QEJM6A-E-MPA-31 - 第75页
Ref No. Remarks R 1 Q't y 7-B 基 板 ホルダユニット Board Holder Unit ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit No . キット品 番 Kit Name キット名称 N610027373AA Part N ame 備 考 ｾｸｼｮﾝNo. PARTS LIST Section No. R 3 GUIDE 2 1 N210022551A…
?$
7
8
@AB-.
%*#%
''
!"#
).
""
Ref
No.
Remarks
R
1
Q't
y
7-B
基
板
ホルダユニット
Board Holder Unit
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット品
番
Kit Name
キット名称
N610027373AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
GUIDE
2
1 N210022551AA
CYL-NUT
2
2 KXFB00V6A00
CYL-NUT
2
3 KXFB00V7A00
PLATE
1
7 N210037012AA
BAR
4
9 N210037014AA
PIN
20
12 KXFB00VCA01
PLATE
1
13 N210022554AA
GUIDE
1
14 N210022555AA
SCREW
6
15 KXFB00UPA00
PLATE
2
16 N210022557AA
DOG
1
18 N210037016AB
BRACKET
1
19 KXFB0A3CA00
O-RING
80
23 KXF0DHMAA00 ID2XW0.5 gray NBR60deg
JOINT
4
24 KXF02BTAA00 KQL04-M5
CYLINDER
2
25 KXF0A6PAA00 CJ2F16-115
PLUNGER
1
26 KXF0E1CMA00 BSJL4
SHAFT
2
27 KXF0DY97A00 LSG-SC-20-151(DDA)
LINEAR-BUSH
2
28 KXF0DY8XA00 TBW-20UU
SPACER
6
37 N510017033AA 3382330-26140
SPACER
6
38 N510017032AA 3382330-26060
SPRING
1
39 KXF0CTJAA00 6659
BOLT
2
41 XVE26B5FTC
Hexagon socket head cap screw M2.6X5-12.9 SOB
WASHER
2
42 N510018476AA
Small round-plain washer 2.6 10H A2J (Trivalent)
COLLAR
2
43 KXF0DSBAA00 NCLM3-10-15.0
PLATE
2
44 KXF0CTNAA00 LMST20
WASHER
2
45 N510015406AA FWSSB-D8.0-V5.0-T2.5
WASHER
6
46 KXF0E13QA00 WSSB15-4-5
BOLT
3
52 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
4
53 N510017313AA
Hexagon socket head cap screw M3X16-10.9 A2J (Trivalent)
BOLT
2
54 N510017323AA
Hexagon socket head cap screw M3X30-10.9 A2J (Trivalent)
BOLT
2
55 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
1
57 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
BOLT
6
58 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
2
59 N510017428AA
Hexagon socket head cap screw M6X12-10.9 A2J (Trivalent)
WASHER
4
61 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
4
62 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
3
63 N510020098AA Thick washer for M3
WASHER
2
64 N510020099AA Thick washer for M4
WASHER
2
65 N510020100AA Thick washer for M5
WASHER
2
66 N510020101AA Thick washer for M6
NUT
3
68 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
NUT
2
69 N510017862AA
Hexagon nut Type-1 Best class M5-6H-4T A2J (Trivalent)
BOLT
8
70 N510017472AA
Hexagon socket head cap screw M8X20-10.9 A2J (Trivalent)
BOLT
4
71 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
M56
8-A
コンベア
幅寄
せ
部
Conveyor Width Adjustment Section
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610012610AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
M57
