FP HEAD-Guide/Screw
PSC
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHT-M7337-A0 FP STOPPER SET 1
39
2
90990-41J074 COLLAR 1 40
3
91312-03016 BOLT HEX,SOCKET HEAD 2 41
4
91312-03045 BOLT HEX,SOCKET HEAD 2 42
5
91312-04012 BOLT HEX,SOCKET HEAD 7 43
6
91312-04014 BOLT HEX,SOCKET HEAD 6 44
7
91312-05016 BOLT HEX,SOCKET HEAD 6 45
8
91B00-02610 KEY, STRAIGHT 1 46
9
92902-06600 WASHER,PLAIN 2 47
10
92A08-03303 SCREW SET 2 48
11
95302-05700 NUT HEXAGON 2 49
12
98702-03010 SCREW,FLAT HEAD 2 50
13
KGJ-M710B-C0 SPACER PIPE 2
/
51
14
KHT-M2688-00 MAGNET 2
/
Í
52
15
KHT-M7302-00 UP PLATE,FP AXIS 1
/
Í
53
16
KHT-M7303-00 GUIDE,FP AXIS 1
/
Í
54
17
KHT-M7309-00 HOUSING,BRG.FP 1
/
Í
55
18
KHT-M7310-00 BALL SCREW,FP 1
/
Í
56
19
KHT-M7312-00 PULLEY,P32-3GT 1
/
Í
57
20
KHT-M7314-00 LOCK NUT 1
/
Í
58
21
KHT-M7319-00 DAMPER,FP 1
/
Í
59
22
KHT-M7327-00 MINI CLAMP LEVER 2
/
60
23
KHT-M7336-00 BALL PLUNGER 2
/
61
24
KKX-M7301-00 PLATE 1,FP AXIS 1
/
Í
62
25
KKX-M7304-00 PLATE 2,FP AXIS 1
/
Í
63
26
KKX-M7305-01 HOLDER,NUT 1
/
Í
64
27
KKX-M7307-00 COVER,SOL. 1
/
65
28
KKX-M7332-00 PLATE,NUT 1
/
66
29
KKX-M7333-00 BLOCK 1,NOZZLE 1
/
67
30
KKX-M7334-00 BLOCK 2,NOZZLE 1
/
68
31
KM8-M117B-00 PLUG (M6) 1
/
Í
69
32
KX1-M2231-00 BEARING 1
/
Í
70
33
99480-04010 PIN,PARALLEL 2 71
34
99480-05018 PIN,PARALLEL 4 72
35
73
36
74
37 75
38 76
8
2
FP HEAD-Guide/Screw
PSC
KKX-1306
4
5
10
8
7
7
8
6
1
3
2
12
9 11
8
6
7
8
