xxii Safety instructions 3.4 Label positions T he following warning/caution labels are attached to the Y AMAHA products to ensure safe and correct use. Check that the information on eac h label is clearly legible and str…
xxi
Safety instructions
Potential
hazard
Machine damage
To avoid
hazard
If machine is not to be used for 6 months or more, block off the solvent path to protect solvent
pump.
Applicable
machines
All solder paste printers
Case
Maintenance
Potential
hazard
Might disable machine functions
To avoid
hazard
Periodically replace USP battery since it has a limited service life.
Applicable
machines
Machines equipped with UPS (option)
Case
Maintenance
Potential
hazard
Machine damage
To avoid
hazard
Read manuals and use correct procedure to operate machine.
Applicable
machines
YS24X (machines equipped with sATS II)
Case
All case
xxii
Safety instructions
3.4 Label positions
The following warning/caution labels are attached to the YAMAHA products to ensure safe and correct use.
Check that the information on each label is clearly legible and strictly comply with the instructions.
For safety precautions other than those on the labels shown in this section, see the instructions in "1. Safety".
n
NOTE
Basically, labels are attached to the positions shown below, although they may differ slightly depending on the
machine model.
n
NOTE
When connecting power to this equipment, refer to "Power connection terminals" described in the appendix of the
maintenance manual or user's manual.
Warning labels
Front side
N Open/close cover section
N Open/close cover inner side
N Open/close cover
N Open/close cover
N Conveyor opening
N Main switch
N Panel inner side
N Conveyor lower base section
N Machine front side, Lower panels
93201-H0-10
xxiii
Safety instructions
n
Label positions
Warning labels
Rear side
N Open/close cover
N Open/close cover inner side
N Transparent cover inner side
N Conveyor opening
93203-H0-10
