Feeder Floating Detection
Feeder Holder
KMC-1709
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 $NK-2N NYLON CLIP 2 39
2 90112-02J006 BOLT HEX,SOCKET HEAD 3 40
3 90990-11J003 SCREW, PAN HEAD W/W 2 41
4 90K41-001320 LABEL,CAUTION 1 42
5 90K41-001620 LABEL,CAUTION 3 43
6 91312-03006 BOLT HEX,SOCKET HEAD 2 44
7 91312-04010 BOLT HEX,SOCKET HEAD 10 45
8 91312-05014 BOLT HEX,SOCKET HEAD 4 46
9 91312-04006 BOLT HEX,SOCKET HEAD 1 47
10 92902-03200 WASHER,PLAIN 3 48
11 KLW-M653V-00 SENSOR,FDR.FLT.ASSY 2 B
Í
49
12 KLW-M653V-10 SENSOR,FDR.FLT.ASSY 1 B
Í
50
13 KGS-M3906-00 BRACKET 6 3 /
Í
51
14 KHY-M3901-00 BRACKET SENSOR 2 4 /
Í
52
15 KHY-M3910-00 BRACKET SENSOR 1 3 /
Í
53
16 KHY-M3951-00 PLATE SENSOR 3 /
Í
54
17 KHY-M3952-00 PLATE SENSOR 1 /
Í
55
18 KHY-M3953-00 BRACKET SENSOR 3 1 /
Í
56
19 KLW-M3902-00 BRKT.,SENSOR L 1 /
Í
57
20 KLW-M3904-00 BRKT.,SENSOR R 1 /
Í
58
21 KLW-M3905-00 PLATE,NUT 2 /
Í
59
22 KLW-M3907-00 BLOCK,SENSOR 1 /
Í
60
23 KLW-M3908-00 STAY,SENSOR 1 /
Í
61
24 KLW-M3909-00 COVER,SENSOR 1 /
Í
62
25 91312-03010 BOLT HEX,SOCKET HEAD 3 63
26 92902-04200 WASHER,PLAIN 5 64
27 92902-05200 WASHER,PLAIN 4 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
