QEJM6A-E-MPA-31 - 第78页
8-B コンベア 幅寄 せ 部 Conveyor Width Adjustment Section パーツレイアウト Kit No. キット品 番 Kit Name キット名称 N610012610AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. M59
Ref
No.
Remarks
R
1
Q'ty
8-A
コンベア
幅寄
せ
部
Conveyor Width Adjustment Section
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット
品番
Kit Name
キット名称
N610012610AA
Part Name
備 考
ｾｸｼｮﾝ
No
.
PARTS LIST
Section No.
R
3
PLATE
2
6 N210021896AA
PIN
2
7 KXFB0210A00
HOUSING
2
8 N210021900AA
HOUSING
1
9 N210021901AA
SHAFT
1
10 N510028444AA GE-16(g6)-326-w101
SHAFT
2
11 N210021904AA
BLOCK
1
12 N210021905AA
BRACKET
1
13 N210030230AA
BRACKET
1
15 N210030232AA
STOPPER
2
17 N210030234AA
BOLT
2
19 N510017368AA
Hexagon socket head cap screw M4X45-10.9 A2J (Trivalent)
WASHER
2
20 N510009969AA WASM12-5-1
LINEAR-BUSH
1
25 N510028440AA LM16-UU
LINEAR-BUSH
2
26 N510028443AA LMT16-UU
SCREW
1
28 N510018394AA
Hexagon socket set screw Cone point M3X8-45H A2J (Trivalent)
TUBE
1
29 KXF03PCAA00 TCU0425B-2
JOINT
2
30 KXF02SZAA00 M-5ALU-4
SPEED-CONTROLLER
2
31 KXF00YNAA00 AS1201F-M5-06
JOINT
6
33 KXF02SSAA00 M-3ALU-4
GREASE-NIPPLE
1
37 KXF0CSNAA00 GPA6A
BOLT
12
42 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
2
43 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
BOLT
2
44 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
8
45 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
BOLT
6
46 N510017437AA
Hexagon socket head cap screw M6X25-10.9 A2J (Trivalent)
WASHER
6
51 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
2
52 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
8
55 N510020100AA Thick washer for M5
WASHER
6
56 N510020101AA Thick washer for M6
WASHER
2
58 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
NUT
2
59 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
M58
-
-
( KN610012610AA-03-1 )
8-B
コンベア
幅寄
せ
部
Conveyor Width Adjustment Section
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610012610AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
M59
Ref
No.
Remarks
R
1
Q'ty
8-B
コンベア
幅寄
せ
部
Conveyor Width Adjustment Section
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット
品番
Kit Name
キット名称
N610012610AA
Part Name
備 考
ｾｸｼｮﾝ
No
.
PARTS LIST
Section No.
R
3
SENSOR
1
1 N610012679AA
PLATE
2
6 N210021896AA
PIN
2
7 KXFB0210A00
HOUSING
2
8 N210021900AA
HOUSING
1
9 N210021901AA
SHAFT
1
10 N510028444AA GE-16(g6)-326-w101
BRACKET
1
14 N210030231AA
BRACKET
1
16 N210030233AA
STOPPER
2
17 N210030234AA
BOLT
2
19 N510017368AA
Hexagon socket head cap screw M4X45-10.9 A2J (Trivalent)
WASHER
2
20 N510009969AA WASM12-5-1
LINEAR-BUSH
1
25 N510028440AA LM16-UU
LINEAR-BUSH
2
26 N510028443AA LMT16-UU
SCREW
1
28 N510018394AA
Hexagon socket set screw Cone point M3X8-45H A2J (Trivalent)
BEARING
2
32 N510024787AA 6000ZZ
COLLAR
4
36 KXF0DYSZA00 NCLM4-6-10.0
GREASE-NIPPLE
1
37 KXF0CSNAA00 GPA6A
BOLT
8
42 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
2
44 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
8
45 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
BOLT
6
46 N510017437AA
Hexagon socket head cap screw M6X25-10.9 A2J (Trivalent)
BOLT
4
49 N510017321AA
Hexagon socket head cap screw M3X25-10.9 A2J (Trivalent)
WASHER
4
50 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
2
51 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
4
52 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
1
53 N510018505AA
Round finish plain washer 10 10H A2J (Trivalent)
WASHER
1
54 N510018483AA
Small round-plain washer 10 10H A2J (Trivalent)
WASHER
8
55 N510020100AA Thick washer for M5
WASHER
4
56 N510020101AA Thick washer for M6
WASHER
4
57 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
WASHER
2
58 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
NUT
2
59 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
NUT
1
60 N510017887AA
Hexagon nut Type-1 Best class M10-6H-4T A2J (Trivalent)
BOLT
1
61 N510017169AA
Hexagon socket head cap screw M10X35-10.9 A2J (Trivalent)
M60
-
-
( KN610012610AA-03-2 )
