1-H 本体部 Main Body パーツレイアウト Kit No. キット品 番 Kit Name キット名称 N610023989AB ｾｸｼｮﾝNo. PARTS LAYOUT Section No. M15
Ref
No.
Remarks
R
1
Q't
y
1-G
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
N610023989AB
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
3
28 N210043257AA
COVER
1
30 N210071161AA
COVER
1
31 N210071162AA
COVER
1
32 N210071163AA
COVER
1
33 N210071164AA
COVER
1
42 N210043249AC
BRACKET
4
43 N210043259AA
PW106A1
8
44 KXFB02RKA00
SENSOR
4
112 KXF0DKWAA00 EX-21A(DA 0DKWA)
SCREW
16
113 N510018036AA
Cross recessed Pan head machine screw M3X10-4.8 A2J (Trivalent)
SCREW
10
137 N510018303AA
Cross recessed Truss head machine screw M5X8-4.8 A2S (Trivalent)
BOLT
8
165 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
12
172 N510017419AA
Hexagon socket head cap screw M5X8-10.9 A2J (Trivalent)
BOLT
37
174 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
WASHER
8
190 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
12
191 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
37
196 N510020100AA Thick washer for M5
COVER
1
214 N210043247AC
COVER
1
215 N210069405AA
COVER
1
216 N210071178AA
COVER
1
217 N210086826AA
COVER
1
218 N210069412AA
BRACKET
1
219 N210043266AA
COVER
1
220 N210045241AB
COVER
1
221 N210043252AC
BRACKET
2
231 KXFB02RPA00
BRACKET
2
232 KXFB09X3A00
BRACKET
1
233 N210071175AA
BRACKET
1
234 N210071176AC
BRACKET
1
235 N210071177AB
BRACKET
1
236 N210049689AC
SPACER
8
242 N210053167AB
M14
1-H
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610023989AB
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
M15
Ref
No.
Remarks
R
1
Q't
y
1-H
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
N610023989AB
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COVER
1
57 N210022722AB
COVER
1
58 N210022723AC
COVER
1
59 N210022724AC
FRAME
2
138 N510012057AA SFF-244 L=406
FRAME
2
141 KXF0E10PA00 SFF-404 L=325
NUT
14
142 N510016442AA HTDSN5-5
CAP
14
143 KXF0ATKAA00 SFA-905
BRACKET
2
148 KXF0E10SA00 HBLFSNK8
NUT
6
149 N510008940AA HTDSN8-8
NUT
4
150 KXF0E10TA00 SFB-007
NUT
14
151 KXF0E01HA00 SFB-008
CAP
18
152 KXF0E01GA00 SFA-907
BRACKET
2
155 N510010282AA SFJ-N03T
BRACKET
6
156 KXF0DTWAA00 SFJ-N03
BRACKET
4
157 N510010284AA SFJ-K11
NUT
4
158 KXF0CW2AA00 SFB-003
BOLT
12
171 N510017414AA
Hexagon socket head cap screw M5X6-10.9 A2J (Trivalent)
BOLT
14
175 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
6
180 N510017433AA
Hexagon socket head cap screw M6X16-10.9 A2J (Trivalent)
BOLT
4
181 N510017435AA
Hexagon socket head cap screw M6X20-10.9 A2J (Trivalent)
BOLT
4
185 N510017472AA
Hexagon socket head cap screw M8X20-10.9 A2J (Trivalent)
WASHER
24
191 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
10
192 N510018501AA
Round finish plain washer 6 10H A2J (Trivalent)
WASHER
10
226 KXF0E2KYA00 HDW8
SCREW
4
239 N510018376AA
Hexagon socket set screw Cup point M5X10-45H A2J (Trivalent)
M16
