1 Introduction and Installation User Manual Line Computer UNIX
1.5 Software Installation Software Version 502.xx 10/2000 Issue
34
I
t I I
A menu for the selection of a production line (example) is displayed only if line configurations exist (see
chapt. 12, section 12.2.1):
1) SMT
2) ERP_L2
Please select a line [1-2]:
● Enter number of line (e.g. 1 for SMT) and press RETURN.
Do you want to configure the LRU software for line SMT [y/n]:
● Enter y and press RETURN.
The line is configured.
A list containing the allocations of the time zone settings is displayed ("Timezone-Configuration").
Select a timezone [1-12]:
● Enter number of time zone desired and confirm by pressing RETURN.
Now the language to be used by the LC system when it is started up can be selected ("Language-
Configuration").
(1) D = Deutsch (German) 2) F = French 3) GB = English 4) I = Italian )
5) J = Japanese
Enter a value in between [1-5]:
● Enter number of language desired and confirm by pressing RETURN.
NOTE
Only in cases where a second LAN card for the SIPLACE LAN is installed in the line computer, will
the IP address, netmask and broadcast address of the LAN card for the SIPLACE LAN be displayed
together with an inquiry as to whether they are to be changed.
● Enter y and press RETURN if the data are to be changed.
Enter internet address for SIPLACE network card
(<Return> for default....):
User Manual Line Computer UNIX 1 Introduction and Installation
Software Version 502.xx 10/2000 Issue 1.5 Software Installation
35
I
t I I
● Enter the address and press RETURN.
The entry is displayed.
Is the internet address ’...’ correct [y/n]:
● Enter y and press RETURN if the entry is correct.
(Enter n and press RETURN if the entry needs to be corrected).
Enter netmask for SIPLACE network card
(<Return> for default....):
● Enter the number of the "netmask" and press RETURN.
The entry is displayed.
Is the netmask ’...’ correct [y/n]:
● Enter y and press RETURN if the entry is correct.
(Enter n and press RETURN if the entry needs to be corrected).
Enter broadcast address for SIPLACE network card
(<Return> for default....):
● Enter the number of the "broadcast address" and press RETURN.
The entry is displayed.
Is the broadcast address ’...’ correct [y/n]:
● Enter y and press RETURN if the entry is correct.
(Enter n and press RETURN if the entry needs to be corrected).
The entry of y completes the configuration of the LAN card.
A note is now displayed on the handling regarding OEM software, as well as the steps to be per-
formed following the start of the LC program (consistency check via Data Manager of setups and
line configuration).
In addition you will be informed that a version check of the station software
should be performed.
Next, the following prompt is displayed.
Please take out the CD and press <RETURN>
● Remove the CD and the diskette, if applicable, and press RETURN.
● Press any key on the keyboard.
After a short time a message is displayed on the screen requesting you to reboot the system.
1 Introduction and Installation User Manual Line Computer UNIX
1.5 Software Installation Software Version 502.xx 10/2000 Issue
36
I
t I I
** Safe to Power Off **
- or -
** Press Any Key to Reboot **
● Press any key on the keyboard.
The computer system reboots.
CAUTION
In the event that the boot diskette (see
page 1 - 29) used for the SW installation was not the correct
one, an error message will be displayed during the shutdown process (prior to “Safe to Power Off”).
Upon the subsequent booting of the computer, the following queries have to be answered:
There may be a system dump memory image in the swap device!
Do you want to save a copy of it?
[y/n]
● Enter n and press RETURN.
Do you want to remove the dump from the swap device now?
[y/n]
● Enter y and press RETURN.
It is imperative that the two preceding questions be answered as indicated, as otherwise problems
with the operating system are likely to arise.
Okay to check the root filesystem
[y/n]
● Enter y and press RETURN.
After a while, the "Login" dialog box (see
chapt. 2, section 2.1.1) appears.
● Type plr in the "login" editing field and press the RETURN key.
● Type plr in the "Password" editing field and press the RETURN key.
The LC software is started with the selected desktop configuration and language.
ATTENTION !
After any initial installation of the LC software has been carried out, it is mandatory that following
start-up of the line computer the stations be configured with the aid of the Configuration Editor (see
chapt. 12) before proceeding further. Subsequently, the line must be configured with the aid of the Line
Editor (see
chapt. 12).
Whenever an Update or Upgrade of the LC software is performed, it is absolutely necessary that
after the software has been started up, all set-ups be checked for consistency using the "Consistency
Checker" (see chapt. 4, section 4.3.4.6).
NOTE
Upon the first log-on to the LC system, the users "line engineer", "programmer", "operator" do not initially
have a password.
The user "supervisor" has the password "supervisor". Following the software installation, this password
needs to be changed by an authorized person.
