YSP20_mpl - 第84页
KKX-1306 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…
KKX-1306
17
18
16
19
7
9
3
1
8
6
14
10
5
15
1
2
3
6
11
13
4
12
10
2
Key Board
Exterior, etc
KKX-1306
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 $NK-3N NYLON CLIP 4 /
39
2 90172-00J040 WASHER, EXTL, TOOTHED 4 40
3 90990-11J001 SCREW, PAN HEAD W/W 4 41
4 90990-41J007 COLLAR 1 42
5 90990-41J097 COLLAR 2 43
6 91312-04006 BOLT HEX,SOCKET HEAD 8 44
7 91312-04012 BOLT HEX,SOCKET HEAD 2 45
8 91312-05014 BOLT HEX,SOCKET HEAD 2 46
9 KG2-M1362-001 STOPPER 2 /
47
10 KGA-M13B2-01 SHAFT,KEYBOARD 1 /
48
11 KGA-M13B4-00 BRACKET, PAD 1 /
49
12 KGB-M1391-00 MOUSE PAD 1 /
50
13 KKX-M13K1-00 BRACKET,KEYBOARD 1 /
Í
51
14 KKX-M13K4-00 BRKT.,KEYBOARD 1 /
Í
52
15 92902-04200 WASHER,PLAIN 4 53
16 KKX-M13K0-00 BRKT. KEYBOARD ASSY. 1 /
Í
54
17
KW3-M5150-50 KEYBOARD J
1
Japanese
A
55
KW3-M5150-60 KEYBOARD E
1
English
A
56
18
KW3-M5169-04 MOUSE
1 A
57
19
KGA-M13B5-00 MOUSE POCKET ASSY
1 /
58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
10
2
Key Board
Exterior, etc
KKX-1306
4
2
1
5
3
7
6
10
3
Temp.Con.Spare
Exterior, etc
