL
4
M3X10
/
Í
49
12
KHT-M3300-C1 BACK UP,C
3 /
50
13
KHT-M3304-01 BLOCK,BACK UP
1 /
51
14
99480-03012 PIN,PARALLEL
1
M3X12
/
Í
52
15
90990-21J004 PIN
1 /
Í
53
16 54
17 55
18
56
19
57
20
58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
7
9
PCB Back Up (Op.)
Conveyor Unit
