YSP20_mpl - 第81页
KKX-1306 16 22 18 13 1-6,35,36 7 14 8 19 1 1,37 9-10 20 19 17 23-34 12 19 1-6,35,36 15 20 21 7 8 16 19 1 1,37 9-10 17 10 1 Exterior, etc Exterior, etc
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 90166-12JA10 SCREW PAN HEAD 6
39
2 97602-04308
SCREW PAN HEAD W/WASHER
13
40
3 KLA-M4209-00 SYSTEM UNIT ASSY 1
STD
B
r
41
4 KLA-M4209-20 SYSTEM UNIT ASSY 1
for INSPECTION
B
r
42
5 KLA-M4255-00 FLASH DISK 1 B
r
43
6 KHL-M441H-53 VISION BOARD ASSY 1 B
r
44
7 KHN-M4530-56
REMOTE IF BOARD ASSY 1
STD
B
r
45
8 KHN-M5840-B2
SERVO BOARD ASSY
2
STD
B
r
46
9
KHN-M5803-81 SERVO UNIT ASSY
2
for PSC
B
r
47
10 KJJ-M5880-20 D.POWER BOARD ASSY 2
B
r
48
11 KHN-M5840-02 SERVO BOARD ASSY 2
B
r
49
12 KHN-M5840-A2 SERVO BOARD ASSY 2 B
r
50
13 KJJ-M4140-10 DUMMY PANEL SERVO 2 /
r
51
14 KJJ-M4141-00 DUMMY PANEL SYS 1 /
r
52
15 KJJ-M411A-00 PLATE 4 /
Í
53
16
KJJ-M411B-00 BRACKET 2 4 /
Í
54
17 KJJ-M53A9-20 FILTER 4 A
Í
55
18 KJJ-M53E9-20
TAPE 4
A
Í
56
19 KJX-M4116-00
BRACKET,1 FILTER
2
/
57
20
KJX-M4117-00
BRACKET,2 FILTER 2
/
58
21 KJX-M4216-00 BRACKET 1 FILTER 1 /
59
22 KJX-M4217-00 BRACKET 2 FILTER 1 /
60
23 KJX-M53A9-00. FILTER 1 A
61
24 KJX-M53A9-20 FILTER 2 A
62
25 KJX-M53E9-00 TAPE 1 A
63
26 KJX-M53E9-20 TAPE 2 A
64
27 KHN-M4530-26 REMOTE IF BOARD ASSY 1
for YTC
B
r
65
28
66
29
67
30
68
31
69
32
70
33
71
34
72
35
73
36
74
37 75
38 76
9
1
Control Box
Control Box
KKX-1306
16
22
18
13
1-6,35,36
7
14
8
19
11,37
9-10
20
19
17
23-34
12
19
1-6,35,36
15
20
21
7
8
16
19
11,37
9-10
17
10
1
Exterior, etc
Exterior, etc
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KKE-M669V-00 HNS,SWITCH ACTIVE 2 B
Í
39
2 KKE-M669V-10 HNS,SWITCH READY 2
B
Í
40
3 KKE-M669V-20 HNS,SWITCH START 2 B
Í
41
4 KKE-M669V-30 HNS,SWITCH STOP 2 B
Í
42
5 KKE-M669V-40 HNS,SWITCH ERR.CLR. 2 B
Í
43
6 KKE-M669V-50 HNS,SWITCH RESET
2
B
Í
44
7
KKE-M6555-A0 LANE SELECT SWITCH ASSY
2
B
Í
45
8 KGK-M5138-00
SWITCH EMG ASSY
2
B
Í
46
9 KGT-M5106-B0 SMT OPE.PANEL ASSY 2 DC12V
A
47
10 KGT-M5119-03 SMT OPE.T.PANEL ASSY 2 A
48
11 KKX-M13B0-00 ERROR SIGNAL ASSY. 2 STD /
Í
49
12 KKX-M5126-30 SAFETY SW LOCK ASSY 1 B
Í
50
13 KKX-M5126-40 SAFETY SW LOCK ASSY 1 B
Í
51
14 KKX-M5126-20 SAFETY SW LOCK ASSY 1 B
Í
52
15 KKX-M5126-00 SAFETY SW LOCK ASSY 1 B
Í
53
16 KKX-M5126-10 SAFETY SW LOCK ASSY 2 B
Í
54
17 91312-04045 BOLT HEX,SOCKET HEAD
16
55
18
KJJ-M4580-24
I/O CONV. BOARD ASSY 1
B
Í
56
19
KGA-M4187-00 FAN GUARD 119MM
8
/
Í
57
20 KHY-M6185-10 FAN MOTOR ASSY 4
B
Í
58
21 KKE-M6554-00 MAIN SWITCH 1
B
Í
59
22 KGK-M6680-20 HNS,USB MEMORY 2M AS 1 /
Í
60
23 KJX-M4899-00 LIGHT 1 ASSY. 1 1850mm RYG A
61
24 KJX-M4899-10 LIGHT 1 ASSY. 1 1850mm CBG A
62
25 KJX-M4899-20 LIGHT 1 ASSY. 1 1900mm RYG A
63
26 KJX-M4899-30 LIGHT 1 ASSY. 1 1900mm CBG A
64
27 KJX-M4899-40 LIGHT 1 ASSY. 1 2000mm RYG A
65
28 KJX-M4899-50 LIGHT 1 ASSY. 1 2000mm CBG A
66
29 KJX-M4899-60 LIGHT 1 ASSY. 1 2100mm RYG A
67
30 KJX-M4899-70 LIGHT 1 ASSY. 1 2100mm CBG A
68
31 KJX-M4899-80 LIGHT 1 ASSY. 1 2200mm RYG A
69
32 KJX-M4899-90 LIGHT 1 ASSY. 1 2200mm CBG A
70
33 KJX-M4899-A0 LIGHT 1 ASSY. 1 2300mm RYG A
71
34 KJX-M4899-B0 LIGHT 1 ASSY. 1 2300mm CBG A
72
35 KKE-M669V-60 HNS,SWITCH STOP 2 for CE B
Í
73
36 KKE-M669V-70 HNS,SWITCH ERR.CLR. 2 for CE B
Í
74
37
KKX-M13B0-50 ERROR SIGNAL ASSY. 2 for CE B
Í
75
38 76
10
1
Exterior, etc
Exterior, etc
