Tape feeder module 16mm X FS07
Page 11 / 13 16.09.2021
Pos. Item no. Description Part marking
29 03013422-01 BOLT /FOIL DISPOSAL X16
30 03023217-01 ISO 7046-2-M2 X 5-A2-70-H STANDARD PARTS
31 03010342S02 RATCHET BRACE COMPL./ FOLD
ROLLER X8
SPARE PART
32 03009848-01 DIN 1469-C 2 X 6-ST
33 03042536-01 ISO 4762 - M 2,5 X 12-A2-70 STANDARD PARTS
34 00318387-01 SN 213307-H-M2 X 3-A2
35 03023216-01 ISO 7046-2-M2 X 4-A2-70-H
36 03012488-01 SN 213307-H-M2 X 2.5-A2
37 03023228-01 ISO 7046-2-M2,5 X 6-A2-70-H STANDARD PARTS
38 03042535-01 ISO 4762 - M 2,5 X 10-A2-70 STANDARD PARTS
39 03117039S01 STUFFING WHEEL , GEARED CPL.
X16
SPARE PART
40 03050825-01 HOLDING SCREW WEAR PART
41 03042532-01 ISO 4762 - M 2,5 X 5-A2-70 STANDARD PARTS
42 03010415S01 TENSION SPRING Z-051GX SPARE PART
43 03050686S02 MOTOR CPL. /FOIL DISPOSAL X-
SERIES
SPARE PART
44 03043774-01 ADJUSTMENT WASHER /D3.1 D15
T0,1
STANDARD PARTS
45 03096933S01 STRIPPER PLATE, FOIL DISPOSAL
X16
SPARE PART
46 03012359-02 MOTOR MOUNT WITH PICKUP
WINDOW /X16
47 03020730-03 DRIVE W. ATTACHMENTS /X16-88
48 03012822-07 DRIVE KPL. X16-88
49 03012824-04 ENGINEMOUNTING PRE-ASSEMBLED
/X16
50 03005196-01 ROLL, LOCKING X-SERIES SPARE PART
51 00359779-01 DIN 6325 - 3M6 X 10-ST
52 00326589-01 DIN 965-M3 X 10-A2
53 00349527-01 ROUND MAGNET 3X4 NEODYMIUM SPARE PART
54 03019604S01 SLIDING FOIL X-FEEDER SPARE PART
55 03058808S01 SLIDING GUIDE SPARE PART
00344017-02 BEARING SCREW
57 03023216-01 ISO 7046-2-M2 X 4-A2-70-H
58 03012488-01 SN 213307-H-M2 X 2.5-A2
Tape feeder module 16mm X FS07
Page 12 / 13 16.09.2021
Pos. Item no. Description Part marking
59 03011739S03 ENERGY-DATA INTERFACE CPL. /X-
SERIES
SPARE PART
60 03020291S03 LEVER /OPENER TAPE SLIDER
X16-88
SPARE PART
61 03010185S01 ROTARY SLIDE / COMPONENTS
DISPOSAL X8
SPARE PART
62 03020557S01 EJECTOR SPARE PART
63 03050825-01 HOLDING SCREW WEAR PART
64 03050957-01 SHOULDER BOLT DIA4X3.15 M3 SPARE PART
65 03012683-01 COMPRESSION SPRING D-027 SPARE PART
66 03018028-01 CURVED SPRING WASHER FS3X4,5
67 03023216-01 ISO 7046-2-M2 X 4-A2-70-H
68 03042524-01 ISO 4762 - M 2 X 5-A2-70 STANDARD PARTS
69 03014318-01 TAPE SUPPORT CPL. RIGHT SIDE
/X16
70 03021264-01 SCREW / BEARING PICK-UP
WINDOW X16-88
STANDARD PARTS
71 03020562S01 HOLDER / CLIP PICK-UP WINDOW
X16-88
SPARE PART
72 03023217-01 ISO 7046-2-M2 X 5-A2-70-H STANDARD PARTS
73 03021035S03 PICKUP WINDOW CPL. /X16 SPARE PART
74 03021264-01 SCREW / BEARING PICK-UP
WINDOW X16-88
STANDARD PARTS
75 03021215S01 COVER LEFT SIDE /FEEDER X16-88 SPARE PART
76 03022320-01 SUPPORTING BLOCK X16-88 SPARE PART
77 03022396S02 TAPE INFEED SPRING /X16 SPARE PART
78 00328542-01 SN 213307-H-M2,5 X 6-A2 STANDARD PARTS
79 03033798-01 REMFORM-SCREW RF-SN75-2,5 X
10-9.8
STANDARD PARTS
80 03044543-01 REMFORM-SCREW RF-SN85-2,5 X
7,5-9.8
STANDARD PARTS
81 03015453-01 ISO 7046 - M2,5 X 10-4.8 - H
82 00322558-01 SN 213307-H-M3 X 5-A2 STANDARD PARTS
83 03033796-01 REMFORM-SCREW RF-SN75-2,5 X
6-9.8
STANDARD PARTS
84 03032038S01 HEAT GUIDANCE FOIL 100 PC. CONSUMABLE
85 03031926S01 NOTE: TEMPERATURE ( 100 PC ) CONSUMABLE
86 00365111-01 SEALING FOR COVER STRIP
STUFFING GEAR
SPARE PART
Tape feeder module 16mm X FS07
Page 13 / 13 16.09.2021
Pos. Item no. Description Part marking
87 03003541S02 DISTRIBUTOR BOARD 8/12 X SPARE PART
88 00141292S07 TAPE FEEDER MOD. 16MM X W.
SPLICE SENSOR
Spare Part
89 03040855-05 TAPE FEEDER MOD. 16MM X SPLICE
SENSOR
90 03012810-07 TAPE FEEDER MODUL 16MM X
91 03038133S01 SPLICE SENSOR S5 SPARE PART
