Disp.Supply / Vacuum
PSC
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 $KM-11 MUFFLER 2
39
2 $SL4-01 JOINT 2
40
3 $SL6-01 JOINT 4
41
4 $SL8-01 JOINT 1
42
5 $TL4-01 JOINT 1
43
6 $TL6-01 JOINT
2
44
7
$TL8-02 JOINT
3
45
8 $ULA6
JOINT
2
46
9 $USD6-4 JOINT 1
47
10 $ULA8 JOINT 3
48
11 $UY4 JOINT 1
49
12 $USD8-6 JOINT 1
50
13 91312-03020 BOLT HEX,SOCKET HEAD 10
51
14 91312-04005 BOLT HEX,SOCKET HEAD 2
52
15 91312-04006 BOLT HEX,SOCKET HEAD 5
53
16 91312-05006 BOLT HEX,SOCKET HEAD 4
54
17 KGJ-M3245-01 REGULATOR
2
/
Í
55
18
KKX-M7235-00
PRESSURE GAUGE 2
/
Í
56
19
KHT-M7232-A0 DISP. VALVE ASSY
2
/
57
20 KHT-M7236-00 VALVE,125A 1
/
58
21 KHT-M7237-00 VACUUM UNIT 1
/
Í
59
22 KKX-M1142-00 BRKT.,VALVE 2 /
Í
60
23 KKX-M7251-00 BRKT.,VACUUM VALVE 1 /
Í
61
24 KGJ-M9140-01 AIR FILTER 1 /
62
25
63
26
64
27
65
28
66
29
67
30
68
31
69
32
70
33
71
34
72
35
73
36
74
37 75
38 76
