1 Introduction and Installation User Manual Line Computer UNIX
1.5 Software Installation Software Version 502.xx 10/2000 Issue
32
I
t I I
● Remove Installation Diskette and insert the CD-ROM.
● Press any key on the keyboard.
The system is rebooted. When the booting procedure has been completed, the following lines
are displayed:
login:
● Enter plr after "login:" and press RETURN.
Password:
● Enter plr after "Password" and press RETURN.
NOTE
With some hardware configurations the message Terminal is ansi is displayed.
● Acknowledge this message by pressing RETURN.
The CD-ROM is now read in. This takes approx. 10 minutes.
While the data are being read in, information about the ongoing activities is displayed.
If no data are available in the line computer, the following query appears:
There is no user data (SDH) on the line computer.
Do you want to install:
Do you want to install default libraries (GF-/BE-/RI-Bibliothek..) [1]
User data (SDH) saved from old installation [2]
Do not install any data [3]
Please select your choice... ’1’, ’2’ or ’3’
If option 1 is selected, the default libraries will be installed,
if option 3 is selected, only the ST-Bibliothek,
if option 2 is selected, the data previously saved under SCO 3.0 or SCO 5.0 are restored. In this
case the operator is prompted to insert the diskette and the tape containing the backed-up data.
CAUTION
If options 1 and 3 are selected, the line configuration needs to be performed via the Line Editor follo-
wing the installation (see chapt. 12, section 12.2).
● Enter the number of the desired option and confirm by pressing RETURN.
The selected data will be installed.
User Manual Line Computer UNIX 1 Introduction and Installation
Software Version 502.xx 10/2000 Issue 1.5 Software Installation
33
I
t I I
If a master data pool already exists on the computer, the following query appears:
Converting GF-Bibliothek (7xx/8xx/9xx-nozzle)
Do you want to update 7xx/8xx/9xx-nozzles
and sensor specific information (10/12/13/14/17.SST) now [y/n]
● Enter y and confirm your entry by pressing RETURN.
The 7xx/8xx/9xx type nozzles and the sensor types 10, 12, 13, 14, 17 are being entered in the
GF-files. Previously entered 7xx-nozzles are retained.
In the standard range (GF-nos. 1 through 1499) the allocation of the nozzles is carried out via a Table.
The allocations of customer-specific package forms are calculated.
In the Import/Expor directory a "GFupgrade403.log" file is created containing a list of all alloca-
tions. The content of the file can be displayed and printed out by means of the file display option
(see chapt. 4, section 4.5).
Any incorrectly assigned nozzles can be changed subsequently by means of the Package Form
Editor. If a sensor system type 7 already exists, sensor system type 10 will be entered in addition.
Where sensor system type 8 has already been entered, sensor system type 17 will be entered in
addition.
After converting the GF-Bibliothek, first the options for the paper format of the printer ("Configuration of paper
format") are displayed on the screen.
1) A4-Paper
2) Letter
Please choose:
● Enter the number of the desired format and confirm by pressing RETURN.
Now the options for the configuration of the desktop ("Desk-Configuration") are displayed on the screen.
1) Programming
2) Controlling
Enter a value in between [1-2]:
Enter 1 if the desktop (see chapt. 3) is to be set up as a programming station, or enter 2 if the desktop
is to be set up as a control station, and confirm your entry by pressing RETURN.
1 Introduction and Installation User Manual Line Computer UNIX
1.5 Software Installation Software Version 502.xx 10/2000 Issue
34
I
t I I
A menu for the selection of a production line (example) is displayed only if line configurations exist (see
chapt. 12, section 12.2.1):
1) SMT
2) ERP_L2
Please select a line [1-2]:
● Enter number of line (e.g. 1 for SMT) and press RETURN.
Do you want to configure the LRU software for line SMT [y/n]:
● Enter y and press RETURN.
The line is configured.
A list containing the allocations of the time zone settings is displayed ("Timezone-Configuration").
Select a timezone [1-12]:
● Enter number of time zone desired and confirm by pressing RETURN.
Now the language to be used by the LC system when it is started up can be selected ("Language-
Configuration").
(1) D = Deutsch (German) 2) F = French 3) GB = English 4) I = Italian )
5) J = Japanese
Enter a value in between [1-5]:
● Enter number of language desired and confirm by pressing RETURN.
NOTE
Only in cases where a second LAN card for the SIPLACE LAN is installed in the line computer, will
the IP address, netmask and broadcast address of the LAN card for the SIPLACE LAN be displayed
together with an inquiry as to whether they are to be changed.
● Enter y and press RETURN if the data are to be changed.
Enter internet address for SIPLACE network card
(<Return> for default....):
